- Page 1 Mitre Saw BMS14007 UBMS14007 BMS14007-4 BMS14007-6 BMS14007-8 BMS14007S INGCO Global...
- Page 2 2|English The symbols in instruction manual and the label on the tool Double insulated for additional protection. Read the instruction manual before using. CE conformity. Wear safety glasses, hearing protection and dust mask. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
- Page 3 3|English GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"...
- Page 4 4|English suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
- Page 5 5|English 4) Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.
- Page 6 6|English a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Safety instructions for mitre saws a) Mitre saws are intended to cut wood or wood-like products, they cannot be used with abrasive cut-off wheels for cutting ferrous material such as bars, rods, studs, etc.
- Page 7 7|English the fence. l) Provide adequate support such as table extensions, saw horses, etc. for a workpiece that is wider or longer than the table top . Workpieces longer or wider than the mitre saw table can tip if not securely supported. If the cut-off piece or workpiece tips, it can lift the lower guard or be thrown by the spinning blade.
-
Page 8: Specification
8|English SPECIFICATION BMS14007,BMS14007-4, BMS14007-6(ISRAEL Plug), UBMS14007 Model No. BMS14007-8(BS Plug), BMS14007S(SAA Plug) Rated Input power: Rated voltage: /60Hz No-load speed: 5000/min 5000/min ˝ bore Blade diameter: mm x - /4˝ x Number of teeth: Mitre table angles: 0 to 45 to the left &right 0 to 45 to the left &right... -
Page 9: General Safety Rules
9|English EXAMINE ALL PARTS CAREFULLY WARNING! If any part is missing or damaged, do not plug in the mitre saw until you have replaced the missing or damaged parts. GENERAL SAFETY RULES WARNING! When using electric tools basic safety precautions should always be Read all these instructions before attempting to operate your product. - Page 10 10|English if cutting operations create dust. f I . connection of dust extraction and collecting equipment, ensure these are connected and properly used. 11) Do not abuse the cable. Never pull the cable to disconnect it from the socket. Keep the cord away from heat, oil and sharp edge. 12) Secure work.
-
Page 11: Additional Safety Rules For Mitre Saws
11|English switch does not turn it on and off. 21) WARNING . The use of any accessory or attachment other than one recommended in this instruc tion manual may present a risk of personal 22) Have you r to ol rep aired by a qu alified person . This electric to ol com plies w it h th e relevant safety rules. - Page 12 12|English - gloves for handling saw blades (saw blades shall be carried in a holder wherever practicable) and rough material. WARNING! of loose materials e.g. chips and cut-offs. Use correctly sharpened saw blades. Observe the maximum speed marked on the saw blade. Repair s sh all only be carried out by the laser m anufacturer or an authorise d agent .
-
Page 13: Environmental Protection
13|English SYMBOLS V .... volts A... amperes Hz... hertz W..... watts min..minutes~..alternating current h... hours Class II Construction I …………...ON O ....OFF min -1 …………………..revolutions per minute Wear safety goggles Wear ear protection Wear a breathing mask and all bystanders must read and understand instruction manual before using this product. - Page 14 14|English BMS14007 , UBMS14007 , BMS14007-4 , BMS14007-6 , BMS14007-8 , BMS14007S...
-
Page 15: Spare Part List
15|English SPARE PART LIST BMS14007 , UBMS14007 , BMS14007-4 , BMS14007-6 , BMS14007-8 , BMS14007S Part Description Part Description Screw M10X10 Bracket Spring Cap of Rocker Pin Steel Ball Φ8.5 Rocker Pin Nut M8 Screw/8.8 M4X8 Base Screw/8.8 M4X8 Bracket... - Page 16 16|English SPARE PART LIST BMS14007 , UBMS14007 , BMS14007-4 , BMS14007-6 , BMS14007-8 , BMS14007S Part Description Part Description Screw M5X40 Inner Flange Lock Base Screw M4X8 Lock Trigger Blade Spring Outer Flange Screw M5X16 Screw M8X16 Retainer Plate Screw ST4X16...
- Page 17 INGCO TOOLS CO., LIMITED No. 45 Songbei Road, Suzhou MADE IN CHINA Industrial Park, China. 0621.V01 BMS14007 UBMS14007 BMS14007-4 BMS14007-6 BMS14007-8 BMS14007S...
