- Page 1 OWNER’S MANUAL LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LCD MONITOR MODEL E2241V E2241VB E2341V E2341VG E2441V www.lg.com E2541V...
-
Page 2: Safety Precautions
Safety Precautions Please read these safety precautions carefully before using the product. Failure to follow those warnings may result in death, serious injury or damage to the Warning product or other property. Electrical Power Related Precautions Warning Use only the power cord supplied with the unit or another manufacturer authorized cord. - Failure to do so may result in fire or electrical shock or damage to the product. -
Page 3: Precautions In Installing The Product
Safety Precautions Precautions in installing the Product Warning Keep away from heat sources like electrical heaters, curdles or other open flames. - Electrical shock, fire, malfunction or deformation may occur. Keep the packing anti-moisture material or vinyl packing out of the reach of children. - Anti-moisture material is harmful if swallowed. -
Page 4: Precautions In Using/Cleaning The Product
Safety Precautions Make sure the panel faces forward and hold it with both hands to move. - If you drop the product, the damaged product can cause electric shock or fire. Contact an authorized the service center for repair. Do not place the product face down. - This may damage the TFT-LCD screen. - Page 5 Safety Precautions NOTE The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. NOTE This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules.
- Page 6 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Power Cord User's Guide/Cards 15-pin D-Sub Signal Cable DVI-D Signal Cable (To set it up, this signal cable may be (This feature is not available in all attached to this product before countries.)
-
Page 7: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor with its front facing downward on a soft cloth. Assemble the Stand Body into the Assemble the Stand Base(Front, product in the correct direction as shown in... -
Page 8: Disassembling The Stand
Connecting the Display Disassembling the stand Place the monitor face Down on the Put a cushion or soft cloth on aflat cushion or soft cloth. surface. Remove the Stand Body and Use a coin on the back of the Stand Stand Base from product in Base and turn the screw anticlock- correct direction as shown in the... -
Page 9: Positioning Your Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display -After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚... -
Page 10: Connecting With The Pc
Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable. -
Page 11: Control Panel Functions
Control Panel Functions Front Panel Controls For D-SUB and DVI input Only for HDMI input MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED"... - Page 12 Control Panel Functions SUPER ENERGY Use this button to enter SUPER ENERGY SAVING menu.For more information, refer to page 16. SAVING Button AUTO Button AUTO IMAGE ADJUSTMENT When adjusting your display settings, always press the (For D-SUB and DVI input) AUTO button on the MONITOR SETUP OSD.
-
Page 13: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. -
Page 14: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. : D-SUB(Analog signal) input DSUB : DVI-D(Digital signal) input DVI-D : HDMI signal HDMI Main menu Sub-menu Supported input Description MENU To adjust the brightness of the BRIGHTNESS... - Page 15 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description To adjust the brightness of the screen. WIDE Switch to full screen mode according to input image signal. ORIGINAL Change the input image signal ratio to original. * This function works only if input resolution is lower than monitor ratio (16:9).
- Page 16 On Screen Display(OSD) Selection and Adjustment Main menu Description To adjust the contrast of the screen. (Only HDMI input) You can set the offset level. If you select 'HIGH', the screen will be bright and if you select ‘LOW’, the screen will be dark. (only for HDMI input) * Offset? As the criteria for video signal, it is the darkest screen the monitor can...
- Page 17 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the SUPER ENERGY SAVING Button, then the main menu of the OSD appears.
- Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description Turn on the SUPER ENERGY SAVING fuction. When current setting value is ON,the SUPER SAVING color is green. Turn off the SUPER ENERGY SAVING function.Now the monitor is LED SAVING function. When current setting value is OFF,the SUPER SAVING color is gray.
- Page 19 Saving Data depends on the Panel. So,those values should be different from each panel and panel vendor. LG accumulate those values using integrated function with 10 minutes broadcast video signal. LED Saving means that how much power can be saved using WLED Panel instead of CCFL panel.
-
Page 20: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •... -
Page 21: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is • Press the AUTO button to automatically adjust incorrect. your display image to the ideal setting. • Press the AUTO button to automatically adjust On the screen your display image to the ideal setting. background, vertical bars or stripes are visible. - Page 22 CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. • Make sure to check if the video card supports Plug&Play function. The Audio function is not working Picture OK &...
-
Page 23: Specifications
Specifications E2241V/E2241VB Display TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel, Anti-Glare coating 54.6 cm visible diagonal (21.5 inch) 0.248 mm x 0.248 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. Analog,Digital : 56 Hz to 75 Hz (Automatic) HDMI : 56 Hz to 61 Hz (Automatic) Input Form Separate Sync. - Page 24 Specifications E2341V Display TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel, Anti-Glare coating 58.4 cm visible diagonal (23 inch) 0.265 mm x 0.265 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. Analog,Digital : 56 Hz to 75 Hz (Automatic) HDMI : 56 Hz to 61 Hz (Automatic) Input Form Separate Sync.
- Page 25 Specifications E2341VG Display TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel, Glare coating 58.4 cm visible diagonal (23 inch) 0.265 mm x 0.265 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. Analog,Digital : 56 Hz to 75 Hz (Automatic)
- Page 26 Specifications E2441V Display TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel, Anti-Glare coating 60.97 cm visible diagonal (24 inch) 0.277 mm x 0.277 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. Analog,Digital : 56 Hz to 75 Hz (Automatic) HDMI : 56 Hz to 61 Hz (Automatic) Input Form Separate Sync.
- Page 27 Specifications E2541V Display TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel, Anti-Glare coating 63.44 cm visible diagonal (25 inch) 0.288 mm x 0.288 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. Analog,Digital : 56 Hz to 75 Hz (Automatic) HDMI : 56 Hz to 61 Hz (Automatic) Input Form Separate Sync.
-
Page 28: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) DSUB/DVI Timing Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) Polarity(H/V) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 48.363 1024 x 768 60.123 1024 x 768 67.500... -
Page 29: Installing The Wall Mount Plate
Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor with its front facing downward on a soft cloth. Remove the Stand Body and Stand Base from product in correct direction as shown in the picture... - Page 30 <Screw Mounting Interface Dimension> Kensington Security Slot Hole spacing : (A x B) Connected to a locking cable that can be purchased separately at E2241V,E2241VB,E2341V,E2341VG: most computer stores. 75 mm x 75 mm E2441V,E2541V: 200 mm x 100 mm NOTE...
- Page 31 Make sure to read the Safety Precautions before using the product. Keep the OWNER’S MANUAL(CD) in an accessible place for furture reference. The model and serial number of the SET is ENERGY STAR is a set of power-saving located on the back or one side of the SET. guidelines issued by the U.S.Environmental Record it below should you ever need service.
