- Page 1 USER MANUAL ENGLISH Display Flood 80 SW Product code: A0320120 – Black housing A0320121 – White housing Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Display Flood 80 SW Preface Thank you for purchasing this Artecta product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 3: Table Of Contents
Display Flood 80 SW Table of contents Introduction ................................3 Before Using the Product ..........................3 Intended Use ............................... 3 LEDs Lifespan ............................... 3 Text Conventions ..............................3 Symbols and Signal Words ..........................4 Symbols on the Information Label ........................4 Safety .................................. -
Page 4: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● Artecta Display Flood 80 SW ● Schuko to pro-power cable (1,5 m) ● Barndoor ●... -
Page 5: Symbols And Signal Words
Display Flood 80 SW Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury. -
Page 6: Safety
Display Flood 80 SW Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions DANGER Danger for children For adult use only. - Page 7 Display Flood 80 SW Attention Power supply ● Before connecting the device to the power supply, make sure that the current, voltage and frequency match the input voltage, current and frequency specified on the information label on the device. ● Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the required power consumption of the device.
-
Page 8: Requirements For The User
Display Flood 80 SW Attention Do not expose the device to conditions that exceed the rated IP class conditions. This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater than 12 mm, such as fingers, and no protection against harmful ingress of water. Requirements for the User This product may be used by ordinary persons. -
Page 9: Description Of The Device
Display Flood 80 SW Description of the Device The Artecta Display Flood 80 SW is a compact yet powerful floodlight for indoor installation with an asymmetric high grade reflector with a beam angle of 95° x 105°. It features two selectable color temperatures: warm white and cold white and has a built-in, manually controllable dimmer (5 –... -
Page 10: Barndoor
Display Flood 80 SW Barndoor 12) Safety eye (barndoor) Fig. 04 Product code: A0320120 / A0320121... -
Page 11: Product Specifications
Display Flood 80 SW Product Specifications Model: Display Flood 80 SW Electrical: Input voltage: 100–240 V AC, 50/60 Hz Power consumption: 93 W PFC: 0,93 Fuse: T2 AL, 250 V Physical: Dimensions: 280 x 255 x 315 mm (L x W x H) (without accessories) Weight: 4 kg Optics:... -
Page 12: Dimensions
Display Flood 80 SW Dimensions Fig. 05 Installation Safety Instructions for Installation WARNING Incorrect installation can cause serious injuries and damage of property. If the device is installed overhead, the installation must be carried out only by instructed or skilled persons. Follow all applicable European, national and local safety regulations concerning overhead installation on supporting structures. -
Page 13: Mounting
Display Flood 80 SW Mounting The device can be mounted to a supporting structure in any orientation. Make sure that all loads are within the pre-determined limits of the supporting structure. CAUTION Restrict the access under the work area during mounting. To mount the device, follow the steps below: 01) Use a clamp to attach the device to the supporting structure, as shown in Fig. -
Page 14: Angle Adjustment
Display Flood 80 SW Angle Adjustment You can adjust the angle of the device with the 2 adjustment handles (02). 01) Turn the 2 adjustment handles (02) counterclockwise to release them. 02) Tilt the device at the desired angle (see Fig. 07). 03) Turn the 2 adjustment handles (02) clockwise to tighten them. -
Page 15: Barndoor Installation
Display Flood 80 SW Barndoor Installation The Display Flood 80 SW is delivered with a barndoor. To install the barndoor, follow the steps below: 01) Lift the color frame clip (05) and flip it backwards (see Fig. 08). 02) Insert the barndoor into the color frame holders (04) (see Fig. 09). 03) Pull the color frame clip (05) downwards (see Fig. -
Page 16: Power Linking Of Multiple Devices
Display Flood 80 SW Power Linking of Multiple Devices This device supports power linking. Power can be relayed to another device via the power OUT connector. Note that the input and the output connectors have different designs: one type cannot be connected to the other. -
Page 17: Troubleshooting
Display Flood 80 SW Troubleshooting This troubleshooting guide contains solutions to problems which can be carried out by an ordinary person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage. -
Page 18: Basic Cleaning Instructions
Display Flood 80 SW Basic Cleaning Instructions The external lens of the device must be cleaned periodically in order to optimize the light output. The cleaning schedule depends on the conditions at the site where the device is installed. When smoke or fog machines are used at the site, the device will need more frequent cleaning. -
Page 19: Deinstallation, Transportation And Storage
Display Flood 80 SW Deinstallation, Transportation and Storage Instructions for Deinstallation WARNING Incorrect deinstallation can cause serious injuries and damage of property. ● Let the device cool down before dismounting. ● Disconnect power supply before deinstallation. ● Always observe the national and site-specific regulations during deinstallation and dismounting of the device. - Page 20 ©2020 Artecta...
