  • Page 1 EVI DC inverter heat pump for heating and cooling - split system (with Wi-Fi control) TECHNICAL PASPORT. INSTALLATION AND OPERATION MANUAL Version 0.2...
  • Page 2 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ GENERAL FEATURES: Dear clients, before using the device, 1. General Features familiarize yourself with this instruction for installation, storage and operation. 1. Low running costs and high efficiency We hope that the appliance you have ·A high coefficient of performance (COP) of up purchased will contribute to creating coziness to 5 results in lower running costs compared...

  • Page 3: Basic Instructions And Warnings

    INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 1. BASIC INSTRUCTIONS The power cable has a standard tip, which must be connected to a AND WARNINGS standard outlet (16A; 230V). The  outlet must have a separate power Before starting installation...

  • Page 4: Heat Pump Installation

    INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ prolonged period, then you might choose on the inlet and outlet water connections for to turn the heat pump off or decrease the ease of serviceability. temp. setting of the control several degrees to 3.2.
  • Page 5 (a) But if the copper pipe length is above 5m, the added refrigerant volume will be 60g/m for SUNSYSTEM SPLIT R32-0126- 1PH; 120g/m for SUNSYSTEM SPLIT R32-0220- 3PH. The max copper pipe length is 10meter for SUNSYSTEM SPLIT R32-0126-1PH, 15meter for SUNSYSTEM SPLIT R32-0220-3PH.

  • Page 6: Preparation For Installation

    INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 4. PREPARATION FOR INSTALLATION 4.1. Outdoor unit with 1 fan - components COMPONENTS А High pressure safety relay Air inlet temperature sensor High pressure side Schrader type valve Heat exchanger (evaporator) Compressor Electronic expansion valve Hot gas temperature sensor...
  • Page 7 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 4.2. Outdoor unit with 2 fans - components COMPONENTS А Compressor Heat exchanger (evaporator) Low pressure side Schrader type valve Air inlet temperature sensor Compressor 4-way diverter valve Low pressure compressor gas temperature sensor Low pressure sensor...
  • Page 8 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 4.3. Indoor unit - components SUNSYSTEM SPLIT R32-0126-1PH SUNSYSTEM SPLIT R32-0220-3PH COMPONENTS А Water inlet Safety valve Outlet water (DHW) Refrigerant R32 - Input Heating water outlet DN25 Refrigerant R32 - Outlet...

  • Page 9: Installation

    INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5. INSTALLATION 5.1. Outdoor unit with 1 fan - dimensions. SUNSYSTEM SPLIT R32-0126-1PH 1094 1049...
  • Page 10 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.2. Outdoor unit with 2 fans - dimensions. SUNSYSTEM SPLIT R32-0220-3PH 1056 1000 114.5...
  • Page 11 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.3. Indoor unit - dimensions. SUNSYSTEM SPLIT R32-0126-1PH SUNSYSTEM SPLIT R32-0220-3PH 75 74...
  • Page 12 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.4. Installation location. 5.5. Minimum distances during installation. 5.5.1. Minimum distances in mm for 1 Choose a place with good air outdoor unit with 1 and 2 fans:  circulation so that the cooled air can flow in and the warm air can flow out.
  • Page 13 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ в) Arrangement in a row: Air inlet Air inlet Air inlet Air inlet Air inlet > 500 > 500 > 500 > 500 > 500 > 500 Air outlet Air outlet Air outlet Air outlet...
  • Page 14 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ G/ Brackets for floor mounting; G/Designer cover with console; H/ Strip foundation; H/ Strip foundation; K/ Frost protection for the foundation K/ Frost protection for the foundation (compacted gravel, e.g. 0 to 32/56 mm), layer (compacted gravel, e.g.
  • Page 15 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ Do not close the openings.; H/ Strip foundation; G/ Brackets for floor mounting; K/ Frost protection for the foundation (compacted gravel, e.g. 0 to 32/56 mm), layer H/ Strip foundation;...
  • Page 16 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.6.2. Wall mounting. b) Wall mount with wall mount а) Wall mounting with a set of wall bracket kit and designer trim. mounting brackets. A/ Gravel layer for percolation of condensate; A/ Gravel layer for percolation of condensate; B/ Vibration isolation;...
  • Page 17 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.6.3. Installation of the indoor unit on a wall: 5.7. Connecting the refrigerant piping. The installation room must be dry and а) Indoor unit above the outdoor protected from frost.
  • Page 18 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.7.1. Outdoor unit: Refrigerant piping 5.7.2. Indoor unit: Refrigerant piping connection. connection. C ) Pipeline for the liquid D) Piping for the hot gas Contamination moisture refrigerant piping  cause the device to malfunction.
  • Page 19 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.8. Drainage and Condensation - By setting the control panel, the operating Condensation will occur from the evaporator modes are set: in hot water mode, in heating when the unit is running and drain at a steady or cooling mode;...
  • Page 20 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.9.2. For hot water installation only. Safety valve EXTERNAL MODULE Hot water outlet INTERNAL Hot Water Tank MODULE Cool water inlet Diagram 4. Assembly diagram of a hot water installation 5.9.3.

  • Page 21: Electrical Connections

    INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 5.10.1. Plumbing Installation Requirements: 6.1. Power supply. 1. When water pressure exceeds 490Kpa, a). If the supply voltage is too low or please use reducing valve to reduce the water too high, it can cause damage and/or result in pressure below 294Kpa.
  • Page 22 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 6.3.. Electrical Wiring Diagram. 6.3.1. Single phase system (SUNSYSTEM SPLIT R32-0126-1PH). External body.
  • Page 23 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 6.3.2. Three phase system (SUNSYSTEM SPLIT R32-0220-3PH). External body.
  • Page 24 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 6.3.3. Inner body (SUNSYSTEM SPLIT R32-0126-1PH). Single phase system.

