- Page 1 Englewood Small Cell Model: SCE4255W Quick Installation Guide Manufacture By: Sercomm Corporation 8F, No. 3-1, YuanQu Street, Nankang, Taipei 115, Taiwan, R.O.C.
-
Page 3: Table Of Contents
Table of Contents CHAPTER 1 INTRODUCTION ....................1 Package Contents ......................1 Key Feature ........................1 LEDs ........................... 2 Front & Rear Panel ......................3 CHAPTER 2 INITIAL INSTALLATION................5 CHAPTER 3 SPECIFICATIONS .................... 6 General Specification ......................6 RF Characteristics ......................6 Safety Information...................... -
Page 5: Chapter 1 Introduction
Package Contents Package will include following items: 1 x Englewood SCE4255W Device 1 x AD/DC Power Supply Adapter If any of the above items are damaged or missing, please contact your dealer immediately. Key Feature ... -
Page 6: Leds
LEDs Englewood has 4 LED indicators: Power, LTE (Small cell), and WAN. Table below describes the definition of each of Englewood LED: Description Steady ON Blinking Power(Green) Device is Power On Device is Off or No power LTE(Green/Red) Green -Connect Red - Alarm No LTE service to (different flash... -
Page 7: Front & Rear Panel
Front & Rear Panel Front Panel Interface Panel... - Page 8 Power Input: 12 Vdc, 2.5A, Power Jack to Power Adaptor External GPS connector Lan port input for console configuration Wan port for backhaul connect Aside Panel Rest Factory reset button SFP slot for install fiber SFP...
-
Page 9: Chapter 2 Initial Installation
Chapter 2 Initial Installation SCE4255W is designed for Plug-n-Play (PnP) and self-configure which not require any soft- ware installation to use. When device power on the device, it will start scanning and search for valid LTE backhaul donor eNB and begin the device Plug PnP and provision processes. The PnP and provision process will take approximate 6~7 min. -
Page 10: Chapter 3 Specifications
Chapter 3 Specifications General Specification Connectivity 4 x Internal Antennas Ethernet or Fiber wired connection Power Supply External Power Adapter: Input: AC100～240V~1.6A, 50Hz/60Hz, 0.9A Max. Output: 12 Vdc, 2.5A Operating Requirement Operating Temp. 0ºC to 40ºC Storage Temp. -5ºC to 45ºC Operating Humidity 5% to 90% Non-Condensing Storage Humidity 5% to 95% Non-Condensing Reset button... - Page 11 Regulatory Requirements FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 12: Safety Information
Safety Information All instructions, warning and caution statements that accompany this equipment must be strictly followed at all times to ensure its safe use. Observe all warning and caution symbols that are fixed to this equipment. This electrical equipment is designed with the utmost care for the safety of those who install and use it. - Page 13 At least one other trained person must be in attendance, who can immediately and safely disconnect the system if necessary. This second person must be trained in first aid for emergency purposes Some parts of all electrical installations are energized. Failure to follow safe work Practices and the safety warnings may lead to bodily injury and property damage.
-
Page 14: Device Surface Cleaning
Device Surface Cleaning You may clean the device case using a cloth dampened with mild liquid detergent (such as Dawn) and water. Always unplug/disconnect power before apply any cleaning to Device. Warning Do not submerse the Device or its accessories in water or allow water to enter into the case;... -
Page 15: Accessories
Accessories Item Description AC/DC Adapter (without power core) AC100～240V~0.9A, 50Hz/60Hz auto switching, 12 V DC, 2.5A...
