- Page 1 Scan the QR code for the most up-to-date information A9500 SkyID Module Created 8/23 207858.1...
- Page 2 WARNING AGAINST COUNTERFEIT PRODUCTS: Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or Spe- ktrum technology.
- Page 3 11. Select Add Device. 2. Secure the SPMA9500 module to your aircraft. 3. Connect to a Spektrum telemetry port, an open servo port (up to 9v), or a 3.3V to 9V power source. 4. Verify operation by viewing solid LED or Remote ID mobile app.
- Page 4 • Includes three wiring harnesses to meet the needs of most modelers. • Status is communicated with an internal LED and through Spektrum Telemetry • Able to function without Spektrum telemetry on any model aircraft from an open servo port, or any 3.3V to 9V power source. Contents •...
-
Page 5: Installation
SRXL2 or XBUS port. Wiring Options 4-Pin ZH to 3-Pin Servo Connector enables connection with any Spektrum receiver with an SRXL2 connection, or any standard servo port. 4-Pin ZH to 4-Pin Servo Connector enables connection with any Spektrum receiver with an SRXL2 or XBUS port. - Page 6 A9500 Remote ID Module Connection 4-Pin ZH port for power and status updates over telemetry. Connect with your Receiver AR6250MHX Helicopter Receiver Bind/Prog port AR630 Receiver Bind/Prog/SRXL2 port Bind/Prog/SRXL2 port is shared with the AR637T Receiver SRXL2 port on the side of the case.
-
Page 7: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution GPS may not function Located indoor indoors, take model outside Too close to large metal Cannot acquire objects a GPS lock Take model to an open Too close to tall buildings flying area Too close to high voltage lines Lost GPS during flight Disconnect and then Rapid flash... -
Page 8: Warranty Services
asserted. As Horizon has no control over use, setup, final assembly, modification or misuse, no liability shall be assumed nor accepted for any resulting damage or injury. By the act of use, setup or assembly, the user accepts all resulting liability. If you as the purchaser or user are not prepared to accept the liability associated with the use of the Product, purchaser is advised to return the Product immedi- ately in new and unused condition to the place of purchase. -
Page 9: Warranty And Service Contact Information
Warranty Requirements — For Warranty consideration, you must include your original sales receipt verifying the proof-of-purchase date. Provided warranty con- ditions have been met, your Product will be serviced or replaced free of charge. Service or replacement decisions are at the sole discretion of Horizon. Non-Warranty Service —... -
Page 10: Fcc Information
2.400GHz to 2.4835GHz frequency range. Supplier’s Declaration of Conformity Spektrum SkyID Module (SPMA9500) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 12 © 2023 Horizon Hobby, LLC. DSMX, SRXL2 are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. All other trademarks, service marks and logos are property of their respective owners.
