GSM TELEPHONE
GSM TELEPHONE
SGH-X500
CONTENTS
1.
Safety Precautions
2.
Specification
3.
Product Function
4.
Array course control
5.
Exploded View and Parts List
6.
Disassembly and Assembly
instructions
7.
MAIN Electrical Parts List
8.
Block Diagrams
9.
PCB Diagrams
10. Flow Chart of Troubleshooting
11. Reference data

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGH-X500 and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung SGH-X500

Summary of Contents for Samsung SGH-X500

  • Page 1 GSM TELEPHONE SGH-X500 GSM TELEPHONE CONTENTS Safety Precautions Specification Product Function Array course control Exploded View and Parts List Disassembly and Assembly instructions MAIN Electrical Parts List Block Diagrams PCB Diagrams 10. Flow Chart of Troubleshooting 11. Reference data...

  • Page 2: Table Of Contents

    Contents 1. Safety Precautions 1-1. Repair Precaution ................1-1 1-2. ESD(Electrostatically Sensitive Devices) Precaution ......1-2 2. Specification 2-1. GSM General Specification ..............2-1 2-2. GSM Tx Power Class ..............2-2 3. Product Function 3-1. Main Function ................3-1 4. Array course control Software Downloading 4-1.
  • Page 3 Contents 10. Flow Chart of Troubleshooting 10-1. Baseband 10-1-1. Power ON ................10-1 10-1-2. Initial ..................10-4 10-1-3. Sim Part ................10-6 10-1-4 Microphone Part ..............10-8 10-1-5. Speaker Part ................10-10 10-2. RF 10-2-1. EGSM RX ................10-13 10-2-2. DCS RX ................10-14 10-2-3. PCS RX ................10-15 10-2-4.

  • Page 4: Safety Precautions

    ● Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 5: Esd(Electrostatically Sensitive Devices) Precaution

    ● You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 6: Specification

    S ensi ti vit y -102 dBm -102 dBm -100 dBm -100 dBm TDM A Mu x Cell Radiu s 35 Km 35 Km 2 Km SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 7: Gsm Tx Power Class

    8±4 dBm 8±4 dBm 9± 3dBm 6±4 dBm 6±4 dBm 7±3 dBm 4±4 dBm 4±4 dBm 5±3 dBm 2±5 dBm 2±5 dBm 0±5 dBm 0±5 dBm SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 8: Product Function

    3. Product Function Main Function -My mane card -Java world -Voice memo -Stopwatch -SIM service -Access the homepage -SMS and MMS -Bluetooth -Set Quiet mode -Network services SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 9: Array Course Control

    4. Array course control Test Jig (GH80-03307A) Test Cable (GH39-00127A) RF Test Cable (GH39-00397A) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 10: Software Downloading

    • Three binary files for downloading X500 . – X500XXYY.s3 : Main source code binary. 4-2. Pre-requsite for Downloading • Downloader Program(OptiFlash.exe) • X500 Mobile Phone • Data Cable • Binary files SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 11: S/W Downloader Program

    2. Select the “Options” -> “Settings” -> “Generic” -> “Specify hardware platform”. Choose hardware platform for the downloader file setting. Set the everything else as the default values which are shown below SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 12 However, OptiFlash will use a slower speed if either the PC’s or the phone’s serial hardware is incapable of handling the selected speed SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 13 “X500XXYY.s3”, for the downloader binary setting. Make sure that not to change the reserved memory regions. In case of X500 the reserved regions are : -0x20000000 – 0x2000ffff -0x21fc0000– 0x21ffffff SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 14 7. After finishing downloading, Certain memory resets should be done to guarantee the normal performance. 8. Confirm the downloaded version name and etc. : *#1234# Full Reset : *2767*3855# SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 15: Exploded View And Parts List

    5-1. Cellular phone Exploded View QFR01 QFU01 QIF01 QLC01 QKP01 QSP01 QMO01 QME03 QMI01 QMP01 QME01 QFL01 QAN05 QCR05 QSC11 QAN02 QMW02 QRE01 QRF03 QVO01 QRF01 QBA01 QCR05 QBA00 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 16: Cellular Phone Part List

    SPEAKER 3001-001963 QVO01 　 ASSY KEY-VOLUME GH98-01510A QFR01 　 ASSY-CASE-FRONT GH98-00892A 　 QIF01 PMO-COVER IF GH72-30580A QRE01 　 ASSY-CASE-REAR GH98-00895A 　 QRF03 PMO-COVER EARJACK GH72-30586A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 17 GH74-23813A MPR-TAPE PBA D GH74-24143A MPR-CUSHION LCD GH74-24319A MPR-CUSHION INTENNA GH74-24320A MPR-TAPE IF COVER GH74-24740A MPR-VINYL BOHO SUB WINDOW B GH74-24835A MPR-TAPE REAR BOSS GH74-25692A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 18: Disassembly And Assembly Instructions

    1) Be careful a demage of PBA components. Framework demage. 2) Be careful about the tear of LCD FPCB molding damage! 2) Be careful about the tear of LCD FPCB SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 19 1) Be careful about the scratch occurrence or Framework demage. 2) When you dissolve Motor and Speaker, you have to use pincette in the Hook(above blue Circle). SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 20: Assembly

