- Page 1 Trio G20/G25/G25.3 (natural gas) Instructions for installation (GB / IE) Please retain this document carefully...
-
Page 2: Table Of Contents
Appendix 4 Figures Preface DRU, a manufacturer of gas heating appliances, develops and produces products that comply with the highest qua- lity, performance and safety requirements. This guarantees that the user will be able to enjoy using his product for many years to come. -
Page 3: Introduction
The appliance is supplied with a wireless remote control that works on batteries. CE Declaration We hereby declare, that the design and construction method of the gas-fired heating appliance issued by Dru complies with the essential requirements of the gas appliance directive. -
Page 4: Instructions
- Do not make any changes to the appliance. 6.2.1 Reconstruction to different type of gas If you want to convert this appliance into a different type of gas, please contact DRU’s service department and ask what is possible. Reconstructions should only be performed by authorized gas installers. -
Page 5: Flue Gas Discharge / Combustion Air Supply System
If necessary, you can also use an existing discharge channel (see section 6.5.4). Caution - Only use the concentric system supplied by DRU (Ø100 / Ø150 mm). This system was tested in combination with the appliance; DRU cannot guarantee a proper and safe operation of other systems and cannot accept liability for these systems;... - Page 6 t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Use a parker to fix the clip binding to the pipe on locations that are unreachable after installation; ➠...
- Page 7 t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Table 1: Relation construction concentric system / setting appliance total number of total number of meters vertical and/or sloping pipe length meters horizontal ↓8...
- Page 8 t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Table 3: Relation construction concentric system / setting appliance total number of total number of meters vertical and/or sloping pipe length meters horizontal ↓8...
-
Page 9: Connecting Gas
The following requirements apply when connecting to an existing chimney flue: - only allowed when used in combination with the special DRU chimney installation set. The installation regulation is also supplied; - the dimensions should be at least 150 x 150 mm;... -
Page 10: Panes
t r i o i n s t r u c t i o n f o r i n s ta l l at i o n 6.8.1 Wood set The wood set consists of vermiculite (see Appendix 4, Fig. 8), chips (see Appendix 4, Fig. -
Page 11: Wireless Remote Control
t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Wireless remote control The appliance is supplied with a wireless remote control. Ignition, controlling the flame height and switching off are performed by a remote control that operates a receiver in the control box. -
Page 12: Alternative Operation
4, Fig. 20). For connecting an external control unit, you will need a “Domotics connection cable for GV60”. Consult DRU’s service website. The following contacts are possible: - Ignition: connect both contacts 1 + 3, for one second (if there is a 2nd thermocouple, the appliance should burn at full power for at least 20 sec. -
Page 13: Flame Picture
t r i o i n s t r u c t i o n f o r i n s ta l l at i o n 8.3.1 First ignition of the appliance after installation or adjustments !Caution After installation, or after work has been performed, you should ignite the appliance for the first time without the glass window. -
Page 14: Delivery
t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Caution - If necessary, place back the wood set correctly; see section 6.8. Inspect the flue gas discharge / combustion air supply system;... -
Page 15: Storingen
t r i o i n s t r u c t i o n f o r i n s ta l l at i o n 11. Storingen Malfunction search diagram atmospheric gas-fired heating appliance with electronic ignition: Starting up cycle. Start 1.05 1.01... - Page 16 t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Fires with electronic ignition, fault finding: Ignition and burning Start 2.10 Do(es) main burner(s) 2.06 Pilot can be lit.
- Page 17 Lack of combustion air. Check: two/three sided appliances flue system permissible; (no slots allowed). proper flue terminal used, make should be ‘DRu’; Flames: too high terminal correctly sited on Line pressure. roof or wall relative to Burner pressure.
-
Page 18: Appendix 1 Parts Included With The Delivery
t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Appendix 1 Parts included with the delivery In the following table you can find the parts that are supplied with the appliance. Table 5: Parts included with the delivery Part Quantity... -
Page 19: Appendix 4 Figures
t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Appendix 4 Figures 1x90° 38c-744f max. 3m Fig. 1 Fig. 2 Fig. 3 Fig. - Page 20 t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Fig. 7 Fig. 8 Fig. 9 Fig. 10...
- Page 21 t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Fig. 11 Fig. 12 Fig. 13 Fig. 14...
- Page 22 t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Fig. 15 Fig. 16 Fig. 17 Fig. 18 Fig. 19...
- Page 23 t r i o i n s t r u c t i o n f o r i n s ta l l at i o n Fig. 20 Fig. 21 38p-0181 38C-2031/1 Fig. 22 Fig. 23 38p-0182 38p-0179 Fig.
- Page 24 DRu Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven Ratio 8, NL-6921 RW Duiven...
