  • Page 1 ARGUSfit Getting started Edition 5 - 2024-07-04 © 2024 imc Test & Measurement GmbH imc Test & Measurement GmbH • Voltastr. 5 • 13355 Berlin • Germany...
  • Page 2 Monitor installation medium in the folder "Products\imc DEVICES\OSS" or "Products\imc DEVICEcore\OSS" or "Products\imc STUDIO\OSS". If you wish to receive a copy of the GPL sources used, please contact our tech support. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 2...
  • Page 3 Notes denote useful additional information on a A reference in this document is a reference in particular topic. the text to another text passage. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 3...
  • Page 4: Table Of Contents

    6.4 Measurement Modules ........................ 39 6.4.1 B-4 ..................................39 6.4.2 UTI-6 ................................. 39 6.4.3 ICPU-6 ................................39 6.4.4 CAN FD (DSUB-9) .............................. 40 Index .......................... 42 © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 4...
  • Page 5: General Introduction

    CE Certification, current certificates and information about the imc quality system on our website: https://www.imc-tm.com/quality-assurance/. imc Warranty Subject to the general terms and conditions of imc Test & Measurement GmbH. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 5...
  • Page 6 Products not satisfying these requirements may only be used with special approval of the regulating body in the country where operated. All lines connected to the imc ARGUSfit should not be longer than 30 m and they should be shielded and the shielding must be grounded.
  • Page 7 In order to comply with the value limits applicable to Class B devices according to part 15 of the FCC regulations, all signal leads connected to imc ARGUSfit must be shielded. Unless otherwise indicated, no connection leads may be long leads (< 30 m) as defined by the standard IEC 61326-1.
  • Page 8: Explanation Of Symbols

    The device itself does not generate dangerous voltages. DC, Direct Current Supply of the device via a DC voltage source (in the specified voltage range) © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 8...
  • Page 9: History

    STUDIO 2023 R5 the GPS functionality is fully supported Amendments and bug-fix in Edition 2 Section Amendments CAN FD new module added: ARGFT/CAN FD © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 9...
  • Page 10: Safety

    The user must also ensure that any personnel assisting in the use of the imc ARGUSfit have also read and understood the content of this document.
  • Page 11 Industrial safety We certify that imc ARGUSfit in all product configuration options corresponding to this documentation conforms to the directives in the accident prevention regulations in "Electric Installations and Industrial Equipment" (DGUV Regulation 3)*. This confirmation applies exclusively to devices of the imc ARGUS series, but not to all other components included in the scope of delivery.
  • Page 12 Before touching the device sockets and the lines connected to them, make sure static electricity is diverted to ground. Damage arising from electrostatic discharge is not covered by the warranty. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 12...
  • Page 13: Assembly And Connection

    (forced ageing). The operating temperature data represent the extreme limits at which the function of all components can still be guaranteed. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 13...
  • Page 14: Notes On Connecting

    Legend: imc ARGUSfit provides a complete integration of the imc CANSASfit module series (CANFT) for slower channels, e.g. for temperature measurement. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 14...
  • Page 15: Precautions For Operation

    5. Avoid prolonged exposure of the device to sunlight. Due to their function, the imc ARGUSfit modules, just like the CANSASfit modules, are open at the connection points (module connectors). This is not a problem when used in a controlled, dry environment. In order to...
  • Page 16: Click Mechanism

    Chapter 3 3.3.2 Click mechanism imc ARGUSfit (ARGFT) modules and imc CANSASfit (CANFT) modules can be mechanically and electrically connected by a click-lock, without tools and without additional connecting cables. Before you start connecting the modules together, make sure that no supply voltage is connected.
  • Page 17: Using Canft Modules

    Chapter 3 3.3.3 Using CANFT modules imc ARGUSfit enables the integration of imc CANSASfit modules. These are clicked onto the left side of the ARGUSfit base unit. Additional modules can be connected by cable to the LEMO socket "CANSAS". The channels of these modules are fully integrated into the imc STUDIO setup page as analogue channels.
  • Page 18 The terminator must be plugged in before the ARGUS system is switched on. Fig. 5: CAN termination Reference imc CANSAS manual See also chapter "CAN termination with CANFT" in the imc CANSAS manual. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 18...
  • Page 19: Power Supply

    Chapter 3 3.3.4 Power supply An imc ARGUSfit system is operated with a DC supply voltage that is supplied via an ARGFT module with a socket ("POWER") compatible with LEMO.EGE.0B.302. This can be an ARGFT-BASE or an ARGFT-FIBER-CONVERTER, for example. Power is supplied to the rest of the system via the internal supply network (power backbone) of the electrical click connections between the modules.
  • Page 20: Fiber Converter

    Notes on connecting Chapter 3 3.3.5 Fiber Converter The Fiber Converter is a clickable module for the modular imc ARGUSfit system. It allows decentralized distributed system topologies. The module converts the internal high-speed ARGUS system bus, which connects the ARGUS measurement amplifiers and interface modules via the click connector, to a fiber-optic data link in the sense of a media converter.
  • Page 21: Ups-Nimh

