Page 19
1. Interface Introduction (1) Sewing Data Input Interface Data input interface is shown at right and please refer to the following list for detailed function description. 1 1 2 2 1 1 8 8 1 1 3 3 1 1 1 1 1 1 0 0 1 1 4 4 1 1 7 7...
Page 20
Icon Function Remarks Set Upper-Thread Tension (S51, S52 and S56 will be influenced S52, S55, S56) by the data switch of sewing. For the pattern from No.1~ No.26, this key means to set left Set/Return to Left Over-edging over-edging width; while for the Width patterns from No.27~ No.30, this (...
Page 21
(2) Sewing Interface Press to enter the sewing interface shown at right. Please refer to the following list for detailed function description. 1 1 2 2 1 1 3 3 1 1 1 1 1 1 0 0 1 1 6 6 1 1 4 4 1 1 5 5 1 1 7 7...
Page 22
Function Remarks Icon Pattern No. Display Upper-thread Tension Setting Left Over-edging Width Left Width of Knife Groove Right Width of Knife Groove Length of Cloth Cutting Single Stitching/ Double Stitching Numbers of Basting Total Number of Stitches Current Sewing Speed Counter Value : Sewing Counter : No.
2. Presser Foot Type Selection (1) Display data input interface Only under the data input interface (orange), can user change the contents of setting. Under the sewing interface (blue), press READY key to display the data input interface. (2) Enter the interface for selecting presser foot type Press Presser Foot Type Selection Key (A) to display the interface for selecting the presser...
Page 24
(4) Confirm Presser Foot Type Press to close the interface and finish the change. Pressing is to quit directly – 23 –...
3. Sewing Shape Selection Press to enter sewing shape selection interface. (1) Select the 1st bar-tacking shape There are five common 1 bar-tacking shapes, which are Square Type, Radial Type, Eyelet Type, Semi-lunar Type and the Round Type. When the parameter K04 is set to 30, another 4 types of bar-tacking section can be used, which are bar-tacking section sewing, bar-tacking with left cut, bar-tacking with right...
Page 26
(2) Finish Sewing Shape Selection Select to finish sewing shape and press to return to the main interface. Press to quit directly, without changing the sewing shape number. (3) Controlled by Parameter K04 K04 = 12 shapes K04 = 20 shapes K04 = 30 shapes Square 1, 18, 19, 20...
Page 28
4. Sewing Data Setting (1) Change Sewing Data Press to enter the sewing setting interface (as shown at right). Select the sewing data for changing; Then the system will enter the setting status. The parameters with purple background are the input type, while the parameters with blue background are the selection type Press...
Page 29
5. Mode and Parameter Setting 1 1 2 2 Press to shift between the Data Input Interface and Mode Interface (as shown at right), and detailed editing and setting operations can be carried out under this interface. Note: For some icons, user has to hold pressing to open them.
Page 30
Software Version Inquiry Keyboard Lock User Management Setting Test Mode Sewing Type Setting Brightness Adjustment Level 2 Parameter Setting Counter Setting Parameter Back-up & Recovery Play Video – 29 –...
Page 31
5.1 Level 1 Parameter Setting (1) Parameter Setting Operation Select to enter the interface for level 1 parameter setting (as shown at right). Press to quit the setting interface. When some parameters are changed, the system will display the “Modified” in the parameter setting interface.
Page 32
Select U19, and enter the interface 5.2 Level 2 Parameter Setting (1) Parameter Setting Operations Under the interface of Mode Setting Level 3, press to enter the interface for setting parameters of Level 2 (as shown in the right figure). For the operation methods, please take the description in 7.2 Level 1 Parameter Setting for reference.
Page 33
6. Change Sewing Type Press to sewing type selection interface (as shown at right). : Normal Sewing : Continuous Sewing : Cyclic Sewing After confirming the sewing type, press to end the operation. Press to display the data input interface of the selected sewing type.
Page 34
7. Test Mode Under Mode Setting Level 2 interface, press to enter the Test Mode interface (as shown at right). The function of each figure is shown as below: Name I01 Needle thread trimming I02 Down thread trimming I03 Input inspection I04 Inspection of LCD display I05 Correction of touch...
