HG 3,5
HG 6,5
HG 4,1
HG 6,6
HG 5
HG 10
Download PDF version from www.Dynaset.com
USER MANUAL
HYDRAULIC GENERATORS
HG 10,1
HG 15,1
HG 12
HG 20,1
HG 12,1
HG 26
HG 30,1
HG 55
HG 35
HG 65
HG 45
HG 80

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HG 3,5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dynaset HG 3,5

Summary of Contents for Dynaset HG 3,5

  • Page 1 HG 3,5 HG 6,5 HG 10,1 HG 15,1 HG 30,1 HG 55 HG 4,1 HG 6,6 HG 12 HG 20,1 HG 35 HG 65 HG 5 HG 10 HG 12,1 HG 26 HG 45 HG 80 Download PDF version from www.Dynaset.com...
  • Page 3 Please visit on our website and social media channels for the latest news and updates. www.dynaset.com info@dynaset.com www.facebook.com/dynaset www.youtube.com/dynasetoy www.twitter.com/Dynaset_ofcl www.instagram.com/dynaset_official Subscribe to our newsletter. Follow the QR code! Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 4: Table Of Contents

    4.2.2. INSTALLING DYNASET VALVES 4.2.3. CONNECTING HYDRAULIC HOSES 4.2.4. HYDRAULIC FLUIDS 4.3. INSTALLING HG HYDRAULIC GENERATOR 4.4. GROUNDING 4.5. IP CODE REQUIREMENTS Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 5 6.6. TROUBLESHOOTING MANUFACTURER’S LIMITED WARRANTY PRODUCT DISPOSAL DECLARATION OF CONFORMITY TECHNICAL SPECIFICATIONS 10.1. 50HZ IP23 SUPER COMPACT MODELS 10.2. 50HZ IP54 MODELS Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 6 Picture 40: Adjusting the RMP-cartridge ........................53 Picture 41: Adjusting the RPM-cartridge without installation valve 1 ................54 Picture 42: Adjusting the RPM-cartridge without installation valve 2 ................55 Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 7: General

    Electric equipment“. 11. Single phase power output socket type on the HG Hydraulic Generator. READ CHAPTER „1.9.1. Single phase socket plug type“. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 8: Type Plate

    8. Single Phase: Main voltage/ current. 4. Minimum hydraulic flow 9. Manufacturer’s contact 5. Maximum hydraulic pressure information 6. Production month / year Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 9: Hg's Line-Up

    6. C: HG 45 kVA - 80 kVA 3. F: HG 12 kVA 7. W: HG IP54 generators 4. F: HG 19 kVA Picture 3: HG Hydraulic Generator line-up Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 10: Hg's Main Components

    HG Hydraulic Generator’s IP class is marked into the products identification key. From the following chart you can check your IP class information. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 11 HYDRAULIC GENERATORS GENERAL Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 12: Voltage And Frequency

    The pictures are based on information on the internet page: http://www. worldstandards.eu/electricity/plugs-and-sockets. Picture 5: Single phase voltage and frequency map Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 13: Hydraulic Equipment

    Pressure release valve prevents oil pressure raising too high. Add-on valves (V/W) As an addition for traditional valve options, Dynaset offers HG Hydraulic Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 14: Electric Equipment

    30 RCD has a test button to test its proper operation in fault condition. When the Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 15 If you have a need for other electrical equipment for your generator please contact us for more information about the possibilities of upgrading your product. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 16: Single Phase Socket Plug Type

    220-240 16 A socket: L Grounded 220-240 Grounded 220-240 C & N Grounded 220-240 C & O (Unsafe with E & F) Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 17: Three Phase Socket Plug Type

    Three-phase socket plugs are delivered according to the IEC60309 and NEMA standards. Few common models are presented in the pictures 9 and 10. Picture 9: IEC60309 three phase sockets and plugs Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 18: Picture 10: Nema Three Phase Sockets And Plugs

    3p + n + e 400 V 32 A 50-60 3p + n + e 125/250V 30 A 50-60 3p+e 120/208V 30 A 50-60 4p+e Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 19: Safety

