Technical Bulletin

TB 01 / Note for the toner installation error

OPIC

Following error message may appear when installing the new toner container. This may be corrected as below.

ESSAGE DISPLAYED

MFP :

"The toner container is improperly installed"

ORRECTIVE ACTION

Once take out the toner container from the machine. Rotate

the coupling at the right side of the toner container clockwise

to eliminate the gap between the hook of the coupling and the

latch. Then, reinstall it in the machine.

Error message may appear

Enlarged view of section

Hook of coupling

Classification:

Field Measure:

Serial Nos.:

Eliminate the gap

Latch

Entire Stock Rework

In-Field modification at next visit

In-Field modification by case

No modification necessary

Please check the above and act correctively.

n/a

UTAX

Printer :

"Check the toner container"

Coupling

CLP 3721

CLP 3726

CLP 4721

CLP 4726

Toner container

Coupling

Rotate the coupling CW

to eliminate the gap

2KW-B081/M

Date: 18-03-2011

1/1

Need help?

Do you have a question about the CLP 3721 and is the answer not in the manual?

Questions and answers

Summary of Contents for Utax CLP 3721

Page 1 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 01 / Note for the toner installation error 2KW-B081/M Date: 18-03-2011 OPIC Following error message may appear when installing the new toner container. This may be corrected as below.
Page 2 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 02 / Firmware Upgrade (MAIN 02.005 / ENG. 03.003) 2KV-B085/M Date: 18-04-2011 OPIC The firmware is upgraded as follows. ONTENT OF CHANGES  Garbled characters. Characters in the maintenance report may be garbled. - Therefore, this is corrected.
Page 3 Big 5 font may not be printed out. - Therefore, this is corrected.  Measure against garbled characters with a certain file containing PJL. FIRMWARE Program No. Ver. Remarks 002.005 (CLP 3721, CLP 3726 / 4721, 4726) 2KV_3F00.002.005 MAIN 003.003 (CLP 3721 / 4721) 2KT_1000.003.003...
Page 4 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 03 / Colour background after setup NPresson/M Date: 17-05-2011 OPIC Colour background after setup. Sample ORRECTIVE ACTION Check the contact springs of the drum units. 1 Open the top cover and 2 Slide the container guide and 3 Open the RFID holder.
Page 5 7 Remove the developing units. 8 Remove the right cover and the >HIGH VOLTAGE PWB<. HIGH VOLTAGE PWB 9 Check the resistor from the drum contacts. Figure  right side CYAN MAGENTA BLACK YELLOW right side Ω Ω Ω Ω Figure ...
Page 6 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: Please check the above and act correctively. Serial Nos.:...
Page 7 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 04 / Corrective measures for C0150 error with… 2KT-B120/M Date: 30-05-2011 OPIC C0150 error may appear with the wire (EXIT-ENGN) pinched by the rib on COVER TOP P. Therefore, the following are changed.
Page 8 Please take good care when attaching the clamp to avoid the wire pinch when attaching COVER TOP P.   Serial Nos.: CLP 3721 - CLP 4721 From available timing in April 2011 production on. CLP 3726 - CLP 4726 ...
Page 9 A band image is formed in between the color calibration and color registration adjustment. Therefore, this is corrected.  Drum refresh mode supported FIRMWARE Program No. Ver. Remarks 2KV_3F00.002.005 002.005 (all) CLP 3721, CLP 3726 / CLP 4721, CLP 4726 MAIN 2KT_1000.004.003 004.003 only CLP 3721 / CLP 4721 ENGINE 004.003 only CLP 3726 / CLP 4726 2KV_1000.004.003...
Page 10 Please replace with the new type unit when the problem arises. Please upgrade the engine firmware together with replacing with the new unit.   Serial Nos.: CLP 3721 - CLP 4721 From available timing in June 2011 production. CLP 3726 - CLP 4726 ...
Page 11 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 06 / Correcting Parts List - >HOOK DU RELEASE< 2KW-B234/M Date: 02-08-2011 OPIC The parts number of the HOOK DU RELEASE (No.1) is registered. FIG. 5 PAPER CONVEYING SECTION...
Page 12 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 07 / Note when adjusting the color registration 2KW-B326/M Date: 11-10-2011 OPIC Please perform the following when adjusting the color registration. When the color registration shift appears: Perform [Calibration] (auto adjustment) Manually adjust the color registration if [Calibration] (auto adjustment) cannot correct it.