  • Page 25: Operation Of The Heat Pump

    INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 7. OPERATION OF THE HEAT PUMP 7.3. Definition of Buttons. 7.1. Controller panel. Buton Description Function When the heat pump is off, all buttons are On/Off turn on or turn off the heat gray, and when on and running, all buttons...
  • Page 26 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 7.4.3. Operate mode selection. Buton Function Description Status Check the running parameters of the heat pump Faulty Record the most recent error codes WiFi Wifi settings System Check and set the system parameters of the heat pump parameters Factory...
  • Page 27 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 7.4.7. Timer settings. In the main interface, press TIMER button to enter timing setting interface. -In the WEEK column, users can select which weekdays to perform timer switch.
  • Page 28 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 7.4.9. System parameters query & settings. Description Remark Press “SETTING” in the main interface to enter Water inlet temperature -30~99 setting interface, then press “SYSTEM Water outlet temperature -30~99 PARAMETERS”...
  • Page 29 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ Description Range Default Code Р01 Temperature difference of return water and cooling target 2~18 temperature Р02 Temperature difference of return water and hot target temperature 2~18 Р03 Hot water setting temperature...
  • Page 30 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ Description Range Default Code Celsius/Fahrenheit switch 0-Celsius / 1-Fahrenheit (0 is not enabled, Heating target temperature automatic Р22 1 is enabled) (only adjustment enable applicable at heating mode) Р23 Heating compensation temperature point 0-40 (ambient temperature)
  • Page 31 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 7.4.10. High Temperature Antisepsis Function: 7.4.12. Auxiliary Electric Heater for Water (when hot water function is selected). Tank. High temperature Antisepsis Start conditions (all below conditions must be cycle once every...

  • Page 32: General Operating Guide

    INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ Shut-down condition: heating running. 1) Under Cooling or Hot Water Refrain from using this heat pump if Mode; any electrical components have been  2) Without Heating Demand or in contact with water.

  • Page 33: General Maintenance

    INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 9.2.6. Safety Precautions: 10. GENERAL MAINTENANCE a) User can’t self-install the unit, ensure agent 10.1. Controller Error Codes. or specialized install company to do, or else maybe cause safety accident and affect the If there’s error in the heat pumps, the error use effect.
  • Page 34 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ Definition of Error or Protection Error Code Er 03 Water flow failure Er 04 Antifreeze in winter Er 05 High pressure fault Er 06 Low pressure fault Er 09 Communication failure Er 10 Communication failure of frequency conversion module...
  • Page 35 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ When there’s Er 20 error in the system, it will display below detailed error code from 1 to 348. Among them, 1~128 are in the first class, when will be displayed as priority, 257~384 are in the second class, which will be displayed only when error 1~128 don’t appear.
  • Page 36 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 10.2. Common Faults and Debugging Common Faults and Debugging Error Status Possible Reason Solution Power fault Put off the power switch, check the Wiring loose power supply find out the causes and repair Heat pump not Fuse blow fused...

  • Page 37: Wifi Connection And Operation

    INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 11. WIFI CONNECTION AND OPERATION WIFI Connect Method 2: intelligent network distribution mode: 11.1. APP Download. The 1st step: Please go to “Google Play Store” or “Apple By default, it can be connected within 10s App Store”...
  • Page 38 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ Remarks: When the wired controller’s WIFI module is connected to the WIFI hotspot, the AP mode add device interface, confirm that icon flashes fast. the AP network configuration mode is selected icon flashes), click "Next"...
  • Page 39 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 11.2. Software function operation. 11.2.1. Interface Introduction. Click "My house Heat Pump" in "All Devices" in After the device is successfully bound, enter the main interface of "Smart Life" APP to the "My house Heat Pump "...
  • Page 40 INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ Click "Work mode" on the main interface of temperature). the equipment operation to switch mode, and the mode selection interface will pop up as shown in the figure below, just click the mode you need to select.
  • Page 41 INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ 11.2.7. Timer settings. be started, then the electric heating will be started instead of the compressor after 5 In the Setting interface, click ”timing” to enter minutes.

  • Page 42: Technical Parameters

    TECHNICAL PARAMETERS Model: - SUNSYSTEM SPLIT SUNSYSTEM SPLIT INSTALLATION and OPERATION MANUAL ТЕХНИЧЕСКИ ПАСПОРТ. ИНСТРУКЦИЯ за МОНТАЖ и ЕКСПЛОАТАЦИЯ R32-0126-1PH R32-0220-3PH Nominal heating power Heating mode: ambient temperature +7 C/water (input - output) 30-35 Output heating power (kW) 6.5-12.6 10.5-22.0 4.21-4.62...
  • Page 43 INSTALLATION and OPERATION MANUAL...

  • Page 44: Table Of Contents

    CONTENT BASIC INSTRUCTIONS AND WARNINGS................3 HEAT PUMP ENERGY SAVING TIPS ..................3 HEAT PUMP INSTALLATION ....................4 PREPARATION FOR INSTALLATION ..................6 INSTALLATION ........................9 ELECTRICAL CONNECTIONS ....................21 OPERATION OF THE HEAT PUMP..................25 GENERAL OPERATING GUIDE .................... 32 USERS GUIDE ........................32 GENERAL MAINTENANCE....................33 WIFI CONNECTION AND OPERATION ................

This manual is also suitable for:

Split r32-0220-3ph
