Service Manual Paper Feeder PF 520 PF 530 First Edition Date: 26-05-2010 3M9SM060...
Page 2
Service Manual Paper Feeder PF 520 PF 530 First Edition Date: 26-05-2010 3M9SM060...
Page 3
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. It may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste officials for details in your area for proper disposal. ATTENTION IL Y A UN RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN MODELE DE TYPE INCORRECT.
Page 4
Revision history Revision Date Replaced pages Remarks...
Page 6
Safety precautions This booklet provides safety warnings and precautions for our service personnel to ensure the safety of their customers, their machines as well as themselves during maintenance activities. Service personnel are advised to read this booklet carefully to familiarize themselves with the warnings and precautions described here before engaging in maintenance activities.
Page 7
Safety warnings and precautions Various symbols are used to protect our service personnel and customers from physical danger and to prevent damage to their property. These symbols are described below: DANGER: High risk of serious bodily injury or death may result from insufficient attention to or incorrect compliance with warning messages using this symbol.
Page 8
1. Installation Precautions WARNING • Do not use a power supply with a voltage other than that specified. Avoid multiple connections to one outlet: they may cause fire or electric shock. When using an extension cable, always check that it is adequate for the rated current...................... •...
Page 9
2. Precautions for Maintenance WARNING • Always remove the power plug from the wall outlet before starting machine disassembly....• Always follow the procedures for maintenance described in the service manual and other related brochures............................• Under no circumstances attempt to bypass or disable safety features including safety mechanisms and protective circuits.
Page 10
• Do not remove the ozone filter, if any, from the copier except for routine replacement....... • Do not pull on the AC power cord or connector wires on high-voltage components when removing them; always hold the plug itself......................•...
3M9/3NA 1-2 Installation 1-2-1 Installation environment Installation location (Be based on the machine establishment place.) Avoid direct sunlight or bright lighting. Ensure that the photoconductor will not be exposed to direct sunlight or other strong light when removing paper jams. Avoid locations subject to high temperature and high humidity or low temperature and low humidity;...
3M9/3NA 1-2-2 Unpacking (1) Unpacking Figure 1-2-1 1. Paper feeder 7. Left sub-cursor* 2. Outer case 8. Right sub-cursor* 3. Plastic bag 600 x 800 9. Installation guide etc. 4. Left pad *: Multi purpose feeder only. 5. Right pad 6.
3M9/3NA (2) Removing the tapes Procedure 1. Remove the tapes. Paper feeder Paper feeder (Normal): two tapes (Normal) Multi purpose feeder: four tapes Tape Tape Multi purpose Tape feeder Tape Tape Tape Figure 1-2-2 1-2-3...
3M9/3NA (3) Attaching the sub-cursors (Multi purpose feeder only) Procedure 1. Attach the right and left sub-cursors to the cassette. Right sub-cursor Right sub-cursor Left sub-cursor Cassette Left sub-cursor Figure 1-2-3 1-2-4...
3M9/3NA 1-3 Troubleshooting 1-3-1 Paper misfeed detection (1) Paper misfeed indication When a paper misfeed occurs, the machine immediately stops printing and displays the paper misfeed mes- sage on the operation panel. To remove paper misfed in the machine, open the PF rear cover. Paper jammed in cassette 2.
3M9/3NA (2) Paper misfeed detection condition Machine Paper jam location Cassette 1 MP tray Machine inside Fuser/Eject sections Duplex section Cassette 2 Cassette 3 Sensors Paper feeder 1 Registration sensor MP feed sensor Eject sensor PF feed sensor 1 Paper feeder 2 PF feed sensor 2 Figure 1-3-2 Paper jam location 1-3-2...
Page 24
3M9/3NA Code Contents Conditions location* 0211 Rear cover open (paper The rear cover of paper feeder 1 is opened during feeder 1) printing. 0212 Rear cover open (paper The rear cover of paper feeder 2 is opened during feeder 2) printing.
3M9/3NA 1-3-2 Self-diagnostic function (1) Self-diagnostic function This machine is equipped with self-diagnostic function. When a problem is detected, the machine stops print- ing and display an error message on the operation panel. An error message consists of a message prompting a contact to service personnel and a four-digit error code indicating the type of the error.
