- Page 1 SOHO MagicBox Small Cell Model: SRE4105T Quick Installation Guide Manufacture By: Sercomm Corporation 8F, No. 3-1, YuanQu Street, Nankang, Taipei 115, Taiwan, R.O.C.
-
Page 3: Table Of Contents
Table of Contents CHAPTER 1 INTRODUCTION ....................1 Package Contents ......................1 Key Feature ........................1 LEDs ........................... 2 Front & Rear Panel ......................3 CHAPTER 2 INITIAL INSTALLATION................4 Device Start up Procedure ....................4 CHAPTER 3 SPECIFICATIONS .................... 5 General Specification ...................... -
Page 5: Chapter 1 Introduction
Chapter 1 Introduction SOHO MagicBox is an indoor, self-configuring small cell device that will be used to ensure Increased LTE Data Speeds using Sprint network and Increased LTE coverage at the customer premises. Package Contents Package will include following items:... -
Page 6: Leds
LEDs SOHO MagicBox has 5 LED indicators: Power, GPS, Service(Relay), LTE(Femto), and Info. Table below describes the definition of each of SOHO MagicBox LED: Description Steady ON Blinking Power(Green) Device is Power On Device is Off or No power GPS(Green) -
Page 7: Front & Rear Panel
Front & Rear Panel Front Panel Info Button Info Button for LED Status & Device Reset Back Panel Power Input: 12 Vdc, 2.5A, Power Jack to Power Adaptor... -
Page 8: Chapter 2 Initial Installation
Chapter 2 Initial Installation SRE4105T is designed for Plug-n-Play(PnP) and self-configure which not require any software installation to use. When device power on the device, it will start scanning and search for valid LTE backhaul donor eNB and begin the device Plug PnP and provision processes. The PnP and provision process will take approximate 6~7 min. -
Page 9: Chapter 3 Specifications
Chapter 3 Specifications General Specification Connectivity 12x Internal Antennas No wired connection Power Supply External Power Adapter: Input: AC100～240V~1.6A, 50Hz/60Hz, 0.9A Max. Output: 12 Vdc, 2.5A Operating Requirement Operating Temp. -5ºC to 40ºC Storage Temp. -5ºC to 45ºC Operating Humidity 5% to 90% Non-Condensing Storage Humidity 5% to 95% Non-Condensing Reset button Reset &... -
Page 10: Regulatory Requirements
Regulatory Requirements FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 11: Safety Information
Safety Information All instructions, warning and caution statements that accompany this equipment must be strictly followed at all times to ensure its safe use. Observe all warning and caution symbols that are fixed to this equipment. This electrical equipment is designed with the utmost care for the safety of those who install and use it. - Page 12 At least one other trained person must be in attendance, who can immediately and safely disconnect the system if necessary. This second person must be trained in first aid for emergency purposes Some parts of all electrical installations are energized. Failure to follow safe work Practices and the safety warnings may lead to bodily injury and property damage.
-
Page 13: Device Surface Cleaning
Device Surface Cleaning You may clean the device case using a cloth dampened with mild liquid detergent (such as Dawn) and water. Always unplug/disconnect power before apply any cleaning to Device. Warning Do not submerse the Device or its accessories in water or allow water to enter into the case;... -
Page 14: Accessories
Accessories Item Description AC/DC Adapter (without power core) 919252126AP AC100 ～ 240V~0.9A, 50Hz/60Hz auto switching, 12 V DC, 2.5A...
