TCD210117AA_MODI
2-Phase Closed-loop
Stepper Motor Driver
AiS-D Series
PRODUCT MANUAL
For your safety, read and follow the considerations written in the instruction
manual, other manuals and Autonics website.
The specifications, dimensions, etc. are subject to change without notice for product
improvement. Some models may be discontinued without notice.
Features
• Closed-loop system with real-time position control
• High speed & high torque drive witout missing steps
• Easy operation setting with external adjuster (Gain, Speed filter, In-position, Resolution)
• Built-in brake type motors available (AiS-D-B Series)
ᜢ ᜫ
Safety Considerations
• Observe all 'Safety Considerations' for safe and proper operation to avoid hazards.
• ᜸ symbol indicates caution due to special circumstances in which hazards may occur.
᜸ Warning
Failure to follow instructions may result in serious injury or death.
01. Fail-safe device must be installed when using the unit with machinery that may
cause serious injury or substantial economic loss. (e.g. nuclear power control,
medical equipment, ships, vehicles, railways, aircraft, combustion apparatus,
safety equipment, crime / disaster prevention devices, etc.)
Failure to follow this instruction may result in personal injury, economic loss or fire.
02. Do not use the unit in the place where flammable / explosive / corrosive gas,
high humidity, direct sunlight, radiant heat, vibration, impact or salinity may be
present.
Failure to follow this instruction may result in explosion or fire.
03. Do not connect, repair, or inspect the unit while connected to a power source.
Failure to follow this instruction may result in fire or electric shock.
04. Install the unit after considering counter plan against power failure.
Failure to follow this instruction may result in personal injury, economic loss or fire.
05. Check 'Connections' before wiring.
Failure to follow this instruction may result in fire.
06. Do not disassemble or modify the unit.
Failure to follow this instruction may result in fire or electric shock.
07. Install the driver in the housing or ground it.
Failure to follow this instruction may result in personal injury, fire or electronic shock.
08. Do not touch the unit during or after operation for a while.
Failure to follow this instruction may result in burn or electric shock due to high
temperature of the surface.
09. Emergency stop directly when error occurs.
Failure to follow this instruction may result in personal injury or fire.
᜸ Caution
Failure to follow instructions may result in injury or product damage.
01. When connecting the power input, use AWG18 (0.75 mm
02. Brake is non-polar. When connecting the brake, use AWG24 (0.2 mm
over.
Failure to follow this instruction may result in fire or malfunction due to contact failure.
03. To use the motor safely, do not apply external force to the motor.
04. It is recommended to use STOPPER for the vertical load.
05. Install over-current prevention device (e.g. the current breaker, etc.) to connect
the driver with power.
Failure to follow this instruction may result in fire.
06. Check the control input signal before supplying power to the driver.
Failure to follow this instruction may result in personal injury or product damage by
unexpected driver movement.
07. Install a safety device to maintain the vertical position after turn off the power of
this driver.
Failure to follow this instruction may result in personal injury or product damage by
releasing holding torque of the motor.
08. Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or product damage.
09. Use a dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in fire or electric shock.
10. The driver may overheat depending on the environment.
Install the unit at the well-ventilated environment and forced cooling with a
cooling fan.
Failure to follow this instruction may result in product damage or degradation by heat.
11. Keep the product away from metal chip, dust, and wire residue which flow into the
unit.
Failure to follow this instruction may result in fire or product damage.
12. Use the designated motor only.
Failure to follow this instruction may result in fire or product damage.
) cable or over.
2
) cable or
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AiS-D Series and is the answer not in the manual?

Questions and answers

Related Manuals for Autonics AiS-D Series

Summary of Contents for Autonics AiS-D Series

  • Page 1 For your safety, read and follow the considerations written in the instruction Install the unit at the well-ventilated environment and forced cooling with a manual, other manuals and Autonics website. cooling fan. The specifications, dimensions, etc. are subject to change without notice for product Failure to follow this instruction may result in product damage or degradation by heat.

  • Page 2: Ordering Information

    -|Transparent Guide|- Cautions during Use Dimensions • Unit: mm, For the detailed drawings, follow the Autonics website. • Follow instructions in ‘Cautions during Use’ . Otherwise, it may cause unexpected accidents. • Power supply should be insulated and limited voltage/current or Class 2, SELV power supply device.

  • Page 3: Specifications

    -|Transparent Guide|- Specifications Connectors ■ Power connector Model AiS-D-20□A AiS-D-28□B AiS-D-35□B Power supply 24 VDCᜡ ±10% Pin Function Max. RUN power ≤ 50 W ≤ 60 W 24VDCᜡ Stop power ≤ 10 W Max. RUN current 0.6 A / Phase 1.0 A / Phase 1.2 A / Phase ■...
  • Page 4 -|Transparent Guide|- Connections ■ Resolution setting rotary switch The setting will be applied when motor stops. Signal I/O □ 20 / 42 / 56 / 60 mm □ 28 / 35 mm Setting Resolution Resolution Motor Encoder 0 (factory default) 500 220 Ω...

  • Page 5: Control Input

    -|Transparent Guide|- Control Input ■ Alarm / Warning • Depending on the alarm type, it flashes for 0.4 sec interval and it turns OFF for 0.8 sec ■ Position command pulse repeatedly. • Pulse input is selectable from 1-pulse input method and 2-pulse input method. <e.g: alarm no.
  • Page 6 • Recommended to use ferrite core at both ends of the cable. • The model name is 010, 020, 030, 050, 070, 100, 150, 200 which indicates the cable length. E.g.) CO20-MP070-R: 7 m I/O cable 18, Bansong-ro 513Beon-gil, Haeundae-gu, Busan, Republic of Korea, 48002 www.autonics.com | +82-2-2048-1577 | sales@autonics.com...
