- Page 1 Face Recognition Reader & Controller User’s Manual R71CF-38 2021/03/24...
-
Page 2: Regulatory Information
2. This device must accept any interference received, including interference that may cause undesired operation. Now that the camera and the PC are both having their unique IP addresses and are under the same network segment, it is possible to use the Web browser of the PC to access the camera. www.acti.com... - Page 3 The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see:www.recyclethis.info www.acti.com...
-
Page 4: Safety Information
Dispose of used batteries according to the instructions If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the device yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) www.acti.com... - Page 5 Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to the technical specifications for detailed information. www.acti.com...
-
Page 6: Table Of Contents
Wall Mounting ..................12 Initial Settings ............14 Step 1: Login .................... 14 Step 2: Configure Wired Network Settings ..........15 Basic Operation ............ 16 Main Screen....................16 Home Menu ....................16 Menu Tree ..................... 17 Tips in Picture Taking ........... 18 www.acti.com... -
Page 7: Introduction
Introduction Package Content Face Recognition Reader & Controller Mounting plate Wrench Lock screws for mounting plate (x2) Screw pack Cable Mini-USB to USB cable converter Quick start guide Drill template www.acti.com... -
Page 8: Physical Description
USER’S MANUAL Physical Description Item Camera IR LED Touch Screen Card Reader USB connector Speaker Tamper Key Terminal (Cable Connector) Ethernet Debugging (for debugging only) www.acti.com... -
Page 9: Wiring
Ground Wiegand Wiring Green Group C Wiegand Wiegand Wiring White White/Black Ground White/Purple Lock Wiring (NC) White/Yellow Common White/Red Lock Wiring (NO) Yellow/Gree Group D Door Lock SENSOR Door Contact Black Ground Yellow/Gray BUTTON Exit Door Wiring Yellow/Black Ground www.acti.com... -
Page 10: Wiring Common Devices
Do not wire the device to the electric supply directly. Wiring Secure Door Control Unit The secure door control should connect to an external power supply separately. The suggested external power supply is 12V, 0.5A www.acti.com... -
Page 11: Installation
The device should be installed at least 2 meters away from light, and 3 meters away from the window or door. Make sure the wall can bear three (3) times the weight of the device. Installation Height Recommended installation height of device = 1.43 m to 1.9 m www.acti.com... -
Page 12: Wall Mounting
2. Align the holes to the mounting plate and secure it to the wall using the 4 supplied screws. 3. Route the cable through the cable hole of the mounting plate and hang the device on the mounting plate. www.acti.com... - Page 13 USER’S MANUAL 4. Attach one of the supplied lock screw to secure the device and the mounting plate. www.acti.com...
-
Page 14: Initial Settings
1. Long tap the screen for 3 seconds, a gesture icon will appear, then slide to the left or right to enter the Login page. 2. Tap the unlock icon for the device to prompt for the password. 3. Type the activation password to login. 4. After authentication, the Home Menu will appear. www.acti.com... -
Page 15: Step 2: Configure Wired Network Settings
NOTE: The device IP address and the computer IP address should be in the same IP segment. 4. Set the DNS parameters. You can enable Auto Obtain DNS, set the preferred DNS server and the alternate DNS server. www.acti.com... -
Page 16: Basic Operation
Home Menu After login, the Home Menu appears. Below is the summary of the Home Menu. Except for Communication Network settings, almost all configurations can be done through the Access Control Server thus the Home Menu is rarely used. www.acti.com... -
Page 17: Menu Tree
You will need to plug in a USB flash drive to import/export data. Use the supplied micro-USB to USB cable. System The System Maintenance menu allows you to view the system information and the device capacity. Rebooting of device can also be done here. www.acti.com... -
Page 18: Tips In Picture Taking
Keep expression natural Expression Do not wear hat, sunglasses and other accessories Do not allow hair to cover your eyes, ears, etc. Do not use heavy makeup Posture Face should be facing the camera. Size www.acti.com... - Page 19 Copyright © 2021, ACTi Corporation All Rights Reserved 7F, No. 1, Alley 20, Lane 407, Sec. 2, Ti-Ding Blvd., Neihu District, Taipei, Taiwan 114, R.O.C. TEL : +886-2-2656-2588 FAX : +886-2-2656-2599 Email: sales@acti.com...