    HIGH PRESSURE OIL! Can cause severe injuries. Always wear appropriate clothing and safety equipment. The hydraulic system is pressurized up to 420bar. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 20: Safety Equipment

    When working with HG Hydraulic Generator or accessories, wear appropriate protective clothing, safety goggles, gloves, ear protection. 2.3. OPERATING SAFETY ATTENTION! Do not exceed the maximum load. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 21: Maintenance Safety

    When carrying out any maintenance to HG Hydraulic Generator keep the components of the system clean. This is to ensure safe, reliable and long life operation of your equipment. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 22: Warning Labels

    Clean surface with solvent detergent before attaching labels. USE EAR PROTECTION READ OPERATING BEWARE OF HOT AND SAFETY GOGGLES. INSTRUCTIONS. SURFACE. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 23: Operating Principle

    ± 5%. The response time of the voltage control is less than 1 second. THREE PHASE GENERATORS 3-phase generators are equipped either with compound or electronic voltage regulator. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 24: Performance Of Automatic Frequency Control

    READ CHAPTER „10. TECHNICAL SPECIFICATIONS“. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 25: Picture 13: Pressure/Power Chart

    HYDRAULIC GENERATORS OPERATING PRINCIPLE Picture 13: Pressure/Power chart Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 26 HYDRAULIC GENERATORS OPERATING PRINCIPLE Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 27: Installation

    If you are unsure of the hydraulic system, please contact the manufacturer of your base machine. Next three paragraphs describe the hydraulic systems in more detail. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 28: Picture 14: Open Centre Hydraulic System With Load Sensing Variable Displacement Pump

    In Load Sensing variable-displacement pump, the flow rate and output pressure adjusts automatically based on the load of the hydraulic system. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 29: Picture 15: Connection Figure For Open Centre Hydraulic System With Load Sensing Variable Displacement Pump

    2.1. DYNASET PC-SAE pressure compensator 6. Oil filter 2.2. DYNASET LSV Load 7. Oil tank Sensing valve 3. Base machine’s variable displacement pump Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 30: Picture 16: Closed Centre Hydraulic System With Load Sensing Variable Displacement Pump

    In Load Sensing variable-displacement pump, the flow rate and output pressure adjusts automatically based on the load of the hydraulic system. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 31: Picture 17: Connection Figure For Closed Centre Hydraulic System With Load Sensing Variable Displacement Pump

    2. DYNASET LSV Load Sensing valve 6. Oil cooler 3. DYNASET Shuttle valve 7. Oil filter 4. Base machine’s variable 8. Oil tank displacement pump Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 32: Picture 18: Hydraulic System With Fixed Displacement Pump

    Every stroke of the hydraulic motor moves the same amount of oil. The output flow is function of the motor’s rpm and pump’s displacement. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 33: Picture 19: Connection Figure For Hydraulic System With Fixed Displacement Pump

    2.1. DYNASET PC-SAE pressure compensator 6. Oil filter 2.2. DYNASET LSV Load 7. Oil tank Sensing valve 3. Base machine’s fixed displacement pump Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 34: Dynaset Valves

    Picture 22: Add-on valves DYNASET Add-on valves are made for easy and compact installations for all hydraulic systems to replace LSV and Pressure relief valves. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 35: Installing A Dynaset Hydraulic Product

    Pressure (P) and return (T) lines of a hydraulic system are connected to the DYNASET units corresponding hydraulic ports. Picture 24: Installing hydraulic hoses Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 36: Picture 25: P-Line Operational Hydraulic Flow

    Generally DYNASETs return line is to be connected directly to the return line of a hydraulic system. PRESSURE < 5 bar Picture 27: Return line (T) pressure must be under 5 bars. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 37: Hydraulic Fluids

    NOTE! Sufficient venting is important. Generators components heat up under use. Maintain the generator accordingly and keep the vents open and clean. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 38: Grounding

    Ground the HG from the marked grounding spot in generators frame. The grounding spot varies between different generator models. Picture 29: HG Hydraulic Generator grounging, in picture HG 6,5 Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 39: Ip Code Requirements

