ESKUTE Netuno Installation Manual

Netuno E-Mountain Bike Installation Guide

LED Display Installation Instruction

1. Select the CR-V5mm hexagonal wrench (the
Allen Key) in the tool kit that comes with the
e-bike, and remove the screw in the center
of the standpipe;
4. Adjust the display, put the screw back, and
tighten it to the firmest state to ensure safe
riding.
When open the bike's carton box, take out E-bike and use tools to cut off the package strings.

1 Install the Handlebar

1.1 Use inner hexagon tool to loosen
the stem cover and don't tighten
all bolts immediately before
adjusting the handlebar in a
property angel and position.

2 Install Front Wheel

2.1 Take out the front fork protector
from the front fork (Please note:
Front fork protector is used to
prevent the forks from
being deformed during transport.
It belongs to the packing material.
You can just throw away this
accessory!)
2. Remove the top four protection rings and
protective lid;
5. Put the protective lid on the display;
Discard
3. Install the display to the stem.
6. Tighten the screws on both sides to
complete the installation of the
display.
1.2 Then tighten with tool.
2.2 Take out the quick release
from wheel and unscrew
the bolt from the
quick release.
