imc ARGUSfit

Manual

imc Test & Measurement GmbH • Voltastr. 5 • 13355 Berlin • Germany

Edition 1 - 2023-07-10

Table of Contents

Need help?

Do you have a question about the imc ARGUSfit and is the answer not in the manual?

Questions and answers

Summary of Contents for Axiometrix Solutions imc ARGUSfit

Page 1 ARGUSfit Manual Edition 1 - 2023-07-10 © 2023 imc Test & Measurement GmbH imc Test & Measurement GmbH • Voltastr. 5 • 13355 Berlin • Germany...
Page 2 Monitor installation medium in the folder "Products\imc DEVICES\OSS" or "Products\imc DEVICEcore\OSS" or "Products\imc STUDIO\OSS". If you wish to receive a copy of the GPL sources used, please contact our Hotline. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 2...
Page 3 Notes denote useful additional information on a A reference in this document is a reference in particular topic. the text to another text passage. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 3...
Page 4: Table Of Contents
9 Pin configuration ..................... 68 9.1 Power ............................68 9.2 Remote ............................68 9.3 Base Unit ............................69 9.4 Measurement Modules ........................ 70 Index .......................... 72 © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 4...
Page 5: General Introduction
Please note that all properties described refer to a closed measurement system and not to its individual slices. Attach covers over the module connectors on the upper and lower sides. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 5...
Page 6 Products not satisfying these requirements may only be used with special approval of the regulating body in the country where operated. All lines connected to the imc ARGUSfit should not be longer than 30 m and they should be shielded and the shielding must be grounded.
Page 7 The FCC requires the user to be notified that any changes or modifications made to this product that are not expressly approved by imc may void the user's authority to operate this equipment. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 7...
Page 8: Explanation Of Symbols
The device itself does not generate dangerous voltages. DC, Direct Current Supply of the device via a DC voltage source (in the specified voltage range) © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 8...
Page 9 (This is guaranteed by the absence of named substances). Observe the documentation Read the documentation before starting work and/or operating. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 9...
Page 10: Safety
The user must also ensure that any personnel assisting in the use of the imc ARGUSfit have also read and understood the content of this document.
Page 11 Industrial safety We certify that imc ARGUSfit in all product configuration options corresponding to this documentation conforms to the directives in the accident prevention regulations in "Electric Installations and Industrial Equipment" (DGUV Regulation 3)*. This confirmation applies exclusively to devices of the imc ARGUS series, but not to all other components included in the scope of delivery.
Page 12 Before touching the device sockets and the lines connected to them, make sure static electricity is diverted to ground. Damage arising from electrostatic discharge is not covered by the warranty. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 12...
Page 13: Assembly And Connection
(forced ageing). The operating temperature data represent the extreme limits at which the function of all components can still be guaranteed. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 13...
Page 14: Notes On Connecting
In the following chapters we use the block representation of the modules and not the original photos to illustrate the application examples. Legend: imc ARGUSfit provides a complete integration of the imc CANSASfit module series (CANFT) for slower channels, e.g. for temperature measurement.
Page 15 5. Avoid prolonged exposure of the device to sunlight. Due to their function, the imc ARGUSfit modules, just like the CANSASfit modules, are open at the connection points (module connectors). This is not a problem when used in a controlled, dry environment. In order to...
Page 16 Chapter 3 3.3.2 Click mechanism imc ARGUSfit (ARGFT) modules and imc CANSASfit (CANFT) modules can be mechanically and electrically connected by a click-lock, without tools and without additional connecting cables. Before you start connecting the modules together, make sure that no supply voltage is connected.
Page 17 The modules are designed for blocks of max. 8 modules. · The CAN bus is only active on the left module, see the following figure: Fig. 5: Power supply of ARGFT and CANFT © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 17...
Page 18 3.3.4 Power supply An imc ARGUSfit system is operated by power that is to fed into the base unit via a socket compatible with LEMO.EGE.0B.302 on the base unit ("POWER"). Power is distributed to the rest of the system via the power backbone across the electrical click connectors between the modules.
Page 19 Notes on connecting Chapter 3 3.3.5 Fiber Converter The Fiber Converter is a clickable module for the modular imc ARGUSfit system. It allows decentralized distributed system topologies. The module converts the internal high-speed ARGUS system bus, which connects the ARGUS measurement amplifiers and interface modules via the click connector, to a fiber-optic data link in the sense of a media converter.
Page 20 "Output power" section "Output-side overcurrent protection" · if the UPS buffer duration has expired or the battery is completely discharged in battery mode. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 20...
Page 22 Whether the NiMH batteries are outside the temperature range for charging/discharging is indicated by the color of these LEDs. Fuse The UPS module is protected with a non-resettable 10 A fuse at the input. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 22...
