- Page 1 TM-200 UHF Dual Channel True Diversity Wireless Microphone Installation and Operation...
-
Page 2: Table Of Contents
Contents 01 Safety Operation and Notice ..................... Thank you for choosing a RELACART professional wireless microphone system. You have 02 System Performance Feature ....................joined thousands of other satisfied customers. Our years of professional experience of 03 Receiver Installation Method .................... -
Page 3: Safety Operation And Notice
· Can match T-1H handheld microphone, ET-50 bodypack transmitter, UD-2 desktop microphone. 21. All Relacart products will be afforded one year free maintenance except for man-made damage, such as: · Designed for use on karaoke, DJ, universities, houses of worship. Stable, easy to install, most• affordable —... -
Page 4: Receiver Installation Method
Receiver Installation Method Packing List Installation: Wireless microphone receiver *1 Wireless transmitter ① For better operation the receiver should be at least 3ft (1m). above the ground and at least 3ft (1m). BNC Antenna *2 away from a wall or metal surface to minimize reflections. External power adapter * 1 ②... -
Page 5: Receiver Front Panel Function Introduction
Receiver Front Panel Function Introduction “UP*/AFS” Manually set channel / AFS button: 1. Set the working channel manually, this button can change the channel totally 50 channels.(Go to channel 50, then start from channel 1, and stop pressing the button, the channel light flashes 3 times confirm this channel automatically). -
Page 6: Receiver Rear Panel Function Introduction
Receiver r Panel Function Introduction Transmitter Function Introduction Handheld microphone (T-1H) 5V/1A port: USB output 5V/1A port. Expansion port: for connecting external controlling box. RS-232 port: for connecting central control system. Anti-pull device: used to fix the connecting cable of the external power adapter. DC IN socket: connect to external power adapter. - Page 7 Bodypack transmitter (ET-50) Microphone Head: It is the important part to transfer sound into audio signal. The microphone head is separate to change other microphone head if needed. LCD display: display the frequency, channel, mute and battery life. Battery indicator displays a maximum of 4 bar segments.
- Page 8 Desktop gooseneck microphone (UD-2) Antenna For transmitting a bodypack Power toggle switch Toggle this switch to turn on or off power supply of the transmitter. AF/INS audio input selection switch: The transmitter can be connected with an audio input device (microphone or instrument connection cable) at the top part-the input socket.
- Page 9 Transmitter Battery Installation (T-1H) Power Button/Mute Button: Press the power button to turn on the transmitter, press the power button 1.5 second enter the mute status, press one more time to close the mute function. Long press 3 seconds to turn off the transmitter.
- Page 10 User-friendly steps 1. Press the power button to turn on the receiver, the display and the power indicator are all lit. (UD-2) 2. Manually set channel / auto search button: press, the channel light flashes for 3 seconds to automatically confirm. automatically search and lock on the undisturbed channel in the actual working environment.
- Page 11 The searched channel automatically calculates a clean and undisturbed frequency, indicating that the After the frequency of the transmitter and the receiver are synchronized, when speaking with the radio frequency signal of this channel is received. When the transmitter is on the same frequency as the microphone, it indicates that the audio signal from the transmitter of this channel is received.
- Page 12 Technical Specification Single-receiver Systems Setup: TM-200 Dual Channel Receiver ① Touch “UP1/ AFS” button to change the frequency manually. Or Press this button 3 seconds and the Main Frame Size : EIA standard 1U receiver will auto-scan and lock on to an open, interference-free frequency.
-
Page 13: Bodypack Transmitter (Et-50)
T-1H Handheld Microphone ET-50 Bodypack Transmitter Carrier Frequency Range: 521.25MHz ~ 936.85MHz Carrier Frequency Range: 521.25MHz ~ 936.85MHz Oscillation: PLL Synthesized PLL Synthesized Oscillation: RF Output Power: 10mW/30mW RF Output Power : 5mW/30mW Carrier Deviation: 0.5KHz Carrier Deviation: 0.5KHz Harmonic Radiation: <45dBm Harmonic Radiation: ≤45dB... -
Page 14: Desktop Gooseneck Microphone (Ud-2)
UD-2 Desktop Gooseneck Microphone Carrier Frequency Range: 521.25MHz ~ 936.85MHz PLL Synthesized Oscillation: RF Output Power: 10mW / 25mW Carrier Deviation 0.5KHz Harmonic Radiation: Modulation Mode 45KHz Gain Adjustment Range: 10dB ~ +10dB Frequency Set-Up IR Sync Battery AA x 2 Approximately 8 hours Dimensions (mm): Microphone base: 141 x 115 x 48...
