Dynabrade Dynafile III Assembly

Models:
15300 – Basic Tool
15302 – Versatility Kit
WARNING
!
1
Contact Arm Assembly
For more information on Contact
Arm Assemblies please refer to
chart on page 3.
4
2
5
A
3
T
3.0 N•m
3
Index Key
No. Part # Description
1 15350 Contact Arm Assy.
2 96334 Plug
3 15308 Guide Post
4 11040 Spring
5 15306 Tension Arm
6 95218 Knob Assy.
7 95426 Spring
8 15307 Tension Shaft
9 15309 Dust Cover
10 95217 Screw
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air
tools (ANSI B186.1) and any other applicable safety codes and regulations. Please refer to
Dynabrade ' s Warning/Safety Operating Instructions for more complete safety information.
15300 Tool Assembly
15
11
G
7
2
8
G
6
2
11 15305 Housing
12 96335 Hex Nut
13 15310 Guard
14 15329 Screw
15 15312 Guard Assy.
16 53163 Handle Assy.
17 95311 Screw (2)
18 40029 Motor Lock (2)
19 15338 Handle Support
20 15331 Motor Assy.
Note: Shaded parts represent 15313 Head Assembly.
14
13
12
18
9
A
10
T
3.0 N•m
3
G
2
20
Parts Page Reorder No. PD00•08
Effective January, 2000
Supercedes PD99•28
Dynafile
Air Motor and Machine Parts
Oil: O Air Lube
1 =
O
Adhesive: A = Loctite #242
A
3
Grease: G = Loctite #771
G
2
Torque: N•m x 8.85 = In. - lbs.
T
III
®
16
G
17
2
19
G
17
2
18
O
1
KEY