Page 23 Internal error of the UPS, buffer operation may not be possible. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 23...
Page 24 Reference Pin configuration of the LEMO socket, see chapter "Remote" © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 24...
Page 25 The storage medium is full. If the PC is connected to the measuring device, imc STUDIO documents the error with a message in the Logbook © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 25...
Page 26 3.3.10.1.3 Known issues and limitations The file system becomes slower and slower. Creating more than 1000 folders is to be avoided, since this significantly slows down the file system. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 26...
Page 27 Record blue flashing blue flashing blue flashing blue flashing (measurement) 1 s 1 s 300 ms 150 ms Firmware magenta blue blue blue Update Error blue blue blue © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 27...
Page 28: Maintenance And Servicing
Damage arising from transporting is not covered in the manufacturer's guarantee. Possible damage due to condensation can be limited by wrapping the device in plastic sheeting. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 28...
Page 29: Start Of Operation Software / Firmware
Under some circumstances, this may require using switches to subdivide the network into separate segments in order to govern the data traffic in a targeted way and thus optimize the data rate. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 29...
Page 30: Connecting Via Lan In Three Steps
Subsequently, a prompt appears asking whether to search for devices with an inappropriately configured network interface. Close this message box by clicking "Yes". © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 30...
Page 31 DHCP, the alternative values are used. These could lead to errors in the connection (different networks, same IP addresses, etc.). © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 31...
Page 32: Firmware Update
1. Under no circumstances should the device or its power supply be deactivated during the firmware update! 2. The network connection may not be interrupted. Use a cable connection, not WLAN! © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 32...
Page 33 Nevertheless, with the new version of imc STUDIO, you are able to work with the device running the old firmware edition, if you choose. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 33...
Page 34: Properties
3 2000 via EtherCAT else 400 4 Number of imc STUDIO Monitor-connections or imc REMOTE (as of 14xxxx) connections 5 not available for imc BUSDAQ-2 6 not available for imc BUSDAQflex-2-S © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 34...
Page 35: Device Description
ARGUSfit – fast, compact and modular measurement systems imc ARGUSfit is a compact modular system that allows the user to flexibly assemble fast data acquisition systems (DAQ). Both the base unit and the flexibly combinable measuring modules have independent housings which are connected by a "click"...
Page 36 Multiple DAQ systems of the imc ARGUSfit series as well as other imc data logger and measurement systems can be interconnected via Ethernet. This allows to operate very large and multi-channel setups in which different imc device series work together uniformly and fully synchronized.
Page 37 For an overview of the accessories supplied as standard, please refer to the data sheet of the imc ARGUSfit module supplied. 6.2.3 Optional accessories For an overview of the available accessories, please refer to the data sheet of the imc ARGUSfit module supplied. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 37...
Page 38 This setting can be useful if maximum bandwidth reserves are to be used and there are known limitations on the measured signal's spectral distribution, which justify not performing consistent filtering. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 38...
Page 39 = -48 dB with fg_AAF (3 dB) = f_sample / 10 attenuation at Nyquist-freq.: 1/15630 = -84 dB · Characteristics: Butterworth, 8th order (48 dB/octave) © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 39...
Page 40: Measurement Modules
Reference · Technical Specs: UTI-6-SUP · Status LED codes: UTI-6-SUP · Pin configuration signal connection · UTI-6-SUP: Sensor supply (SUPPLY) 7.1.1 Voltage measurement UTI-6-SUP © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 40...
Page 41 UTI-6 Chapter 7 7.1.1.1 Voltage with bipolar power supply 7.1.1.2 Voltage with unipolar power supply UTI-6-SUP © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 41...
Page 42 25 mV per 1 mA, as shown in Fig. 1a and 1b. The current is powered by an external source with its own supply. In two-wire sensors, it is connected in series to the sensor, Fig. 1b. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 42...
Page 43 +SUPPLY and -SUPPLY according to Fig. 2b. For the setting of the supply voltage of ±12 V, for example, 24 V are available for the current loop. · Sensors with three-wire connection (bipolar supply) can supply signals of both polarity, see Fig. 3. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 43...
Page 44 5 kΩ 0.5 mA 2.5 kΩ 1 mA 1 kΩ 1.25 mA 500 Ω 1.25 mA 250 Ω 1.25 mA 100 Ω 1.5 mA © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 44...
Page 45 Accordingly, this also applies to sensors having only two connections. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 45...
Page 46 ΔT (PT100) [K] ΔT (PT1000) [K] -200 -0.03 -0.01 -0.05 -0.01 -0.13 -0.02 -0.24 -0.05 -0.52 Table: Measurement error for isolation resistance of 10 MΩ © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 46...
Page 47 In case of a short circuit, the module is fully protected. For a complete recovery, the module may have to be switched on again. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 47...
Page 48: Icpu-6
