- Page 1 SPEAKER SYSTEM CSN-255E Left speaker system Connected amplifier Right speaker system (Speaker terminals) STRAIGHT AHEAD FROM THE TWEETER (Hz) IMPEDANCE (Hz)
- Page 2 Allowable Examples Allowable Example 1 Allowable Example 2 Allowable Example 3 6 Ω 6 Ω 6 Ω 6 Ω 8 Ω 6 Ω 6 Ω 8 Ω 8 Ω 8 Ω 8 Ω 8 Ω (Speaker terminals) (Speaker terminals) (Speaker terminals) OK: Combined impedance is 12 Ω...
- Page 3 Caution: If you want to suspend the CSN-255E from the ceiling, use adequate mounting hardware that can bear the load. In addition, be sure to secure the mounting hardware onto a place of high-tensile strength using screws appropriate to the ceiling materials.
- Page 4 8 cm Cone Type Tweeter x 2 Maximum input power: 300 W Sound pressure level: 90 dB/W/m Frequency response: 45 - 20 kHz Impedance: 8 Ω Dimensions: 458 (W) x 270 (H) x 251 (D) mm Mass: 7.8 kg http://www.bmb.com...
