EX10SC-8B42-01 S
PECIFICATIONS
D
ESCRIPTION
I R
NPUT ANGE
I R
NPUT ESISTANCE
Normal
Power off
I P
NPUT ROTECTION
Continuous
Transient
L S V
OOP UPPLY OLTAGE
L S P
OOP UPPLY ROTECTION
CMV (C M V
OMMON ODE OLTAGE
Input to Output
T
RANSIENT
Input to output
CMR (C M R
OMMON ODE EJECTION
50 Hz or 60Hz
NMR (N M R
ORMAL ODE EJECTION
A
CCURACY
L
INEARITY
S
TABILITY
Offset
Gain
S
TABILITY
Offset
Gain
N
OISE
Output, 100 kHz
B (-3 dB)
ANDWIDTH
R T
ESPONSE IME
90% span
304
2-wire transmitter interface
4 mA to 20 mA
35 Ω
35 Ω
40 V ac
ANSI/IEEE C37.90.1
12 V dc
40 V ac
)
1500 V rms maximum
ANSI/IEEE C37.90.1
)
100 dB
)
60 dB per decade above 100Hz
±0.05% span
±0.02% span
±25 ppm/°C
±100 ppm/°C
±25 ppm/°C
±75 ppm/°C
500 μV rms
100 Hz
5 ms
EX10SC Signal Conditioning