The use of ICP e.g. DeltaTron-sensors is supported by a 4 mA current source. The sensor information can be read directly from the sensor in accordance to the standard "TEDS - Transducer Electronic Data Sheets" IEEE 1451.4. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 48...
Page 50: Operating Conditions Of The Measurement Modules
ARGFT modules 60 W at 12 V DC typ. DC vehicle voltage 120 W at 24 V DC AC/DC power adaptor and installations © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 50...
Page 51: Base Unit - Technical Specs
3,6 W (typ.) @ 48 V DC Isolation 60 V against housing (CHASSIS) AC/DC power adaptor 110 V to 230 V AC external adaptor 24 V / 60 W included in delivery © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 51...
Page 52 UPS delay "buffer-time constant": required duration of a continuous outage that will trigger auto shutdown procedure fixed parameter: cannot be changed in the device configuration! © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 52...
Page 53 Number of event calculations analog: 1 per module fieldbus: 8 per module Number of events used 8 per trigger definition 64 used per device © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 53...
Page 54 RMS over block size R Minimum statistics over block size R Maximum Reduction factor R 2 .. 10.000.000 block size or resampling for the processing individually selectable functions © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 54...
Page 55 2 Statistical mean variation. Also dependent on signal quality with IRIG-B (e.g. direct connection to imc master device) respectively the specific network configuration with PTP (e.g. point-to-point connection via PTP-capable network switch such as imc NET-SWITCH-5). © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 55...
Page 56: Uti-6 - Technical Specs
(CHASSIS) and between functional units Analog input channels ±60 V analog input and sensor supply Channel-to-channel ±60 V Coupling Parameter Value Remarks Input coupling Input configuration isolated © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 56...
Page 57 Output power per channel 0.5 W bipolar supply with symmetric load 0.4 W unipolar supply or asymmetric load per module Output impedance 0.6 Ω © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 57...
Page 58 + 4 nA/K·ΔT ΔT -25°C|; with T = ambient temperature Bandwidth 0 Hz to 48 kHz -3 dB 0 Hz to 30 kHz 0.1 dB © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 58...
Page 59 Power supply options via adjacent module module connector (click mechanism) Please find here the description of the UTI-6 and technical specs of environmental conditions here © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 59...
Page 60: Icpu-6 - Technical Specs
Analog input channels ±60 V analog input and sensor supply Channel-to-channel ±60 V Coupling Parameter Value Remarks Input coupling DC, AC and IEPE Input configuration isolated © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 60...
Page 61 86 dB 98 dB 109 dB 100 mV 80 dB 92 dB 103 dB 50 mV 74 dB 86 dB 97 dB 25 mV © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 61...
Page 62 86 dB 98 dB 106 dB 100 mV 80 dB 92 dB 100 dB 50 mV 74 dB 86 dB 94 dB 25 mV © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 62...
Page 63 Power supply options via adjacent module module connector (click mechanism) Please find here the description of the ICPU-6 and technical specs of environmental conditions here © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 63...
Page 64: Expansions
Remarks Max. current 60 W at 12 V DC typ. DC vehicle voltage 120 W at 24 V DC AC/DC power adaptor or installations © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 64...
Page 65 0.22 kg Reference Please find a detailed description of the Fiber-Converter in chapter "Assembly and connection ". Please find here technical details concerning operating conditions. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 65...
Page 66 2.4 h module switched on battery recovery Battery temperature range -10 to +60 °C charging -10 to +60 °C discharging -20 to +65 °C standby © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 66...
Page 67 "Assembly and connection ". The meaning of the LED indicators of the UPS-NiMH - Technical Specs can be found in the section "LED display ". © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 67...
Page 68: Pin Configuration
Note Remote push button (pin 4) Briefly bridge remote push button (pin 4) with GND to switch on/off. © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 68...
Page 69: Base Unit
+CAN-SUPPLY -CAN-SUPPLY CAN_H CAN_L Fig. 14: Socket to connect CANFT modules CAN_GND (view on top of the socket) Reference Description: chapter Assembly and connection © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 69...
Page 70: Measurement Modules
Measurement Modules Chapter 9 9.4 Measurement Modules 9.4.1 UTI-6 Fig. 15: UTI-6-SUP socket (pinning) (view on top of the socket) Reference Description of the module © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 70...
Page 71 Figure 13: GPS socket (base unit) ............................69 Figure 14: Socket to connect CANFT modules ........................69 Figure 15: UTI-6-SUP socket (pinning) ..........................70 © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 71...
Page 72: Index
Power (UPS) module connect Liability restrictions Device group Limitations Device overview Storage medium DIN-EN-ISO-9001 Limited Warranty ElektroG Maintenance Master-/Slave-ID Memory cards microSD Storage medium © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 72...
Page 73 Swapping the storage medium SYNC SYNC socket synchronization System requirements Technical Specs UTI-6 Telephone numbers: Hotline Transport UTI-6 Current measurement Resistance measurement RTD measurement sensor supply © 2023 imc Test & Measurement GmbH imc ARGUSfit - Manual, Edition 1 - 2023-07-10 Page 73...