Page 13 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 08 / Correcting Parts List - Dev. Release Motor etc. Pers-Hor/M Date: 26-10-2011 OPIC The part numbers of the developing release section are registered. Q’ty Compatibility Old Part...
Page 14 2 hours or more at high temperature and high humidity.  Therefore, preventive control for the white streaks is implemented.  FIRMWARE Program No. Ver. Remarks 2KV_3F00.002.005 002.005 (CLP 3721, CLP 3726 / 4721, 4726) MAIN 2KT_1000.006.002 006.002 (CLP 3721 / 4721) ENGINE 006.002...
Page 15 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 10 / Correcting Parts List - >DUCT… + HINGE LID< 2KT-B380/M Date: 27-03-2012 Rev.1  HINGE LID L OPIC The following parts are set up for the service parts for an individual supply.
Page 16 Q’ty Compatibility Old Part New Part Description Remarks Old New 2KV02250 DUCT LEFT INNER 2KV02542 HINGE LID R (right side) 2KV02532 HINGE LID L (left side) Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: Please order the parts according to the necessity.
Page 17 The firmware is upgraded as follows. ONTENT OF CHANGES  UTAX/TA model name support. The TA/UTAX model names are indicated on the report pages.  Performance improvement. Printing a certain PDF file is slow. - Therefore, this is corrected. ...
Page 18   Corrective measures for the PCL-XL error. The PCL-XL error occurs when printing a certain PDF file. - Therefore, this is corrected.   Corrective measures for the XPS error. The XPS error occurs when printing a certain PDF file using the XPS driver. - Therefore, this is corrected. ...
Page 19  FIRMWARE Program No. Ver. Remarks 2KV_3F00.003.007 003.007 (CLP 3721, CLP 3726 / 4721, 4726) MAIN 2KT_1000.006.002 006.002 (CLP 3721 / 4721) ENGINE 006.002 (CLP 3726 / 4726) 2KV_1000.006.002 ENGINE Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case...
Page 20 Type Program No. Remarks 2KV_3F00.003.007 MAIN 2KT_1000.007.004 ENGINE  CLP 3721 / CLP 4721 2KV_1000.007.004 ENGINE  CLP 3726 / CLP 4726 IRMWARE UPGRADE PROCEDURES Fig-1 Note: The engine firmware consists of (1) adjustment firmware and (2) upgrade firmware. Prepare 2 pcs. of USB memory.
Page 21 For the machine with this version firmware or later or once the adjustment firmware is applied, no further executing the adjustment firmware is required.   Serial Nos.: CLP 3721 / CLP 4721 Planned in April 2012 production CLP 3726 / CLP 4726 ...
Page 22 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 13 / PF 520, PF 530 - Correcting Parts List >SPRING..< Beh/M Date: 05-09-2012 OPIC The parts numbers of the SPRING MID IDLE and STOPPER SPRING FEED are registered.
Page 23 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 14 / Firmware Upgrade (V 4.00) 2KT-C335/M Date: 15-01-2013 OPIC The firmware is upgraded as follows. ONTENT OF CHANGES  Corrective measures for the system error (CF248).
Page 24 This is corrected because the font may not be partly printed when printing from SAP-Forms.   FIRMWARE UPGRADE PACK V 4.00 Type Program No. Remarks 2KV_3F00.004.012 MAIN  NEW CLP 3721 / CLP 4721 2KT_1000.008.002 ENGINE  NEW CLP 3726 / CLP 4726 2KV_1000.008.002 ENGINE  NEW 2KV_81BR.001.010 LANGUAGE...
Page 25 In-Field modification by case No modification necessary Please upgrade the firmware to the latest version when the phenomenon occurs. Field Measure:   CLP 3721 / CLP 4721  Q862X02948 Serial Nos.: CLP 3726 / CLP 4726  Q872X04828 ...
Page 26 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 15 / Display message “Close rear cover 1” 2KT-C238/M Date: 18-02-2013 OPIC In rare case, the message “The cover is opened” is displayed by misdetection of REAR COVER opening when slowly closing TOP COVER while REAR COVER is closed.
Page 27 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 16 / Change for the toner container shutter 2KT-C238/M Date: 19-02-2013 HENOMENON The operation fully opening the top tray is tough. And so, HINGE LID R/L at the fulcrum parts of the top tray may be damaged in rare case if pushing up the top tray forcibly to fully open it.
Page 28 Toner container right guide (Below is the side contacting the right frame.) HINGE LID R (2KV02542) RATCHET SHUTTER Part, switching the toner container shutter, in the machine Joint X at the machine side (Toner container side) (Below fits the thrust spring) HOLDER JOINT Added the rib for distinction...
