Galvanized Storage Cabinet, Model GCAB-4415-72W
Identifier Item Description
A4
Top panel
B7
Left side panel
B8
Right side panel
C5
Left rear panel
C8
Right rear panel
D6
Shelf
E3
Front leg assembly
F3
Rear leg assembly
H2
Center panel
L3
Left door
R3
Right door
I
Shelf support
#8 10mm self-tapping
J
screw
Assembly Instructions
Quantity
Product specifications:
1
1
1
Capacity per shelf = 66lbs (30kg)
1
1
Dimensions = 72in. (H) x 44in. (W) x 15in. (D)
5
1
1
Overall weight = 96lbs (~44kg)
1
1
1
20
21
~(183cm x 112cm x 38cm)
Advertisement
Related Manuals for Vestil GCAB-4415-72W
Summary of Contents for Vestil GCAB-4415-72W
- Page 1 Galvanized Storage Cabinet, Model GCAB-4415-72W Assembly Instructions Identifier Item Description Quantity Product specifications: Top panel Left side panel Right side panel Capacity per shelf = 66lbs (30kg) Left rear panel Right rear panel Dimensions = 72in. (H) x 44in. (W) x 15in. (D)
- Page 2 Step 1: Insert the front leg assembly (E3) and rear leg assembly (F3) into the Step 2: Insert center panel (H2) into the slot in the front leg assembly and bottom end (has flange with 2 holes for screws) of the left side panel (B7) and secure it from the inside with a 10mm screw (see 1 &...
- Page 3 (you) for warranty service. Who may request service? Only a warrantee may request service. You are a warrantee if you purchased the product from Vestil or from an authorized distributor AND Vestil has been fully paid.
