Galvanized Storage Cabinet, Model GCAB-3015-67
Identifier Item Description
A1
Top panel
B1
Left side panel
B2
Right side panel
C1
Left rear panel
C2
Right rear panel
D1
Shelf
E1
Front leg assembly
F1
Rear leg assembly
R1
Right door
L1
Left door
I
Shelf support
#8 10mm self-tapping
J
screw
Assembly Instructions
Quantity
Product specifications:
1
1
1
Capacity per shelf = 66lbs (30kg)
1
1
Dimensions = 67in. (H) x 30in. (W) x 15in. (D)
4
1
1
Overall weight = 69lbs (~31.4kg)
1
1
16
20
~(170cm x 76cm x 38cm)