Page 29 Q’ty Compatibility Old Part New Part Description Remarks Old New ------------ 2KV02501 RATCHET SHUTTER ------------ 2KV02510 HOLDER JOINT *1: Only the new parts are set as service parts according to this change. *2: HOLDER JOINT is set as service parts while it remains unchanged this time because it may be replaced with the new parts depending on its dirty level when replacing RATCHET (No.1) at field.
Page 30  FIRMWARE UPGRADE PACK V 4.01N Type File Remarks MAIN 2KV_3F00.004.002  NEW ENGINE CLP 3721 / CLP 4721 2KT_1000.009.001  NEW ENGINE CLP 3726 / CLP 4726 2KV_1000.009.001  LANGUAGE 2KV_81BR.001.010 When upgrading firmware or replacing board etc., please upgrade each firmware to the latest version at the same time.
Page 31 TB 18 / Paper feed jam at the 250-sheet cassette 2KT-D027/M Date: 06-03-2013 Only  CLP 3721 / CLP 4721 OPIC Depending on the backlash to the cassette length direction, the 250-sheet cassette is incompletely inserted into the machine but the cassette feed drive can be driven (The bottom plate is lifted up when feeding the paper from the cassette).
Page 32 AY TO ATTACH THE NEW PARTS Remove the cassette. Release 4 hooks indicated with the triangle 250-sheet cassette engravings and remove the cover from the cassette right rear side. Hook Hook Cover Hook Hook Release 2 hooks and remove the bottom plate Hook from the side of the hooks.
Page 33 Pull out the shaft and remove the old STOPPER HOOK. Cassette rear side Shaft Old STOPPER HOOK Attach SPRING STOPPER HOOK (No.2) to the new STOPPER HOOK (No.1). Added No.2. SPRING STOPPER HOOK At that time, put the edge of SPRING (hooking shape) on the bottom side of the new STOPPER.
Page 34 Reinsert the shaft removed at Step 5 and fix the new STOPPER HOOK ASSY. Note the following 3 points when reinserting the shaft. 1.) Confirm the gear attached to the shaft’s right edge and the bottom plate drive gear engage. Bottom plate drive gear Gear 2.) Pass the shaft over the ground spring.
Page 35 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: When the above phenomenon occurs, please fit the new STOPPER HOOK (No.1) and SPRING (No.2) to the cassette. (Please refer to page 2~4 for the fitting procedures.) ...
Page 36 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 19 / Toner supply failure… 2KT-D022/M Date: 07-03-2013 OPIC When the joint (X) at the machine left side insufficiently engages the joint (Y) at the toner container due to dimensional variation of the parts or the assembly, the machine drive may not be transmitted to the toner container and the toner supply may fail.
Page 37 Machine left side Machine left inner side Toner container left side Joint (X) Joint (Y) Hole of the toner container left guide that inserts the joint Toner motor holder (Attached to outside of the left frame) Parts motion when the top tray is opened and closed - Top tray open: CAM TONER SUPPLY thrusts the joint (X) in the disengaging direction indicated in page 1.
Page 38 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: Please replace with the new CAM TONER SUPPLY (4 pcs of No.1) when the above phenomenon occurs.   Serial Nos.: 1626L / DCC 2726L No production...
Page 39 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 20 / Modification Parts Information… 2KT-D012/M Date: 14-05-2013 OPIC Part number information. ONTENT OF CHANGES Set up the modification parts as a Kit. GEMINI MODIFIKATION KIT - 870LCKIT2KV120 (Set)
Page 40 CASE SPACER: Corrective measures for abnormal image. Insert the T-shape of CASE SPACER into the And then, secure CASE SPACER by putting the rib at the aperture of the guide behind the high voltage bottom of CASE SPACER on the groove of the aperture. board aslant so that the X side of the T-shape first is inserted.
Page 41 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 21 / The color registration drift due to coming off… 2KW-D096/M Date: 28-05-2013 OPIC Please note the following when detaching the Bk drum unit because the ID sensor shutter may come off depending on the way to detach the Bk drum unit (Note 1).