    Hz-position and check the frequency from each socket. Frequency value should be 50 Hz ± Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 40: K Cable Model

    Cable connection models don’t have any electrical safety device such as fuses and residual current device circuit breakers. Picture 33: HG 40 cable model Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 41: Cable Connections

    If the generator series that you are looking for is not found on this guide, take contact to dynaset service at service@dynaset.com for help Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 42: Super Compact Series E, F Three Phase Generators

    110 / 220, 115 / 230, 120 / 240, 127 / 254 H, I, J 60 Hz 120 / 240, 127 / 254, 133 / 266, 139 / 277 H, I, J Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 43 100 / 200, 120 / 240, 127 / 254, 133 / 266, 139 / 277 H, I, J ATTENTION! Connections variate with different generator versions and series. Check your model and follow the specific instructions. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 44: Series C Three Phase Generators (40Kva Upwards)

    110 / 220, 115 / 230, 120 / 240, 127 / 254 60 Hz 120 / 240, 127 / 254, 133 / 266, 139 / 277 Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 45 100 / 200, 120 / 240, 127 / 254, 133 / 266, 139 / 277 ATTENTION! Connections variate with different generator versions and series. Check your model and follow the specific instructions. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 46 HYDRAULIC GENERATORS INSTALLATION Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 47: Operation

    HG can be started by opening the hydraulic flow to it. 3. Connect your appliance to the generator. Picture 35: Connecting load to the HG Hydraulic Generator Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 48: Stopping The Hg Hydraulic Generator

    100% POWER TAKEOFF, P % t,ºC -20 -10 70 75 AMBIENT TEMPERATURE Picture 37: Power take off in higher temperatures Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 49: Maintenance

    Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 50: Cleaning The Hg

    3. After cleaning the generator, place screens/covers back on and secure them with appropriate screws. Picture 38: Cleaning the HG Hydraulic Generator Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 51: Test Safety Devices

    If a fault condition trips the safety device, the fault has to be cleared before the switch can be set back up. Bypassing or removing safety devices to clear the problem is strictly forbidden. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 52: Output Frequency Adjusting

    ATTENTION! Do not adjust the generator when an appliance is connected to it. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 53: Picture 40: Adjusting The Rmp-Cartridge

    Picture 40: Adjusting the RMP-cartridge If a frequency measurement option is not available, adjustments can be made by measuring the output voltage. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 54: Picture 41: Adjusting The Rpm-Cartridge Without Installation Valve 1

    4. Then turn the screw B counter-clockwise for a another quarter of revolution. 5. Lock the setting with the locknut A tightening it to 10 Nm. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 55: Picture 42: Adjusting The Rpm-Cartridge Without Installation Valve 2

    HYDRAULIC GENERATORS MAINTENANCE Picture 42: Adjusting the RPM-cartridge without installation valve 2 Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 56: Troubleshooting

    HIGH FREQUENCY AT Too high rotation speed. Check whether the hydraulic flow and LOAD pressure are sufficient. Adjust RPM- cartridge if necessary. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 57 Ensure proper grounding cable grounding. installation. HYDRAULIC GENERATOR Bearing failure. Replace broken/worn bearing. ABNORMAL NOISE FROM GENERATOR Broken fan. Replace broken/worn fan. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 58 HYDRAULIC GENERATORS MAINTENANCE Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 59: Manufacturer's Limited Warranty

    DYNASET OY or to other location authored by DYNASET OY. Shipment documents must contain: Purchaser’s name and contact information Receipt of original purchase WRN code Problem description Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 60 • Product that is used in exceptional conditions, considered to cause excessive wear and tear. • Faults caused by nature phenomenon’s like flood, thunder, etc. © DYNASET OY, all rights reserved Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 61: Product Disposal

    NOTE! Always act according to the waste legislation, regulations and recommendations in waste disposal and waste recycling issued by your local authorities. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 62 HYDRAULIC GENERATORS PRODUCT DISPOSAL Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 63: Declaration Of Conformity

