  • Page 1 TUF GAMING B760M-PLUS WIFI...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... iv About this guide ......................v Package contents ....................... vi TUF GAMING B760M-PLUS WIFI specifications summary ........vi Chapter 1 Product Introduction Before you proceed ..................1-1 Motherboard overview ................. 1-2 Central Processing Unit (CPU) ..............1-9 System memory ..................

  • Page 4: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 5: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 6: Package Contents

    Package contents Check your motherboard package for the following items. 1 x TUF GAMING B760M-PLUS WIFI motherboard Motherboard Cables 2 x SATA 6Gb/s cables 1 x ASUS Wi-Fi moving antennas 1 x M.2 Rubber package Miscellaneous 1 x Screw package for M.2 SSD...
  • Page 7 TUF GAMING B760M-PLUS WIFI specifications summary Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* Intel & 12 Gen Processors ® M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Storage Intel B760 Chipset ®...
  • Page 8 TUF GAMING B760M-PLUS WIFI specifications summary Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 3 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector...
  • Page 9 TUF GAMING B760M-PLUS WIFI specifications summary Aura Sync Special Features - Aura RGB header - Addressable Gen 2 headers ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 2+ - Power Saving - Two-Way AI Noise Cancelation...
  • Page 10 • Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications. • MyASUS offers a variety of support features such as helping to troubleshoot issues, optimizing product performance, integrating ASUS software, and recovery drive creation.

  • Page 11: Chapter 1 Product Introduction

    • The pin definitions in this chapter are for reference only. The pin names depend on the location of the header/jumper/connector. • For more information on installing your motherboard, please scan the QR code below: TUF GAMING B760M-PLUS WIFI...

  • Page 12: Motherboard Overview

    Motherboard overview 24.4cm(9.6in) CPU_OPT AIO_PUMP CPU_FAN ATX_12V_1 ATX_12V_2 ADD GEN 2_2 HDMI_DP DIGI+ ADD GEN 2_3 DRAM BOOT U2_56 U32G2_E56 U32G2X2_C1 U32G1_9 LAN_U32G1_E34 LGA1700 M.2(WIFI) AUDIO 2242 2260 PCIE SATA 2280 4.0 X4 M.2_1(SOCKET3) PCIEX16(G5) Ethernet AURA Super BATTERY Intel ®...
  • Page 13 The USB 3.2 Gen 2 Type-C connector provides ® TX1- data transfer speeds of up to 10 Gb/s. TX1+ VBUS The USB 3.2 Gen 2 Type-C module is purchased separately. ® TUF GAMING B760M-PLUS WIFI...
  • Page 14 9. USB 3.2 Gen 1 header The USB 3.2 Gen 1 header allows you to connect a USB 3.2 Gen 1 PIN 1 USB3+5V USB3+5V IntA_P1_SSRX- module for additional USB 3.2 Gen 1 ports. The USB 3.2 Gen 1 IntA_P2_SSRX- IntA_P1_SSRX+ IntA_P2_SSRX+ header provides data transfer speeds of up to 5 Gb/s.
  • Page 15 Power Button/Soft-off Button header (PWRSW) The 2-pin header allows you to connect the system power button. Press the power button to power up the system, or put the system into sleep or soft-off mode (depending on the operating system settings). TUF GAMING B760M-PLUS WIFI...
  • Page 16 • Reset button header (RESET) The 2-pin header allows you to connect the chassis-mounted reset button. Press the reset button to reboot the system. • Chassis intrusion header (CHASSIS) The 2-pin header allows you to connect the chassis-mounted intrusion detection sensor or switch.
  • Page 17 3.2 (USB 3.2) ports are for USB 3.2 Gen 2 devices. ). This Universal Serial Bus 3.2 USB 3.2 Gen 2x2 (up to 20Gbps) port (USB Type-C ® (USB 3.2) port is for USB 3.2 Gen 2x2 Type-C devices. ® TUF GAMING B760M-PLUS WIFI...
  • Page 18 Wi-Fi 6 ports. These ports connect to Wi-Fi antennas. • Ensure that the ASUS Wi-Fi moving antennas are securely installed to the Wi-Fi ports. • Ensure that the antennas are at least 20 cm away from all persons. Optical S/PDIF out port. This port allows you to connect your PC to amplified speakers, headphones, or Sony/Phillips Digital Interconnect Format (S/PDIF) compliant devices.

  • Page 19: Central Processing Unit (Cpu)

    CPU designed for LGA1155, LGA1156, LGA1151, and LGA1200 sockets on the LGA1700 socket. • ASUS will not cover damages resulting from incorrect CPU installation/removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user. Installing the CPU...
  • Page 20 Ensure to remove the CPU Socket lever protector on the lever latch before locking the lever latch under the retention tab. Failure to do so may cause damages to your system when installing the cooling system. 1-10 Chapter 1: Product Introduction...

  • Page 21: System Memory

    (D/C) from the same vendor. Check with the retailer to get the correct memory modules. • Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types. Recommended memory configurations...
  • Page 22 Installing a DIMM To remove a DIMM 1-12 Chapter 1: Product Introduction...