Page 42 2nd page of the maintenance report for MFP 2nd page of the service status page for Printer 1st and 2nd digits of the rightmost column of the 15th lines from top 1st and 2nd digits of the 5th groups from left of the 7th lines from b tt Classification:...
Page 43 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB 22 / GEMINI Modification Kit - Serial Numbers Mey/M Date: 25-07-2013 OPIC Service information for the serial numbers of the Technical Bulletin TB-20. Please replace the parts when a problem arises.
Page 44 A) CDC 1626, CDC 1726, CDC 5526L, CDC 5626L / DCC 2626, DCC 2726, DCC 6526L, DCC 6626L (Page 4/7) B) CDC 5526, CDC 5626 / DCC 6526, DCC 6626 (Page 5/7) C) CLP 3721, CLP 3726 / CLP 4721, CLP 4726 (Page 6/7) ...
Page 45 Press down the ID sensor shutter (X in the figure below) inside the BK drum unit by hand, and correct the ID sensor shutter dislocation or come-off. After that, close and open the top tray at the state of closing the RFID holder to check if the ID sensor shutter can be slide horizontally.
Page 46  2KW_1000_CF5.001 File CDC 5526L, CDC 5626L / DCC 6526L, DCC 6626L Download  CDC5526L_CDC5626L_ResetFirmware_FW20120613 or newer  2KW_1000_CF5.001 File CLP 3721 / CLP 4721 Download  CLP3721_ResetFirmware_FW20120613  2KT_1000_CF5.001 File CLP 3726 / CLP 4726 Download  CLP3726_ResetFirmware_FW20130613  KV_1000.CF5.001 File Attention! Prepare two USB sticks (one for the Reset FW and one for the Firmware Upgrade Pack) to execute.
Page 47 Step 3 - Color Registration Adjustment- A) CDC 1626, CDC 1726, CDC 5526L, CDC 5626L / DCC 2626, DCC 2726, DCC 6526L, DCC 6626L Following procedures are the same contents as [Color Registration Procedure (Detailed Setting) in Operation Guide. 1. In the , press the key to select (Fig.3)
Page 48 Step 3 - Color Registration Adjustment- B) CDC 5526, CDC 5626 / DCC 6526, DCC 6626 1. Press key to display the . (Fig.11-1) System Menu/Counter System Menu/Counter menu 2. Press the key to select . (Fig.11-2) Upward Downward Adjustment/Maintenance 3.
Page 49 Start 15. Press after color registration is complete. (Fig.15) (Fig.16) (Fig.17) Step 3 - Color Registration Adjustment- C) CLP 3721, CLP 3726 / CLP 4721, CLP 4726 1. Press MENU 2. Press the key repeatedly until appears. Upward Downward Adjust/Maintenance...
Page 50 14. Press the key repeatedly until appears. Upward Downward M 12345 3 15. Press . 00000 or 0 will be displayed for each value and the cursor (_) will flash under the H value. (Fig.22) 16. In the color registration correction chart printed in Print Registration Chart above, note the numbers of the sections in the magenta H and V charts where the lines most closely coincide as a single straight line.
Page 51 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB-24C 2KW-E091r1/M Date: 24-06-2014 …A  highest priority / …B  second priority / …C  other / …S Service Information Priority: Corrective measures for the MP feed clutch motion error (J0509)
Page 52 Cover the upper divided unit onto the lower Hook Fig.3 divided unit and secure them by four hooks. At that time, adjust the clutch's direction so that the terminals of each clutch fit into the hole of the upper divided unit. (Fig.3) Hook Terminal...
Page 53 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case No modification necessary Field Measure: When the above phenomenon occurs, check if the MP feed clutch normally rotates with feeding papers from the MP tray without the left cover of the main unit. Replace with new part (No.2) when the MP feed clutch does not rotate.
Page 54 Thus, this is corrected. The above wrong state is also cleared only by turning the main switch off and on, but not cleared by detaching and reinstalling the waste toner box or replacing with the new one. FIRMWARE Type Program No. Remarks MAIN 2KV_3F00.005.003  CLP 3721 / CLP 4721 ENGINE 2KT_1000.010.001  CLP 3726 / CLP 4726 ENGINE 2KV_1000.010.001 LANGUAGE 2KV_81BR.001.010 When upgrading firmware or replacing board etc., please upgrade each firmware to the usable latest version at the same time.
Page 55 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB-26S 2KW-F012/M Date: 18-02-2015 …A  highest priority / …B  second priority / …C  other / …S Service Information Priority: Corrective measures for dog-ear at the second side of duplex print...
