Cooper Lighting Sure-Lites UMX Series Specification

DESCRIPTION
The Sure-Lites watertight, corrosion resistant exit with tough polycarbonate
lens is designed for use where rain, moisture, dust or corrosives are
present. Economical long-life fluorescent lamps provide highly visible
signage and downlighting. The vibration resistant lamps make the UMX
perfect for heavy industrial applications (NEMA 4X Listed).
SPECIFICATION FEATURES
Electronic
- Dual Voltage Input
120/277 VAC, 60 Hz
- Line-latching
- Solid-state Voltage
Limited Charger
- Solid-state Switching
- Brownout Circuit
- Low-Voltage Disconnect
- Overload/Short Circuit
Protection
- Sealed Test Switch/Power
Indicator Light
Housing Construction
- NEMA 4X corrosion
resistant fiberglass
housing
- Industrial grey color
- Vented enclosure
11 3/4" [298mm]
Sample Number: UMX203
Series
UMX Self-Powered Wet =
Location with
Fluorescent
Lamps
Battery
20 Self-Powered, Lead =
Calcium
10 Lead Calcium Battery =
w/Remote Capability
22 Self-Powered, Nickel =
Cadmium
COOPER LIGHTING - SURE-LITES
Housing Construction Cont.
- Tough, high contrast
polycarbonate lens
- Rubber booted momentary
test switch and gasketed
charge indicator lamp
- Surface mount only
- Fully gasketed housing
- Wet Location Listed for
operation in ambient
temperatures above
32 degrees F.
Battery
- 6 Volt Sealed Lead Calcium
or Sealed Nickel Cadmium
- Maintenance-Free, Long-Life
- Full Recharge Time
24 hrs. (max.)
11 3/4"
[298mm]
Letter Color / Arrow Options
Direction
DH Dual Heads
8 Red Letters / Right Arrow =
7 Red Letters / No Arrow =
6 Red Letters / Left Arrow =
5 Red Letters / Double Arrow =
4 Green Letters / Right Arrow =
3 Green Letters / No Arrow =
2 Green Letters / Left Arrow =
1 Green Letters / Double =
Arrow
Specifications and Dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
Code Compliance
- UL 924 Wet Location Listed
- Life Safety NFPA 101
- NEC/OSHA
- Most State and Local Codes
Warranty
- Exit: 1-year
- Battery: 5-year pro-rata
(Lead Calcium); 15-year
pro-rata (Nickel Cadmium)
Lamp Data
- AC: Two F6T5 fluorescent lamps
- DC: Two 6V, 6W DC lamps
- Long-life, low energy
consumption
- Available with emergency
lighting heads mounted on
enclosure - consult Cooper
Lighting Representative
7 1/2" [191mm]
Accessories
=
Protective Housing
WG7 Wire Guard =
VS2 Polycarbonate Vandal Shield =
VS2WP Polycarbonate Vandal Shield - =
Weather Proof
®
Type
Date
UMX
SERIES
WET LOCATION EXITS
SELF-POWERED
EMERGENCY FLUORESCENT
LAMPS
Exit Lighting
E N E R G Y D AT A
Charge Mode (Fully Discharged Battery)
Sealed Lead Calcium Battery
Fluorescent Exits - 6W Lamps
Input Power:
120V= 41W
277V= 43W
Input Current (Max.):
120V= .51A
277V= .22A
Power Factor:
120V= >.66
277V= >.69
T.H.D.:
120V= <14%
277V= <14%
Standby Mode (Fully Charged Battery)
Sealed Lead Calcium Battery
Input Power consumption is reduced by
approximately 18 Watts in the standby
operating mode.
Sealed Nickel Cadmium Battery
Fluorescent Exits - 6W Lamps
Input Power:
120V= 29W
277V= 29W
Input Current (Max.):
120V= .42A
277V= .17A
Power Factor
120V= >.57
277V= >.62
T.H.D.:
120V= <9%
277V= <38%
ADX041112
