- Page 1 EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ EC-IMX8MP Specification www.emtop-tech.com wiki.emtop-tech.com sales@emtop-tech.com support@emtop-tech.com...
-
Page 2: Revision History
EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ Revision History Date Revision Change Details 2023/06/02 V1.0 First Released www.emtop-tech.com wiki.emtop-tech.com sales@emtop-tech.com support@emtop-tech.com... -
Page 3: Main Features
EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ Overview: EC-8MP Edge Computer is composed of SOM-IMX8MP, Carrier Board and the steel & aluminum enclosure. Engineered for industrial applications, it has wide operating temperature range from -20℃ to ... - Page 4 EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ I/O Interfaces and Dimension: www.emtop-tech.com wiki.emtop-tech.com sales@emtop-tech.com support@emtop-tech.com...
- Page 5 EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ www.emtop-tech.com wiki.emtop-tech.com sales@emtop-tech.com support@emtop-tech.com...
-
Page 6: Specification
EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ Specification System Unit 2x or 4x Cortex A53 up to 1.8GHz 1x Cortex M7 up to 800MHz 375 Mpixel/s HDR ISP CPU Performance GC7000UL with OpenCL and Vulkan support ... - Page 7 EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ SIM Slot 1x Built-in Micro SIM slot, push pop-up slot SD Slot 1x Built-in Micro SD slot, push pop-up slot M.2 B Key(USB3.0) Support 4G/5G module such as Quectel 4G module, built-in SIM card, etc.
-
Page 8: Software Specification
EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ Software Specification Formats Names Note MMC/SD Source Code BOOTLOADER U-BOOT Source Code Source Code Support JFFS2/EXT4/FAT/NFS KERNEL LINUX-5.15.32 Source Code various of file system PMIC PCA9450CHN driver Source Code... -
Page 9: Order Information
EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ Order Information Item Name LPDDR4 EMMC WIFI/BT Price@1k Temp EC-IMX8MP-L216CW 16GB USD139 0°C-70°C EC-IMX8MP-L216CW-I 16GB USD169 -45°C-85°C Packing List: 1x EC-IMX8MP Edge Computer 1x 12V@2A Power Adapter ... - Page 10 EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ Appendix Quick Start Guide SBC-IMX8MP Support SSH or Serial to get debug information 1x 12V@2A Power Adapter Must 1x USB Type C Cable (Connect to Serial Interface On Board, phone charge Cable OK) Must ...
- Page 11 EC-IMX8MP Edge Computer Series NXP i.MX 8M Plus Quad Core Cortex-A53 1.8GHZ/1.6GHZ Debug Serial, Type-C Interface, Connector To your PC, Drivers will auto install. 12V@2A Power Adapter Optional, Connect Ethernet cable to your router if you use SSH Optional, Connect to your HDMI display...