    "Output power" section "Output-side overcurrent protection" · if the UPS buffer duration has expired or the battery is completely discharged in battery mode. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 21...
  • Page 22 © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 22...
  • Page 23 (age, number of cycles, lazy battery effect). This should be taken into account, especially for thermally demanding applications and high power requirements. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 23...
  • Page 24 Internal error of the UPS, buffer operation may not be possible. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 24...
  • Page 25: Powering On

    Reference Pin configuration of the LEMO socket, see chapter "Remote" © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 25...
  • Page 26: Storage Media In The Device

    ) causes the Windows-Explorer to start while indicating the device selected. Ribbon View Complete Extra > Data (Device) ( Standard Home > Data (Device) ( © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 26...
  • Page 27 Formatting causes all data on the storage medium to be deleted. Before performing the formatting, ensure that all data have been saved on a different storage medium. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 27...
  • Page 28 The storage medium is full. If the PC is connected to the measuring device, imc STUDIO documents the error with a message in the Logbook. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 28...
  • Page 29: Led Display Argft-Base

    - flashing fast Switched off Miscellaneous Power Fail (stop recording, close files) Firmware Update magenta - flashing Firmware required magenta Error red - flashing fast © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 29...
  • Page 30 Switched off Miscellaneous Power Fail as previous state as previous state as previous state (stop recording, close files) Firmware Update Firmware required Error © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 30...
  • Page 31: Maintenance And Servicing

    Detailed information on certificates, the specific contents, underlying standards (e.g. ISO 9001 / ISO 17025) and available media (pdf etc.) can be found on website, or you can contact us directly. 4.2 Cleaning Disconnect imc ARGUSfit devices from all circuits before cleaning. Only qualified personnel are permitted to clean the housing interior.
  • Page 32: Start Of Operation Software / Firmware

    Under some circumstances, this may require using switches to subdivide the network into separate segments in order to govern the data traffic in a targeted way and thus optimize the data rate. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 32...
  • Page 33: Connecting Via Lan In Three Steps

    Subsequently, a prompt appears asking whether to search for devices with an inappropriately configured network interface. Close this message box by clicking "Yes". © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 33...
  • Page 34 DHCP, the alternative values are used. These could lead to errors in the connection (different networks, same IP addresses, etc.). © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 34...
  • Page 35: Firmware Update

    1. Under no circumstances should the device or its power supply be deactivated during the firmware update! 2. The network connection may not be interrupted. Use a cable connection, not WLAN! © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 35...
  • Page 36 Nevertheless, with the new version of imc STUDIO, you are able to work with the device running the old firmware edition, if you choose. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 36...
  • Page 37: Pin Configuration

    Note Remote push button (pin 4) Briefly bridge remote push button (pin 4) with GND to switch on/off. © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 37...
  • Page 38: Base Unit

    -CAN-SUPPLY CAN_H CAN_L Fig. 13: Socket to connect CANFT modules CAN_GND (view on top of the socket) Reference Description: chapter Assembly and connection © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 38...
  • Page 39: Measurement Modules

    Fig. 15: UTI-6 socket (pinning) (View on top of the socket) 6.4.3 ICPU-6 Fig. 16: ICPU-6 socket (pinning) (view on top of the socket) © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 39...
  • Page 40: Can Fd (Dsub-9)

    Measurement Modules Chapter 6 6.4.4 CAN FD (DSUB-9) The CAN FD interface is a clickable module for the modular imc ARGUSfit system. Together with the analog ARGUSfit measurement amplifiers, several of these interfaces can be clicked to an imc ARGUSfit base. For the logical decoding of the channels, the module has a local intelligence in the form of a processor.
  • Page 41 Figure 13: Socket to connect CANFT modules ........................38 Figure 14: B-4 socket (pinning) ............................39 Figure 15: UTI-6 socket (pinning) ............................39 Figure 16: ICPU-6 socket (pinning) ............................. 39 © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 41...
  • Page 42: Index

    Copy data to the PC Issues Storage medium Customer support Tech support Leads Data transfer Password Base Storage medium Power (UPS) module Device Liability restrictions © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 42...
  • Page 43 Restriction of Hazardous Substances RoHS Safe operation Select device with explorer Service Tech support service and maintenance service check Service form Software installation Special hazards Storage © 2024 imc Test & Measurement GmbH imc ARGUSfit - Getting started, Edition 5 - 2024-07-04 Page 43...
  • Page 44 Contact imc Address imc Test & Measurement GmbH Voltastr. 5 13355 Berlin Phone: (Germany): +49 30 467090-0 E-Mail: info@imc-tm.de Internet: https://www.imc-tm.com Tech support If you have problems or questions, please contact our tech support: Phone: (Germany): +49 30 467090-26 E-Mail: hotline@imc-tm.de Internet: https://www.imc-tm.com/service-training/ imc ACADEMY - Training center The safe handling of measurement devices requires a good knowledge of the system.