Page 56 ONTENT OF HANGES (Machine rear side without the rear cover unit and the paper conveying unit.) Middle roller (pulleys pressing paper) Chamfer of Chamfer of the rib (X) the rib (X) Left duplex sheet (Bundled in No.1) Right duplex sheet (Bundled in No.1) Affix the above duplex sheets to the lower parts than where the paper's corners at the machine left and right sides pass through the middle roller.
Page 57 ROCEDURES TO AFFIX THE DUPLEX SHEETS 1) Open the rear cover and remove the right and left straps. Rear cover Strap Strap 2) Detach the rear cover unit. Rear cover unit 3) Make the paper conveying unit horizontal and detach it. Paper conveying unit...
Page 58 4) Clean with alcohol the ranges between the Below is the state with the left and right duplex sheets. second rib and third rib from both horizontal ends of the cassette guide. Cassette guide 5) Affix the left and right duplex sheets that are Below is where the right duplex guide is affixed.
Page 59 Classification: Entire Stock Rework In-Field modification at next visit In-Field modification by case Information only No modification necessary Field Measure: When the above phenomenon arises, affix the duplex sheets in the duplex sheet kit (No.1).   Serial Nos.: 1626L 2626L 1726L 2736L...
Page 60 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB-27C A4CL-F036/M Date: 07-04-2015 …A  highest priority / …B  second priority / …C  other / …S Service Information Priority: Parts number information >RELAY PWB< OPIC The relay PWB (No.1) is registered as the service part.
Page 61 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB-28S COM-F150/M Date: 04-11-2015 …A  highest priority / …B  second priority / …C  other / …S Service Information Priority: Notes when assembling the parts (Bottom plate driving gear) OPIC Prevention of the service call error C1010 due to the wrong attachment of the bottom plate driving gear.
Page 62 Item A for CDC 1626, CDC 1726, CDC 5526, CDC 5626, CDC 5526L, CDC 5626L DCC 2626, DCC 2726, DCC 6526, DCC 6626, DCC 6526L, DCC 6626L 260ci, 261ci, P-C2660MFP, P-C2665MFP, P-C2660iMFP, P-C2665iMFP CLP 3721, CLP 3726 / CLP 4721, CLP 4726 P-C2160DN, P-C2660DN Applicable parts  GEAR Z41S (302KV02B70) Change-2: A rib is applied to a part of the gear holder where it is near gear X.
Page 63 / DCC 2726 CDC 5526 / DCC 6526 CDC 5626 / DCC 6626 CDC 5526L / DCC 6526L CDC 5626L / DCC 6626L CLP 3721 / CLP 4721 CLP 3726 / CLP 4726 260ci 261ci P-C2660MFP Service information only P-C2665MFP...
Page 64 Part Number Info. >GUIDE EXIT / DRUM RELAY PWB / RELAY PWB< Model: CDC 1626, CDC 1726, CDC 5526, CDC 5526L, CDC 5626, CDC 5626L, CLP 3721, CLP 3726 DCC 2626, DCC 2726, DCC 6526, DCC 6526L, DCC 6626, DCC 6626L, CLP 4721, CLP 4726...
Page 65 / DCC 2726 CDC 5526 / DCC 6526 CDC 5626 / DCC 6626 CDC 5526L / DCC 6526L CDC 5626L / DCC 6626L CLP 3721 / CLP 4721 CLP 3726 / CLP 4726 Service information only 260ci 261ci P-C2660MFP P-C2665MFP...
Page 66 Technical Bulletin UTAX CLP 3721 UTAX CLP 3726 CLP 4721 CLP 4726 TB-30S 2KT-I132/M Date: 16-07-2018 …A  highest priority / …B  second priority / …C  other / …S Service Information Priority: Parts list correction (Correct the part number of HOLDER GEAR)
Page 67 CDC 1626, CDC 1726, CDC 5526, CDC 5526L, CDC 5626, CDC 5626L / DCC 2626, DCC 2726, DCC 6526, DCC 6526L, DCC 6626, DCC 6626L P-C2160DN, P-C2660DN, P-C3061DN, P-C3062DN, P-C3560DN, P-C3562DN, P-C4070DN, P-C4072DN CLP 3721, CLP 3726 / CLP 4721, CLP 4726 Rev.1  Permanent measures / new models listed If the following information of the operation failure is provided in the field when cleaning or replacing the feed roller unit, there might be the possibility that the pickup spring comes off when attaching/detaching the feed roller unit.
Page 68 HE WAY TO ATTACH THE NEW OLD PICKUP SPRING The way to attach the new pickup spring (New No.3) Arrow view C Step Hook the B section of the new pickup spring (New No.3) to the step of the paper feed holder. The way to attach the old pickup spring (Old No.3) Insert the pickup spring into the cross-shape boss of the feeding holder and press the spring until the edge of the spring contacts the surface (X) of the feeding holder.
Page 69 P-C2660DN  No production P-C3061DN  No production P-C3062DN  RCE8Y00986 P-C3560DN  No production P-C3562DN  RCJ8Z01093 P-C4070DN  No production P-C4072DN  RCP8Y00716 CLP 4721  CLP 3721 - No production CLP 4726  CLP 3726 - No production...