    If the device has been modified by someone other than the manufacturer or without the manufacturer’s permission, this declaration is not valid Timo Nieminen R&D Manager Menotie 3, 33470 Ylöjärvi, Finland 01.07.2019 Dynaset Oy | Menotie 3, 33470 Ylöjärvi | puh. 03 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 64 HYDRAULIC GENERATORS DECLARATION OF CONFORMITY Dynaset Oy | Menotie 3, 33470 Ylöjärvi | puh. 03 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 65: Technical Specifications

    HYDRAULIC GENERATORS TECHNICAL SPECIFICATIONS 10. TECHNICAL SPECIFICATIONS Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 66: 50Hz Ip23 Super Compact Models

    HYDRAULIC GENERATORS TECHNICAL SPECIFICATIONS 10.1. 50HZ IP23 SUPER COMPACT MODELS HG3,5S , HG5S HG6,5E , HG10E , HG12F HG19F Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 67 BSP 1/2” HG10E-E400SS23-49-VF BSP 1/2” BSP 1/2” BSP 1/2” BSP 1/2” HG12F-E400SS23-54-VF HG19F-E400SS23-63-VF BSP 1/2” BSP 1/2” HG19F-E400SS23-79-VF BSP 3/4” BSP 1” Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 68 HYDRAULIC GENERATORS TECHNICAL SPECIFICATIONS HG26G, HG35G HG45C, HG65C , HG80C Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 69 BSP 1” HG35G-E400SS23-100-K BSP 3/4” BSP 3/4” HG45C-E400SS23-90-K BSP 1” BSP 1” BSP 1” BSP 1” HG65C-E400SS23-120-K HG80C-E400SS23-180-K BSP 1” BSP 1” Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 70 * Models are also available by request for other 50 Hz voltage systems. ** Depending on the hydraulic fluid. VF = Model with F-type socket(s) Other options available by request. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 71 * Models are also available by request for other 50 Hz voltage systems. ** Depending on the hydraulic fluid. VF = Model with F-type socket(s) Other options available by request. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 72 * Models are also available by request for other 50 Hz voltage systems. ** Depending on the hydraulic fluid. Other options available by request. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 73 * Models are also available by request for other 50 Hz voltage systems. ** Depending on the hydraulic fluid. Other options available by request. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...

  • Page 74: 50Hz Ip54 Models

    HYDRAULIC GENERATORS TECHNICAL SPECIFICATIONS 10.2. 50HZ IP54 MODELS HG4,1W , HG6,6W , HG10,1W , HG12,1W HG15,1W , HG20,1W HG30,1W Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 75 BSP 1/2” BSP 1/2” BSP 1/2” HG12,1W-E400SS54-54-VF HG15,1W-E400SS54-63-VF BSP 1/2” BSP 1/2” HG20,1W-E400SS54-78-VF BSP 3/4” BSP 1” HG30,1W-E400SS54-90-K BSP 1” BSP 1” Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 76 * Nominal current 1~phase / 3~phase /phase must not exeed maximum load. ** Depending on the hydraulic fluid. VF = Model with F-type socket(s) Other options available by request. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 77 * Nominal current 1~phase / 3~phase /phase must not exeed maximum load. ** Depending on the hydraulic fluid. VF = Model with F-type socket(s) Other options available by request. Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 78 HYDRAULIC GENERATORS TECHNICAL SPECIFICATIONS Dynaset Oy | Menotie 3, FI-33470 Ylöjärvi, Finland | tel: +358 3 3488 200 | info@dynaset.com | www.dynaset.com...
  • Page 79 © DYNASET OY, all rights reserved...
  • Page 80 Menotie 3 FI-33470 Ylöjärvi, Finland tel: +358 3 3488 200 info@DYNASET.com ELECTRICITY MAGNET POWER HG Hydraulic Generator HMG PRO Hydraulic Magnet Generator HGV POWER BOX Variable Hydraulic Generator System MAG Lifting Magnet HGV Variable Hydraulic Generator System HMAG PRO Hydraulic Magnet...

This manual is also suitable for:

Hg 4,1Hg 5Hg 6,5Hg 6,6Hg 10Hg 10,1 ... Show all