    1) Be careful about the scratch occurrence or ※ caution 1) Be careful about the scratch occurrence or Framework demage. Framework demage. 2) Using (1.0 ± 0.1 Kgf/ ㎠ ) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 21 1) Taping FRONT strange protecting tape. ※ caution ※ caution 1) Be careful about the tear of LCD FPCB 1) You have to caution KEYPAD Hole. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 22 Framework demage. M1.4* L3 2) When you assemble REAR , you have to ※ caution check VOLUME KEY omitting. 1) Be careful about the scratch occurrence SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 23: Lcd Kit

    3) BOND is prohibitted over SILK line. 2) Check Motor WIRE bonding condition and 4) Do bonding SPK, MOTOR soldering part external appearance. and some wire. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 24 1) Post 3 insulation TAPE CON TO CON TAPE see below picture. ※ caution ※ caution 1) Follow LCD using consideration 1) Be careful strange material or finger mark. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 25 - if there are any strange spots in LCD surface , please don't use those LCD. those LCD are faulty LCD - if there are any kinds of tear/split/demage/short in FPCB, please don't use those LCD. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 26: Main Electrical Parts List

    C-CER,CHIP 2404-001268 C128 C-TA,CHIP 2203-006048 C200 C-CER,CHIP 2203-006048 C201 C-CER,CHIP 2203-000254 C202 C-CER,CHIP 2203-000254 C203 C-CER,CHIP 2203-006048 C204 C-CER,CHIP 2203-000254 C205 C-CER,CHIP 2203-000254 C206 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 27 C-CER,CHIP 2203-006348 C313 C-CER,CHIP 2203-002709 C314 C-CER,CHIP 2404-001381 C315 C-TA,CHIP 2203-006562 C316 C-CER,CHIP 2203-000311 C317 C-CER,CHIP 2203-000311 C318 C-CER,CHIP 2203-000940 C319 C-CER,CHIP 2203-006562 C320 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 28 C-CER,CHIP 2404-001381 C407 C-TA,CHIP 2203-006194 C500 C-CER,CHIP 2203-006423 C501 C-CER,CHIP 2203-000254 C502 C-CER,CHIP 2203-006048 C503 C-CER,CHIP 2203-006048 C504 C-CER,CHIP 2203-000254 C505 C-CER,CHIP 2203-006681 C506 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 29 C-CER,CHIP 2203-005682 C629 C-CER,CHIP 2203-005682 C630 C-CER,CHIP 2203-005682 C631 C-CER,CHIP 2203-002668 C632 C-CER,CHIP 2203-005234 C633 C-CER,CHIP 0404-001172 DIODE-SCHOTTKY 3722-002067 EAR302 JACK-EAR PHONE 1405-001161 F401 VARISTOR SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 30 2703-001868 L612 INDUCTOR-SMD 0601-002053 LED401 0601-002053 LED402 0601-002053 LED403 0601-002053 LED404 0601-002053 LED405 0601-002053 LED406 0601-002053 LED407 0601-002053 LED408 0601-002053 LED409 0601-002053 LED410 0601-002053 LED411 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 31 R-CHIP 2007-007142 R212 R-CHIP 2007-000157 R213 R-CHIP 2007-007528 R214 R-CHIP 2007-000139 R215 R-CHIP 2007-000139 R216 R-CHIP 2007-001290 R217 R-CHIP 2007-001290 R218 R-CHIP 2007-000171 R219 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 32 R-CHIP 2007-007142 R329 R-CHIP 2007-000831 R330 R-CHIP 2007-000831 R331 R-CHIP 2007-000171 R333 R-CHIP 2007-000171 R335 R-CHIP 2007-000171 R336 R-CHIP 2007-000173 R337 R-CHIP 2007-000153 R338 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 33 R-CHIP 2007-000174 R429 R-CHIP 2007-000174 R430 R-CHIP 2007-008483 R501 R-CHIP 2007-008542 R502 R-CHIP 2007-008419 R503 R-CHIP 2007-008419 R505 R-CHIP 2007-008419 R506 R-CHIP 2007-008419 R507 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 34 IC-MCP 1405-001082 VR201 VARISTOR 1405-001082 VR302 VARISTOR 1405-001082 VR305 VARISTOR 1405-001082 VR306 VARISTOR 1405-001082 VR307 VARISTOR 1405-001082 VR308 VARISTOR 1405-001108 VR402 VARISTOR 1405-001108 VR404 VARISTOR SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 0406-001201 ZD404 DIODE-TVS 0406-001201 ZD405 DIODE-TVS 0406-001201 ZD408 DIODE-TVS 0406-001201 ZD420 DIODE-TVS 0406-001201 ZD421 DIODE-TVS 0403-001547 ZD501 DIODE-ZENER 0406-001208 ZD504 DIODE-TVS 0406-001208 ZD505 DIODE-TVS 7-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 36: Block Diagrams

    8. Block Diagrams 8-1. RF PART SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 37 Block Diagrams 8-2. LOGIC PART SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 38: Bt Block

