Samsung SGH-X566 User Manual

SGH-X566
User's Guide
• Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
• Depending on your country, your phone and accessories may appear different
from the illustrations in this guide.
• Please read this manual before operating your phone, and keep it for future
reference.
Printed in Korea
Code No.: GH68-14444A
World Wide Web
http://www.samsungmobile.com English (LTN). 03/2007. Rev.1.0
Silent Press and hold in Idle mode to disable all sounds on the phone.
To exit, press and hold this key again.
mode
Voicemail
Press and hold 1 in Idle mode to access your voicemail server.
server
With the phone closed, press the Volume keys four times to send an
SOS
SOS message to preset phone numbers. Once the SOS message is
mode
sent, the phone will change to SOS mode and will receive calls only
from the SOS message recipients until the SOS mode is cancelled.
Upon receiving a call from the SOS message recipients, the phone
will automatically answer the call, after one vibration, relaying the
emergency situation to the caller.
Display
Your phone is in Idle mode when you are not on a call or using a menu.
You must be in Idle mode to dial a phone number.
Icons
Text and graphics
Soft key function
Menu Phonebook
indicators
Using the menus
In Idle mode, press the Menu soft key to enter the main menu.
Labels at the bottom corners of the
display show the current soft key
functions. Press the left soft key ( )
or right soft key ( ) to perform the
function indicated.
To exit the
To return to the menu without
previous menu changing the
level, press the menu settings,
C
Back soft key or . press this key.
Use the 4-way navigation keys to scroll
up, down, left, or right through the menu
system, highlight menu items, change
feature settings, and play games.
Installing the SIM card and battery
1. Remove the battery cover and insert the SIM card.
Battery cover
2. Install the battery and reattach the cover.
Battery
Your phone displays the following status indicators on the top of the
screen:
Icon Description
Received signal strength
Call in progress
Out of your service area; you cannot send or receive calls
except for emergency calls
GPRS network
Home Zone, if you have registered for the appropriate service
Office Zone, if you have registered for the appropriate service
Alarm set
New SMS message
New MMS message
Call diverting feature active
Call ringer type
• None: Melody
• : Vibration
• : Vibration then melody
Silent mode
Battery power level
To select or modify a menu or feature:
1. In Idle mode, press the Menu soft key.
2. Press the Navigation keys to reach a desired menu and then press
the Select soft key or .
3. If the menu contains any submenus, locate the one you want by
pressing the Navigation keys. Press the Select soft key or
enter the submenu.
If the selected menu contains additional submenus, repeat this step.
4. Press the Navigation keys to find the setting of your choice.
5. Press the Select soft key or to confirm your chosen setting.
Shortcut numbers
You can quickly access the menu you want by using shortcut numbers.
The shortcut number displays in front of the menu name in Menu mode.

Charging the battery

1. Plug the supplied travel adapter.
To AC wall outlet
2. When charging is finished, unplug the adapter.
Note: Do not remove the battery from the phone without unplugging the
adapter first. Otherwise, the phone may be damaged.
Switching on or off the phone
1. Press and hold for more than one second to switch on the phone.
2. To switch off the phone, press and hold
Changing the display language
1. In Idle mode, press the Menu soft key.
2. Select Phone settings Language Text
→ →
3. Select a language.
Making a call
1. In Idle mode, enter an area code and phone number, and press
2. When you want to end the call, press .
Answering a call
1. When the phone rings, press the Accept soft key or
call.
2. To end the call, press .
Menu map
1. Call log 5. Messages
1.1 Missed calls 5.1 Text messages
1.2 Received calls 5.2 Multimedia messages
1.3 Dialled calls 5.3 Push messages
1.4 Delete all 5.4 Preset messages
1.5 Call time 5.5 Voice mail
1.6 Call costs* 5.6 Broadcast
5.7 Settings
2. Network services 5.8 SOS messages
to 5.9 Memory status
2.1 Call diverting
2.2 Call barring
6. Fun box
2.3 Call waiting
2.4 Network selection 6.1 WWW services
2.5 Caller ID 6.2 Media box
2.6 Band selection 6.3 JAVA world
2.7 Active line*
7. Planner
3. Applications
7.1 New memo
7.2 Calendar
3.1 Voice recorder
7.3 To do list
3.2 SIM-AT*
7.4 Clock
7.5 Alarm
4. Sound settings
7.6 Calculator
4.1 Incoming calls
7.7 Converter
4.2 Messages
7.8 Timer
4.3 Power on/off
7.9 Stopwatch
4.4 Connection tone
4.5 Keypad tone
8. Camera
4.6 Minute minder
8.1 Take photos
4.7 Silent mode
8.2 My photos
4.8 Alerts on call
Phone layout and key functions
Soft keys
Perform functions
indicated by the text
above the key.
Volume keys
In Idle mode, adjust the
keypad tone volume.
Send an SOS message
when pressed four times
with the phone closed.
SOS mode
Dial key
Makes and answers a call.
In Idle mode, retrieves
the most recent calls.
Voicemail server key
Voicemail server
Alphanumeric keys

Adjusting the volume

1. In Idle mode, press the
2. Select Sound settings
for more than two seconds.
3. Press the Navigation keys to adjust the volume level.
4. Press the Save soft key.
While a call is in progress, press
volume.
language.
Changing a ringtone for calls
1. In Idle mode, press the
2. Select Sound settings
.
My sounds.
3. Select a ringtone and press the
Redialing recent numbers
to answer a
1. In Idle mode, press
2. Press Up or Down to scroll to the number you want.
3. Press to dial the number.

Entering text

Changing the text input mode
8.3 Delete all
8.4 Settings
8.5 Memory status In a text input field, press the right soft key until the input mode indicator
you want appears:
9. Phone settings
9.1 Display • : T9 mode
9.2 Greeting message
• : ABC mode
9.3 Language
9.4 Offline mode
• : Number mode
9.5 Security
9.6 Auto redial
• None: Symbol mode
9.7 Anykey answer
9.8 Active folder
T9 mode
9.9 Volume key
9.0 Reset settings
1. Press 2 to 9 to start entering a word. Press each key once for one
Phonebook
letter.
1 Find name
2 FDN list Example: To enter Hello in T9 mode, press 4, 3, 5, 5, and 6.
3 Add entry
T9 predicts the word that you are typing, and it may change with each
4 Speed-dial list
5 Own number key that you press.
6 Group setting
7 Management
2. Enter the whole word before editing or deleting characters.
8 SDN*
3. When the word displays correctly, go to step 4. Otherwise, press
display alternative word choices for the keys that you have pressed.
*
Shows only if supported For example, Of and Me use
by your SIM card.
4. Press to insert a space and enter the next word.
Web access/
Confirm key
In Idle mode, accesses
the web browser.
Selects the highlighted
option or confirms input
in Menu mode.
4-way navigation keys
In Menu mode, scroll
through menu options.
In Idle mode, access
specific menus directly.
Power/End key
Turns the phone on or
off when held down.
Also ends a call.
Cancel/Clear key
Deletes characters from
the display. Returns the
display to the previous
menu level.
Silent mode key
Silent mode
Menu soft key.
Incoming calls Ring volume.
→ →
Up or Down to adjust the earpiece
Menu soft key.
Incoming calls Default ringtones or
→ →
Yes soft key.
.
0 to
6 and 3.
