- Page 1 FlinFuzion Solar Hybrid Inverter FlinFuzion Solar Hybrid Inverter 3kVA-24V & 5kVA-48V USER MANUAL Version: 1.1...
-
Page 2: Table Of Contents
FlinFuzion Solar Hybrid Inverter Table Of Contents ABOUT THIS MANUAL ............................1 Purpose ................................1 Scope ................................1 SAFETY INSTRUCTIONS ........................... 1 INTRODUCTION ..............................2 Features ................................2 Basic System Architecture ..........................2 Product Overview ............................. 3 INSTALLATION ..............................4 Unpacking and Inspection.......................... -
Page 3: About This Manual
FlinFuzion Solar Hybrid Inverter ABOUT THIS MANUAL Purpose This manual describes the assembly, installation, operation and troubleshooting of this unit. Please read this manual carefully before installations and operations. Keep this manual for future reference. Scope This manual provides safety and installation guidelines as well as information on tools and wiring. SAFETY INSTRUCTIONS WARNING: This chapter contains important safety and operating instructions. -
Page 4: Introduction
FlinFuzion Solar Hybrid Inverter INTRODUCTION This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications. -
Page 5: Product Overview
FlinFuzion Solar Hybrid Inverter Product Overview 1. LCD display 2. Status indicator 3. Charging indicator 4. Fault indicator 5. Function buttons 6. Power on/off switch 7. AC input 8. AC output 9. PV input 10. Battery input 11. Circuit breaker 12. -
Page 6: Installation
FlinFuzion Solar Hybrid Inverter INSTALLATION Unpacking and Inspection Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should have received the following items inside of package: The unit x 1 User manual x 1 ... -
Page 7: Battery Connection
FlinFuzion Solar Hybrid Inverter Install the unit by screwing two screws. It’s recommended to use M4 or M5 screws. Battery Connection CAUTION: For safety operation and regulation compliance, it’s requested to install a separate DC over-current protector or disconnect device between battery and inverter. It may not be requested to have a disconnect device in some applications, however, it’s still requested to have over-current protection installed. - Page 8 FlinFuzion Solar Hybrid Inverter 4. Connect all battery packs as below chart. 5. Insert the battery wires flatly into battery connectors of inverter and make sure the bolts are tightened with torque of 2 Nm in clockwise direction. Make sure polarity at both the battery and the inverter/charge is correctly connected and conductors are tightly screwed into the battery terminals.
-
Page 9: Ac Input/Output Connection
FlinFuzion Solar Hybrid Inverter AC Input/Output Connection CAUTION!! Before connecting to AC input power source, please install a separate AC breaker between inverter and AC input power source. This will ensure the inverter can be securely disconnected during maintenance and fully protected from over current of AC input. The recommended spec of AC breaker is 32A for 3KVA and 50A for 5KVA. -
Page 10: Pv Connection
FlinFuzion Solar Hybrid Inverter 5. Make sure the wires are securely connected. CAUTION: Appliances such as air conditioner are required at least 2~3 minutes to restart because it’s required to have enough time to balance refrigerant gas inside of circuits. If a power shortage occurs and recovers in a short time, it will cause damage to your connected appliances. -
Page 11: Final Assembly
FlinFuzion Solar Hybrid Inverter 3. Fix PV wire cover to the inverter with supplied screws as shown in below chart. 4. Check correct polarity of wire connection from PV modules and PV input connectors. Then, connect positive pole (+) of connection wire to positive pole (+) of PV input connector. Connect negative pole (-) of connection wire to negative pole (-) of PV input connector. -
Page 12: Operation
FlinFuzion Solar Hybrid Inverter OPERATION Power ON/OFF Side view of unit Once the unit has been properly installed and the batteries are connected well, simply press On/Off switch (located on the button of the case) to turn on the unit. Operation and Display Panel The operation and display panel, shown in below chart, is on the front panel of the inverter. -
Page 13: Lcd Display Icons
FlinFuzion Solar Hybrid Inverter LCD Display Icons Icon Function description Input Source Information Indicates the AC input. Indicates the PV input Indicate input voltage, input frequency, PV voltage, charger current (if PV in charging for 3K models), charger power, battery voltage. Configuration Program and Fault Information Indicates the setting programs. - Page 14 FlinFuzion Solar Hybrid Inverter In battery mode, it will present battery capacity. Load Percentage Battery Voltage LCD Display < 1.85V/cell 1.85V/cell ~ 1.933V/cell Load >50% 1.933V/cell ~ 2.017V/cell > 2.017V/cell < 1.892V/cell 1.892V/cell ~ 1.975V/cell Load < 50% 1.975V/cell ~ 2.058V/cell >...
