9. SENSOR PAIRING

9-1. TPMS Sensor Pairing

If the need arises to replace a sensor or change the location of pre-paired sensors
follow these simple steps.
Press the 'set' and '+' buttons for 3 seconds until a beep is heard to enter the
sensor pairing mode. It will start with the vehicle's passenger front wheel flashing.
Press the '+' button to scroll through to the desired wheel location for the new
sensor to be programmed to. Then screw the sensor onto the tyre valve and wait
for a beep (up to 20 seconds). Once a beep is heard, press, and hold the 'set'
button until another beep is heard to save the new data and return to standby
mode. Repeat this process for any additional sensors.

9-2. Wheel Bearing Sensor Activation and Pairing

All wheel bearing sensors need to be activated and paired to the monitor, (to
prolong the shelf life of the internal battery prior to first time installation).
Activation can be done just prior to, or after they have been installed on the hub
bearing dust caps.
Press the 'set' and '-' buttons for 3 seconds until a beep is heard. The passenger
front wheel will flash. Whilst the wheel icon is flashing, hold the magnet against
the sensor where the arrow is pointing and within 3 seconds the monitor will
beep, and the temperature will show. To save, press and hold the 'set' button again
until a beep is heard to save the new setting and return to standby mode. Repeat
this process for the other sensor/s.
bt = Bearing Temperature
After the passenger front tyre
has successfully paired
After the passenger front wheel
has successfully paired