    Block Diagrams 8-3. BT Block SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 39: Pcb Diagrams

    VR407 VR406 VR405 ZD402 CP_W EN VR421 RAM1_CS ROM1_CS VR419 CP_OEN VR420 VR411 A(1) D(0) VR410 UME501 BAT101 SIM103 VR502 ZD503 VR503 BTC504 MIC301 IFC501 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 40 LEFT RIGHT LED409 LED411 VR408 VR409 DOWN SEND CLEAR LED405 LED401 TP203 TP201 ZD419 LED407 LED408 TP506 TP507 A(0)_TP FLASH_RESET LED414 TP502 TP512 TP508 TP511 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 41: Flow Chart Of Troubleshooting

    Check the clock signal at pin#3 of OSC601 There is 26MHz wave Check the clock generation form at the OSC601 circuit(related to OSC601) pin#1,3 Check the initial operation 10-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 42 Flow Chart of Troubleshooting ① 10-2 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 43 RTX_QN 4 BQN RFIEP GSM_LNA_IN_P SERDAT 3 SDIO RFIEN GSM_LNA_IN_N SERLE _SEN RFIAP SERCLK 1 SCLK RFIAN R603 XOENA C619 OSC601 C622 C623 C624 10-3 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 44: Initial

    There is 26MHz wave form Check the OSC601 at the OSC601 pin#1,3 LCD display is O.K Check the LCD part Sound operation O.K Check the Audio part 10-4 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 45 Flow Chart of Troubleshooting IRQ1 M16 PIO47 PIO34 R14 PIO33 OSC202 C223 C224 VCCD_1.8 R222 AUDIO_EN R223 BP_VF VIB_EN VBT_EN R224 10-5 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 46: Sim Part

    Check the UCD102 SIM103 pin #1 ≥ 2.8V There is any signal check the UCD102 & UCP201 pin#2,#3,#4 of SIM103 Check the SIM Card 10-6 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 47 Flow Chart of Troubleshooting SIM103 VSIM SIM_RST SIM_CLK SIM_IO C108 C109 C110 C111 C112 10-7 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 48: Microphone Part

    Check the reference voltage on mic path Resolder or change The Voltage @ C318 is about 2.0V Check component of mic path. The microphone is O.K Check UCD102 10-8 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 49 R314 MICOUTP C317 C318 C319 AGND C320 R315 R316 MICINN C321 R317 MICOUTN R318 R319 C322 VCCA_2.9 R320 C323 C324 R322 R323 R324 AGND 10-9 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 50: Speaker Part

    @ R302,R307 @ C403, C404 The pin#4 of Check the Check the U301 is "High" UCD102 UCD302, U303 Check the UCP201 Check the U303 10-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 51 AMP_OUT_N VREF VSS 11 C303 R303 U301 AMP_IN_N VSS 10 L304 C309 R305 AMP_IN_P AMP_EN R341 R340 AMP_OUT_P C339 C340 R309 C313 C315 C314 10-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 52 AGND WM_BCLK BCLK VREF UCD302 DGND VMID DBVDD DCVDD C301 HPDETECT CLK13M_WM MCLK C304 C305 C306 C307 C308 C310 R306 C311 R308 VCCD_1.8 R310 10-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 53: Egsm Rx

    OSC601 CHECK OSC601 pin #1 : 26MHz & change or resolder Vp-p : 900mV U602 U602 pin#1,#2,#3,#28 resolder or change Vp-p = 100mV UCD102 CHECK!! 10-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 54: Dcs Rx

    OSC601 CHECK OSC601 pin #1 : 26MHz & change or resolder Vp-p : 900mV U602 U602 pin#1,#2,#3,#28 resolder or change Vp-p = 100mV UCD102 CHECK!! 10-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 55: Pcs Rx

    OSC601 pin #1 : 26MHz & change or resolder Vp-p : 900mV U602 U602 pin#1,#2,#3,#28 Vp- resolder or change p = 100mV UCD102 CHECK!! 10-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 56 Flow Chart of Troubleshooting 10-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 57: Egsm Tx

    U602 OSC601 pin#30 : 26MHz & change or resolder Vp-p : 900mV? U602 UCD102 pin#4,#5,#6,#7 change or resolder = 1.5V U602 change or resolder 10-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 58: Dcs/Pcs Tx

    U602 OSC601 pin#30 : 26MHz & change or resolder Vp-p : 900mV? U602 UCD102 pin#4,#5,#6,#7 change or resolder = 1.5V U602 change or resolder 10-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 59 17 GND3 VCC1 15 GND2 13 GND1 C620 C621 DPCS_PAM_IN VBAT GSM_PAM_IN C625 C626 R604 VMOD_EN TX_PWR BAND_SEL2 TX_EN BAND_SEL1 C627 C628 C629 C630 C631 10-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 60 Flow Chart of Troubleshooting 10-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 61: Reference Data

    PS : Pilot Symbol QPSK: Quadrature Phase Shift Keying RS : Reed-Solomon SI : Service Information TDM : Time Division Multiplexing TS : Transport Stream 11-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 62 ⓒ This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. Code No.: GH68-10801A 2006. 07. Rev.1.0...