-
Page 15: Lcd Setting
FlinFuzion Solar Hybrid Inverter LCD Setting After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press “UP” or “DOWN” button to select setting programs. And then, press “ENTER” button to confirm the selection or ESC button to exit. - Page 16 FlinFuzion Solar Hybrid Inverter 60A (default) Appliances (default) If selected, acceptable AC input voltage range will be within 90-280VAC. AC input voltage range If selected, acceptable AC input voltage range will be within 170-280VAC. AGM (default) Flooded Battery type User-Defined If “User-Defined”...
- Page 17 FlinFuzion Solar Hybrid Inverter Available options in 3KVA model: 22.0V 22.5V 23.0V (default) 23.5V 24.0V 24.5V 25.0V 25.5V Setting voltage point back to utility source when selecting “SBU priority” or Available options in 5KVA model: “Solar first” in program 01. 46V (default) Available options in 3KVA model: Battery fully charged...
- Page 18 FlinFuzion Solar Hybrid Inverter 26.5V 27V (default) 27.5V 28.5V Available options in 5KVA model: Battery fully charged 54V (default) If this inverter/charger is working in Line, Standby or Fault mode, charger source can be programmed as below: Charger source priority: Utility first Utility will charge battery as first priority.
- Page 19 FlinFuzion Solar Hybrid Inverter Solar first Solar energy will charge battery as first priority. Utility will charge battery only when solar energy is not available. Solar and Utility (default) Solar energy and utility will charge battery at the same time. Only Solar Solar energy will be the only charger source no matter utility is...
- Page 20 FlinFuzion Solar Hybrid Inverter 5KVA default setting: 56.4V If self-defined is selected in program 5, this program can be set up. Setting range is from 25.0V to 31.5V for 3KVA model and 48.0V to 61.0V for 5KVA model. Increment of each click is 0.1V. 3KVA default setting: 27.0V 5KVA default setting: 54.0V Floating charging voltage...
-
Page 21: Display Setting
FlinFuzion Solar Hybrid Inverter 60min (default) Setting range is from 5min to 900min. Increment of each click is 5min. Battery equalized time 120min (default) Setting range is from 5min to 900 min. Increment of each click is 5 min. Battery equalized timeout 30days (default) Setting range is from 0 to 90 days. - Page 22 FlinFuzion Solar Hybrid Inverter PV current = 2.5A PV current PV power = 500W PV power AC and PV charging current=50A PV charging current=50A Charging current AC charging current=50A...
- Page 23 FlinFuzion Solar Hybrid Inverter AC and PV charging power=500W PV charging power=500W Charging power AC charging power=500W Battery voltage=25.5V, output voltage=230V Battery voltage and output voltage Output frequency=50Hz Output frequency Load percent=70% Load percentage...
- Page 24 FlinFuzion Solar Hybrid Inverter When connected load is lower than 1kVA, load in VA will present xxxVA like below chart. Load in VA When load is larger than 1kVA (≧1KVA), load in VA will present x.xkVA like below chart. When load is lower than 1kW, load in W will present xxxW like below chart.
-
Page 25: Operating Mode Description
FlinFuzion Solar Hybrid Inverter Operating Mode Description Operation mode Description LCD display Charging by utility and PV energy. Standby mode / Power saving mode Note: Charging by utility. *Standby mode: The inverter is not turned on yet but at this No output is supplied by the time, the inverter can charge unit but it still can charge... - Page 26 FlinFuzion Solar Hybrid Inverter Operation mode Description LCD display Charging by utility and PV energy. The unit will provide output power from the mains. It will also charge the battery at line mode. Charging by utility. If “solar first” is selected as output source priority and solar energy is not sufficient to provide the load, solar energy and the utility will provide the loads and charge the battery at the...