3M9/3NA (2) Self diagnostic codes If the part causing the problem was not supplied, use the unit including the part for replacement. Check procedures/ Code Contents Causes corrective measures Defective bottom Check to see if the bottom plate can move 1020 PF lift motor error (paper feeder 1)
Page 27
3M9/3NA Check procedures/ Code Contents Causes corrective measures 1500 PF heater 1 high tempera- Defective connec- Reinsert the connector. Also check for conti- ture error tor cable or poor nuity within the connector cable. If none, (paper feeder 1) contact in the con- replace the cable.
Page 28
3M9/3NA Check procedures/ Code Contents Causes corrective measures 1600 PF heater 1 low temperature Defective connec- Reinsert the connector. Also check for conti- error (paper feeder 1) tor cable or poor nuity within the connector cable. If none, An external temperature contact in the con- replace the cable.
Page 29
3M9/3NA Check procedures/ Code Contents Causes corrective measures 1620 PF heater 1 low temperature Defective connec- Reinsert the connector. Also check for conti- error (paper feeder 2) tor cable or poor nuity within the connector cable. If none, An external temperature contact in the con- replace the cable.
Page 30
3M9/3NA Check procedures/ Code Contents Causes corrective measures 1800 Paper feeder communica- Improper installa- Follow installation instruction carefully again. tion error tion paper feeder. Communication error between Defective connec- Reinsert the connector. Also check for conti- engine PWB and optional tor cable or poor nuity within the connector cable.
3M9/3NA 1-3-3 Electric problems If the part causing the problem was not supplied, use the unit including the part for replacement. Troubleshooting to each failure must be in the order of the numbered symptoms. Problem Causes Check procedures/corrective measures 1. No electricity at the Measure the input voltage.
Page 32
3M9/3NA Problem Causes Check procedures/corrective measures 1. Defective connector Reinsert the connector. Also check for continuity within the The size of paper cable or poor con- connector cable. If none, replace the cable. on the cassette is tact in the connector. PF cassette size switch and PF main PWB (YC2) not displayed cor- 2.
3M9/3NA 1-3-4 Mechanical problems If the part causing the problem was not supplied, use the unit including the part for replacement. Problem Causes/check procedures Corrective measures Check if the surfaces of the following roll- Clean with isopropyl alcohol. No primary paper ers are dirty with paper powder.
3M9/3NA 1-4 Assembly and disassembly 1-4-1 Precautions for assembly and disassembly (1) Precautions Before starting disassembly of the paper feeder, press the Power key on the operation panel to off. Make sure that the Power lamp is off before turning off the main power switch. And then unplug the power cable from the wall outlet.
3M9/3NA 1-4-2 Paper feed section (1) Detaching and refitting the retard roller Procedure 1. Open the PF rear cover. 2. Release two hooks and then remove Hook the retard guide and retard spring. Retard spring Retard guide Hook PF rear cover Retard guide/ Retard spring Figure 1-4-2...
Page 36
3M9/3NA 4. Check or replace the retard roller unit and refit all the removed parts. *: Before refitting the retard roller unit, firmly install the retard spring onto the projec- tion of the retard roller unit. Retard roller unit Retard guide /Retard spring Retard guide Retard roller unit...
3M9/3NA (2) Detaching and refitting the paper feed roller unit Procedure 1. Remove the cassette. 2. Remove the retard roller unit (see page 1-4-2). Cassette Figure 1-4-5 3. Turn the paper feeder with the bottom side up. Paper feeder Figure 1-4-6 1-4-4...
Page 38
3M9/3NA 4. While pressing the lever A and slide the feed roller pin. Paper feed roller unit 5. Push the lever B and then remove the paper feed roller unit and pickup spring. 6. Check or replace the paper feed roller Lever B unit and refit all the removed parts.
3M9/3NA 1-4-3 PWBs (1) Detaching and refitting the PF main PWB Procedure 1. Remove the cassette. 2. Turn the paper feeder with the bottom side up. 3. Release two hooks and then top cover. Hook 4. Remove the actuator and spring. Hook Top cover Spring...
Page 40
3M9/3NA 6. Remove the screw. Screw 7. Release four hooks and then remove the PFmain PWB. PF main PWB Hook Hook Hook Hook Figure 1-4-10 1-4-7...
3M9/3NA 1-4-4 Warm air blowing section (Multi purpose feeder only) (1) Detaching and refitting the PF heater PWB Procedure 1. Remove the cassette. 2. Remove two screws. 3. Insert a flat-blade screwdriver into the cutout and release two hooks. Hole Hole Hook Hook...
Page 42
3M9/3NA 6. Remove seven connectors from PF heater PWB. PF heater PWB Figure 1-4-13 7. Remove the screw. 8. Release two hooks and then remove Screw the PF heater PWB. PF heater PWB Hook Hook Figure 1-4-14 1-4-9...
