Left speaker system
Allowable Example 1
6 Ω
6 Ω
6 Ω
6 Ω
R
L
R
L
(Speaker terminals)
OK: Combined impedance is 12 Ω
Not-allowable Example 1
6 Ω 6 Ω 6 Ω
6 Ω
R
L
R
L
(Speaker terminals)
NG: Combined impedance is 3 Ω
CSX-580(SE)
Connected amplifier
(Speaker terminals)
L
R
Allowable Examples
Allowable Example 2
Allowable Example 3
8 Ω
6 Ω
6 Ω
8 Ω
8 Ω
R
L
R
L
(Speaker terminals)
OK: Combined impedance is 14 Ω OK: Combined impedance is 16 Ω
Not-allowable Examples
Not-allowable Example 2
Not-allowable Example 3
8 Ω
6 Ω 6 Ω
8 Ω
8 Ω 8 Ω 8 Ω 8 Ω
R
L
R
L
(Speaker terminals)
NG: Combined impedance is 3.4 Ω
NG: Combined impedance is 4 Ω
SPEAKER SYSTEM
Right speaker system
8 Ω
8 Ω
8 Ω
R
L
R
L
(Speaker terminals)
R
L
R
L
(Speaker terminals)
Advertisement
Related Manuals for BMB CSX-580(SE)
Summary of Contents for BMB CSX-580(SE)
- Page 1 SPEAKER SYSTEM CSX-580(SE) Left speaker system Connected amplifier Right speaker system (Speaker terminals) Allowable Examples Allowable Example 1 Allowable Example 2 Allowable Example 3 6 Ω 6 Ω 6 Ω 6 Ω 8 Ω 6 Ω 6 Ω 8 Ω 8 Ω...
- Page 2 Squawkers for midrange/high tone Tweeter for high pitch sound Tweeter for high pitch sound Left speaker Right speaker Woofers for deep bass Standard speaker layout Left speaker Safety catch for lock Remove these four screws. squawker unit Pull the duct hole with a hand.
- Page 3 English OWNER’S MANUAL THANK YOU VERY MUCH FOR PURCHASING THIS BMB SPEAKERS SYSTEM. BEFORE USE, PLEASE READ FOLLOWING INSTRUCTIONS THROUGH CAREFULLY AND FAMILIARIZE YOURSELF WITH THE OPERATION OF THE SYSTEM. BEFORE USE Operating Precautions The maximum input power of these speakers is 400 W (at peak). Higher levels of input power may cause damage to the speaker system and so take every precaution to keep the power down to the specifi...
- Page 4 8 cm Cone Type Tweeter x 1 High-performance oven cone Maximum input power: 400 W Sound pressure level: 90 dB/W/m Frequency response: 45 - 20 kHz Impedance: 8 Ω Dimensions: 464 (W) x 268 (H) x 257 (D) mm Mass: 9.0 kg http://www.bmb.com...