-
Page 27: Battery Equalization Description
FlinFuzion Solar Hybrid Inverter Power from PV energy only. The unit will provide output Battery Mode power from battery and PV power. Battery Equalization Description Equalization function is added into charge controller. It reverses the buildup of negative chemical effects like stratification, a condition where acid concentration is greater at the bottom of the battery than at the top. - Page 28 FlinFuzion Solar Hybrid Inverter However, in Equalize stage, when battery equalized time is expired and battery voltage doesn’t rise to battery equalization voltage point, the charge controller will extend the battery equalized time until battery voltage achieves battery equalization voltage. If battery voltage is still lower than battery equalization voltage when battery equalized timeout setting is over, the charge controller will stop equalization and return to float stage.
-
Page 29: Fault Reference Code
FlinFuzion Solar Hybrid Inverter Fault Reference Code Fault Code Fault Event Icon on Fan is locked when inverter is off. Over temperature Battery voltage is too high Battery voltage is too low Output short circuited or over temperature is detected by internal converter components. -
Page 30: Clearance And Maintenance For Anti-Dust Kit
FlinFuzion Solar Hybrid Inverter CLEARANCE AND MAINTENANCE FOR ANTI-DUST KIT Overview Every inverter is already installed with anti-dusk kit from factory. Inverter will automatically detect this kit and activate internal thermal sensor to adjust internal temperature. This kit also keeps dusk from your inverter and increases product reliability in harsh environment. -
Page 31: Specifications
FlinFuzion Solar Hybrid Inverter SPECIFICATIONS Table 1 Line Mode Specifications INVERTER MODEL 3KVA 5KVA Input Voltage Waveform Sinusoidal (utility or generator) Nominal Input Voltage 230Vac 170Vac±7V (UPS); Low Loss Voltage 90Vac±7V (Appliances) 180Vac±7V (UPS); Low Loss Return Voltage 100Vac±7V (Appliances) High Loss Voltage 280Vac±7V High Loss Return Voltage... - Page 32 FlinFuzion Solar Hybrid Inverter Table 2 Inverter Mode Specifications INVERTER MODEL 3KVA 5KVA Rated Output Power 3KVA/3KW 5KVA/5KW Pure Sine Wave Output Voltage Waveform 230Vac±5% Output Voltage Regulation 50Hz Output Frequency Peak Efficiency Overload Protection 5s@≥150% load; 10s@110%~150% load 2* rated power for 5 seconds Surge Capacity Nominal DC Input Voltage 24Vdc...
- Page 33 FlinFuzion Solar Hybrid Inverter Table 3 Charge Mode Specifications Utility Charging Mode INVERTER MODEL 3KVA 5KVA Charging Algorithm 3-Step AC Charging Current (Max) 60Amp (@V =230Vac) Bulk Charging Flooded Battery 29.2 58.4 Voltage AGM / Gel Battery 28.2 56.4 Floating Charging Voltage 27Vdc 54Vdc Battery Voltage, per cell...
-
Page 34: Trouble Shooting
FlinFuzion Solar Hybrid Inverter TROUBLE SHOOTING Problem LCD/LED/Buzzer Explanation / Possible cause What to do Unit shuts down LCD/LEDs and buzzer automatically will be active for 3 The battery voltage is too low 1. Re-charge battery. during startup seconds and then (<1.91V/Cell) 2. -
Page 35: Appendix: Approximate Back-Up Time Table
FlinFuzion Solar Hybrid Inverter PV input voltage is beyond the Reduce the number of PV Fault code 59 specification. modules in series. Appendix: Approximate Back-up Time Table Model Load (VA) Backup Time @ 24Vdc 100Ah (min) Backup Time @ 24Vdc 200Ah (min) 1100 1200 1500...