3M9/3NA (2) Detaching and refitting the top heater unit Procedure 1. Remove the fan cover (see page 1-4-8). 2. Remove six connectors from PF heater PWB. 3. Remove the connector of the PF fan motor 1. 4. Remove the connector of the PF therm- istor 1.
3M9/3NA (3) Detaching and refitting the side heater unit Procedure 1. Remove the top heater unit (see page 1-4-10). 2. Release two hooks and then remove the top cover. Hook 3. Remove the actuator and spring. Hook Top cover Spring Actuator Figure 1-4-17 4.
Page 45
3M9/3NA 5. Turn the paper feeder with the top side Screw 6. Remove four screws. Screw Screw Screw Figure 1-4-19 7. Turn the paper feeder with the bottom side up. 8. Release two hooks of the drive section Hook from the inside of the paper feeder. Hook Figure 1-4-20 1-4-12...
Page 46
3M9/3NA 9. Turn the paper feeder with the top side up and remove the top frame unit. Top frame unit Figure 1-4-21 10. Remove the side heater unit. Side heater unit Figure 1-4-22 1-4-13...
Page 47
3M9/3NA This page is intentionally left blank. 1-4-14...
3M9/3NA 2-1 Mechanical Construction 2-1-1 Paper feed section (1) Paper feed section The paper feeder conveys paper from the cassette to the machine. Cassette can hold up to 500 sheets of plain paper (80 g/m ). Paper is fed from the paper feeder by the rotation of the pickup roller and paper feed roller.
3M9/3NA (2) Warm air blowing section (Multi purpose feeder only) PF fan motor 1 in the top heater unit blows warm air into the cassette to dehumidity the whole paper, and PF fan motor 2 in the side heater unit blows warm air from near the leading edge of the paper to assist separation of paper.
3M9/3NA 2-2 Electrical Parts Layout 2-2-1 Electrical parts layout (1) Paper feeder (Normal) Machine right Machine inside Machine left Figure 2-2-1 1. PF main PWB (PFMPWB) ....Controls electrical components in the paper feeder and serial communications with the machine. 2.
3M9/3NA (2) Multi purpose feeder Machine right Machine inside Machine left Figure 2-2-2 1. PF main PWB (PFMPWB) ....Controls electrical components in the paper feeder and serial communications with the machine. 2. PF paper sensor 1 (PFPS1)....Detects the presence of paper in the cassette. 3.
3M9/3NA 2-3 Operation of the PWBs 2-3-1 PF main PWB YC111 YC10 Figure 2-3-1 PF main PWB silk-screen diagram 2-3-1...
Page 53
3M9/3NA Connector Signal Voltage Description +3.3V 3.3 V DC 3.3 V DC power source Connected to Ground PF feed sen- DC0V/3.3V PFFS: On/Off PAPSIZE0 0/3.3 V DC PFCSSW: On/Off Connected to PAPSIZE1 0/3.3 V DC PFCSSW: On/Off cassette size Ground switch PAPSIZE2 0/3.3 V DC...
Page 54
3M9/3NA Connector Signal Voltage Description TMDIR 0/3.3 V DC PFPFM control signal Connected to TMLOCK 0/3.3 V DC PFPFM lock signal PF paper TMCLK 0/3.3 V DC (pulse) PFPFM clock signal feed motor #TMDRY 0/3.3 V DC PFPFM: On/Off Ground +24V 24 V DC 24 V DC power source...
Page 56
3M9/3NA Connector Signal Voltage Description LIVE 120 V AC AC power output 220-240 V AC Connected to AC outlet NEUTRAL 120 V AC AC power output 220-240 V AC Connected to AC outlet LIVE 120 V AC AC power output 220-240 V AC Connected to N.C.
Page 57
3M9/3NA This page is intentionally left blank. 2-3-6...
Page 58
3M9/3NA 2-4 Appendixes 2-4-1 Appendixes (1) Wiring diagram PFPFM Paper feeder I/F Engine I/F PFCSSW PFFS PFLM PFMPWB PFPS1 PFPS2 PFLS YC114 YC115 YC113 YC111 YC10 YC14 PFRCSW PFPFCL PFPCCL PFFM1 PFFM2 Multi purpose feeder only. LIVE AC inlet NEUTRAL LIVE AC outlet PFHPWB...
Page 59
3M9/3NA This page is intentionally left blank. 2-4-2...
