D I M E N S I O N S
23 1/4" [591mm]
Max.
6" [152mm]
SURE-LITES
5 1/8"
13" [330mm]
[130mm]
6" [152mm]
SURE-LITES
13" [330mm]
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : L P X 7 0 R W H D H
Family
LPX=
Polycarbonate
Exit
LPXH=High Power*
(Remote
Capacity)
Series
7=Self-Powered with
LED
Face Options
0=Universal
Battery
Blank=Lead Calcium
E n e r g y D a t a
LED Exits -Red Letters
LED Exits-Red Letters SD
Premium Deep Green
Charge Mode (Discharged Battery): Sealed Lead Calcium Battery
Input Power consumption is increased by approximately 2.7 watts in the charge operating mode for red units and 3.4
watts for green units
W a t t a g e R a t i n g s
LPXH* with double-heads (DH) has remote capacity of 11 watts for 1 1/2 hrs. No remote capacity for 4 hrs.
LPXH has Remote Capacity of 22 watts for 1 1/2 hrs. and 11 watts for 4 hrs.
COOPER LIGHTING - SURE-LITES
3/4"
[19mm]
4 3/4"
10"
[121mm]
[254mm]
3 7/8"
[98mm]
[114mm]
3/4"
[19mm]
10"
[254mm]
2 3/4"
[70mm]
Letter
Housing
Colors
Finishes
R=Red
WH=White
DG=Premium
BK=Black
Deep
(Red Only)
Green
Standby Mode (Fully charged Battery): Sealed Lead Calcium Battery
Input Power:
Input Current (Max.):
120V
277V
120V
277V
LED Exits
4.9W
4.7W
.07A
.03A
4.0W
3.9W
.06A
.02A
Premium
3.1W
2.9W
.06A
.02A
D E S C R I P T I O N
The LPX Series LED Exit is an
economical, yet attractive,
4 1/2"
alternative to metal exits. Its
[114mm]
contemporary round corner
styling, designer white finish,
and consistent family
appearance enables it to blend
with any decor. The tough
injection molded
polycarbonate materials resist
discoloration due to age and
ultraviolet radiation. The
structural components are
2 3/4"
[70mm]
made even stronger with
3 3/4"
reinforcing ribs throughout.
[95mm]
max.
All components are of snap-fit
construction to facilitate
installation; reliable and labor-
saving push-in AC connectors
4 1/2"
are standard to further improve
the installation time. The under
5-minute installation time of
the LPX Series Exits makes it
the fastest installed exit on the
market today. The LPX Series
Exits are available in universal
configurations.
Voltage
Accessories
Blank=120/277
(Order Separately)
VAC
CCX18PKWH=18" Pendant
Kit, White
CCX18PKHTWH=18"
Hang True Pendant Kit,
Heads
White
Blank=No
WG10=Wall Mount (without
Heads
heads)
(LPXH
WGS11=Ceiling or End
Only)
Mount (without
DH=Double
heads)
Heads
WG12=Wall Mount (with
heads)
WG17=Ceiling or Wall
Options
Mount (with heads)
SD=Self-Diagnostics
VS1=Polycarbonate Vandal
(Red Only)
Shield (without heads)
VS2=Polycarbonate vandal
shield (with heads)
LPX1HWH=Head assembly,
Power Factor:
120V
277V
120V
> .59
> .64
< 45% < 44%
>.57
>.58
<40%
> .41
> .44
< 49% < 53%
LPX(H) SERIES
P o l y c a r b o n a t e
S e l f - P o w e r e d
( R e m o t e C a p a c i t y )
D o u b l e H e a d s
E X I T L I G H T I N G
• Dual Voltage Input 120/277
VAC, 60Hz, isolation
transformer
• Injection molded, high
impact, polycarbonate
housing
• LED lamping
• Heads DC: 6V, 5.4W
incandescent wedge base
lamps. PAR 36 Style
• Sealed Lead Calcium Battery,
Maintenance Free, Long Life,
Full Recharge Time, 24 hours
(max.); 48 hours (max.) for
LPXH units
• Ceiling, wall, or end
mountable
• Universal exits can be field
configured as single face or
double face and ceiling wall
or end mounted
• Knockout provided on
housing for surface conduit
attachment
• Snap-fit canopy with captive
mounting screws included
with all exits
• Line-Latching, Solid-State
Voltage Limited Charger,
Solid-State Switching,
Brownout Circuit, Low-
White (LPXH
only)
Voltage Disconnect,
Overload/Short Circuit
Protection, Test Switch /
Power Indicator Light, Push-
T.H.D.:
in AC power connectors
facilitate installation
277V
• UL 924, UL 924, 4 hour rated
(LPXH Units), Life Safety
NFPA 101, CSA Certified,
NEC/OSHA, Damp Location
<46%
Listed Standard, suitable for
floor proximity installation
• Patent No. 5,735,498 and
5,678,336
COOPER LIGHTING
®
EXITS
H i g h P o w e r
643