  • Page 23: Installation

    For 2242, 2260 length Install the bundled screw stand to the M.2 length screw hole you wish to install your M.2 to. Install your M.2 to the M.2 slot. Secure your M.2 using the bundled screw stand’s screw. TUF GAMING B760M-PLUS WIFI 1-13...
  • Page 24 • This M.2 rubber pad is optional for when installing a single sided M.2 storage device. Ensure to install the bundled M.2 rubber pad before installing your single sided M.2 storage device. • DO NOT install the bundled M.2 rubber pads when installing a double-sided M.2 storage device.

  • Page 25: Wi-Fi Antennas Installation

    Wi-Fi antennas installation Installing the ASUS Wi-Fi antennas Connect the bundled ASUS Wi-Fi antennas connectors to the Wi-Fi ports at the back of the chassis. • Ensure that the ASUS Wi-Fi antennas are securely installed to the Wi-Fi ports. •...
  • Page 26 1-16 Chapter 1: Product Introduction...

  • Page 27: Chapter 2 Bios And Raid Support

    BIOS and RAID Support Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 28: Bios Setup Program

    BIOS Setup program Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief onscreen help to guide you in using the BIOS Setup program. Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST).

  • Page 29: Asus Ez Flash 3

    ASUS EZ Flash 3 The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS-based utility. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.

  • Page 30: Asus Crashfree Bios 3

    ASUS CrashFree BIOS 3 The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using a USB flash drive that contains the BIOS file.

  • Page 31: Raid Configurations

    For more information on configuring your RAID sets, please refer to the RAID Configuration Guide which you can find at https://www.asus.com/support, or by scanning the QR code. RAID definitions RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in parallel, interleaved stacks.
  • Page 32 Chapter 2: BIOS and RAID Support...

  • Page 33: Appendix

    Appendix Notices FCC Compliance Information Responsible Party: Asus Computer International Address: 48720 Kato Rd., Fremont, CA 94538, USA Phone / Fax No: (510)739-3777 / (510)608-4555 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 34 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 35 Tenez cet appareil à distance du ventre des femmes enceintes et du bas-ventre des adolescents. TUF GAMING B760M-PLUS WIFI...
  • Page 36 ASUS products sold in Vietnam, on or after September 23, 2011,meet the requirements of the Vietnam Circular 30/2011/TT-BCT. Các sản phẩm ASUS bán tại Việt Nam, vào ngày 23 tháng 9 năm2011 trở về sau, đều phải đáp ứng các yêu cầu của Thông tư 30/2011/TT-BCT của Việt Nam.
  • Page 37 ASUSTek Computer Inc. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of The Radio Equipment Regulations 2017 (S.I. 2017/1206). Full text of UKCA declaration of conformity is available at https://www.asus.com/support/. The WiFi operating in the band 5150-5350MHz shall be restricted to indoor use for the country listed below: UKCA RF Output table (The Radio Equipment Regulations 2017) Intel®...
  • Page 38 Pilns ES atbilstības paziņojuma teksts pieejams šeit: zahtjevima i ostalim odgovarajućim odredbama direktive 2014/53/EU. Cijeli https://www.asus.com/support/. tekst EU izjave o sukladnosti dostupan je na https://www.asus.com/support/. Wi-Fi darbība 5150–5350 MHz ir jāierobežo lietošanai telpās valstīs, kuras WiFi koji radi na opsegu frekvencija 5150-5350 MHz bit će ograničen na norādītas tālāk.
  • Page 39 ASUSTek Computer Inc. tukaj izjavlja, da je ta naprava skladna s temeljnimi zahtevami in drugimi relevantnimii določili Direktive 2014/53/EU. Polno besedilo izjave EU o skladnosti je na voljo na https://www.asus.com/support/. WiFi, ki deluje v pasovnem območju 5150–5350 MHz, mora biti v državah, navedenih v spodnjem seznamu, omejen na notranjo uporabo: Declaración de conformidad simplificada para la UE...

  • Page 40: Warranty

    • ASUS offers a voluntary manufacturer’s Commercial Guarantee. • ASUS dragovoljno nudi komercijalno proizvođačko jamstvo. • ASUS reserves the right to interpret the provisions of the ASUS • ASUS zadržava prava na tumačenje odredbi ASUS komercijalnog Commercial Guarantee. jamstva. •...
  • Page 41 • ASUS tilbyr som produsent en frivillig kommersiell garanti. • Bảo hành thương mại này của ASUS được cung cấp độc lập và ngoài • ASUS forbeholder seg retten til å tolke bestemmelsene i ASUS sin Bảo đảm pháp lý theo luật định và không có cách nào ảnh hưởng đến kommersielle garanti.

  • Page 42: Asus Contact Information

    Address: 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112 ASUS COMPUTER INTERNATIONAL (America) Address: 48720 Kato Rd., Fremont, CA 94538, USA ASUS COMPUTER GmbH (Germany and Austria) Address: Harkortstrasse 21-23, 40880 Ratingen, Germany ASUSTeK (UK) LIMITED Address: 1st Floor, Sackville House, 143-149 Fenchurch Street, London, EC3M 6BL,...
