Connect to Door Contact ................ 13 Connect to Electric Bolt ................13 Connect to Magnetic Lock ..............14 Connect to Reader ................... 14 Connect to Electric Strike ............... 15 Connect to Relay Output Module for Added Security ......15 www.acti.com...
Page 3
Configure the IP Address ..............17 Useful Shortcuts ..................18 How to Exit the Menu ................18 How to Change the Master Code ............18 How to Lock and Unlock the Keypad ............ 18 Accessing the Device ........... 19 Web Interface ................... 19 www.acti.com...
Every reasonable care has been taken during the writing of this manual. Please inform your local office if you find any inaccuracies or omissions. We cannot be held responsible for any typographical or technical errors and reserve the right to make changes to the product and manuals without prior notice. www.acti.com...
Safety Check Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine if the product is in proper operating condition. www.acti.com...
NOTE: Actual items may slightly vary. Additional Requirement for Installation The following items are not included in the package. Installers must prepare these items to do the installation. 1. DC 10~24V Power adapter 2. Ethernet cable 3. Allen wrench www.acti.com...
Front Panel Below are the detailed descriptions of the front panel indicators and keypad. Press to enter SETUP mode In SETUP menu, press to go back a previous screen. ESC / Quit Press to “Enter” or select www.acti.com...
Installation Guide Connectors This section shows the connectors at the back of the device and its pin mapping definition. For wiring examples, see Wiring Diagram on page 13. www.acti.com...
3. Flush the mounting plate into the wall. 4. Drill the holes and attach the four (4) screws Cable hole to secure the plate as marked on the illustration. www.acti.com...
(cable with white lines) while the BLACK wire connects to the ground wire of the power adapter. White stripe: Connects to 12V Pin Connects to GND Pin 4. Continue to connect other devices, as needed. Refer to Wiring Diagram on page 13. www.acti.com...
Align the top part of the reader/controller to the mounting plate and attach the two (2) supplied screws. Step 4: Connect to Power Source When the unit is connected to the power source, the unit will initialize. Once complete, the LCD will display “Ready”. www.acti.com...
Installation Guide Wiring Diagram This section shows the wiring options you can do with the reader/controller. Connect to Door Contact Connect to Electric Bolt www.acti.com...
Installation Guide Wiegand Mode It is possible to use the unit as a reader and connect it to another unit which can be the controller. To do this, connect the units by Wiegand. Below is the wiring diagram. www.acti.com...
5. Press the keypad to enter the preferred IP address. TIP: Press to enter or copy the existing value shown on the screen. 6. Continue to enter the Net Mask, and Gateway. 7. When done, press to exit the configuration menu. www.acti.com...
3. Press the keypad to enter the new 6-digit master code. 4. The screen will automatically show SUCCEEDED after pressing the last digit of the code. How to Lock and Unlock the Keypad Press at the same time to lock or unlock the keypad. www.acti.com...
1. Open a web browser and type the IP address on the address bar. 2. If prompted to login, type the User Name “admin” and leave the Password empty. 3. After a successful login, the user interface will be shown. www.acti.com...
