SMC Networks EZ Connect SMC2735W Installation Manual

802.11a wireless cardbus adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EZ Connect

802.11a Wireless CardBus Adapter

N 54 Mbps data rate (72 Mbps Turbo Mode): provides
alternative for wired LANs that can dramatically cut costs
N Coverage area up to 1650 ft
N Seamless connectivity to wired Ethernet LANs: augments
existing networks quickly and easily
N Supports 64/128/152-bit Wired Equivalent Privacy (WEP)
N Supports a wide range of operating systems
(Win98/NT/ME/2000/XP)
N Built-in antenna
N Easy installation

Installation Guide

SMC2735W

Advertisement

Table of Contents
loading

Related Manuals for SMC Networks EZ Connect SMC2735W

Summary of Contents for SMC Networks EZ Connect SMC2735W

  • Page 1: A Wireless Cardbus Adapter

    N Coverage area up to 1650 ft N Seamless connectivity to wired Ethernet LANs: augments existing networks quickly and easily N Supports 64/128/152-bit Wired Equivalent Privacy (WEP) N Supports a wide range of operating systems (Win98/NT/ME/2000/XP) N Built-in antenna N Easy installation Installation Guide SMC2735W...

  • Page 3: User Guide

    EZ Connect User Guide The easy way to make all your network connections 6 Hughes Irvine, CA 92618 Phone: (949) 707-2400 December 2001 Pub. # 150000013700A Part No: 01-111321-006...
  • Page 4 Copyright © 2001 by SMC Networks, Inc. 6 Hughes Irvine, CA 92618 All rights reserved. Printed in Taiwan Trademarks: SMC is a registered trademark of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.
  • Page 5 30 days of purchase from SMC or its Authorized Reseller. Registration can be accomplished via the enclosed product registration card or online via the SMC web site. Failure to register will not affect the standard limited warranty. The Limited Lifetime warranty covers a product during the Life of that Product, which is defined as the period of time during which the product is an “Active”...
  • Page 6 WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.
  • Page 7 FCC - Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with instructions, may cause harmful interference to radio communications.
  • Page 8 OMPLIANCES...

  • Page 9: Table Of Contents

    Network Topologies ....... 22 Ad Hoc Wireless LAN ......22 Infrastructure Wireless LAN .
  • Page 10 ABLE OF ONTENTS...

  • Page 11: Ez Connect

    802.11a W Introduction SMC’s EZ Connect 802.11a Wireless CardBus Adapter is a 54 Mbps (72 Mbps Turbo Mode) wireless network card that seamlessly integrates with existing Ethernet networks to support applications such as mobile users or temporary conferences. This solution...

  • Page 12: Package Checklist

    ™ 802.11 ONNECT Package Checklist The EZ Connect Wireless CardBus Adapter package includes: • 1 EZ Connect 802.11a Wireless CardBus Adapter (SMC2735W) • 1 Driver and Utility CD ROM • This User Guide Please register this product and upgrade product warranty at: www.smc.com.

  • Page 13: Applications

    Applications EZ Connect Wireless products offer a fast, reliable, cost-effective solution for wireless client access to the network in applications such as: • Remote access to corporate network information E-mail, file transfer and terminal emulation • Difficult-to-wire environments Historical or old buildings, asbestos installations and open areas where wiring is difficult to employ •...

  • Page 14: Led Indicators

    EZ C ™ 802.11 ONNECT LED Indicators The SMC2735W includes two status LED indicators, as described in the following figure and table. Power Network Alternate Power/Network IRELESS Power LED Network LED Condition Status Awake from power save. (The CardBus Adapter automatically enters this state after exit from power save mode and before any other activity.)

  • Page 15: System Requirement

    System Requirement Before you install the EZ Connect 802.11a Wireless CardBus Adapter, check your system for the following requirements: • A computer with a CardBus slot • Windows 98/NT4.0/ME/2000/XP (Have the Windows installation CD-ROM ready for use during installation) •...

  • Page 16: Hardware Installation

    1. Turn your computer on and boot to your operating system. 2. Find an available CardBus slot in your computer. 3. With the EZ Connect 802.11a Wireless CardBus Adapter 68-pin connector facing the CardBus slot and the EZ Connect 802.11a Wireless CardBus Adapter label facing up, slide the card completely into the CardBus slot as shown below.
  • Page 17 ARDWARE NSTALLATION 6. Install the EZ Connect Wireless 802.11a CardBus Configuration Utility for your wireless CardBus Adapter. The Setup.exe file can be found on the CD ROM. See “Configuration and Diagnostic Utility” on page 25 for more information.

  • Page 18: Driver Installation

    Any new or updated drivers can be downloaded from SMC’s Web site at: http://www.smc.com. You may find that the instructions in this chapter do not exactly match your version of Windows.

  • Page 19: Windows 98/2000/Me/Xp Installation

    Windows 98/2000/ME/XP Installation 1. Insert the CardBus into a standard CardBus slot in your notebook. 2. Windows 98/2000/ME/XP will automatically detect the new hardware and prompt you to install the driver. Click “Next” to find the driver. RIVER NSTALLATION...
  • Page 20 RIVER NSTALLATION 3. Insert the CD ROM labeled “SMC2735W/SMC2755W Driver/ Utility/Documentation CD,” specify the location “D:\Driver\Win2K (or Win98...)” and click “Next.”...
  • Page 21 RIVER NSTALLATION 4. Click “Next” to copy files from the CD-ROM. 5. Click “Finish” to end the installation.
  • Page 22 RIVER NSTALLATION 6. To communicate with SMC EZ Connect 802.11a wireless devices, you may need to configure the CardBus Adapter. From the “Start” menu select “Settings” ” then click on “Control Panel.” 7. Double click on the “SMC NIC Configuration” icon...
  • Page 23 RIVER NSTALLATION 8. You may either modify the default settings or create a new configuration profile. To modify the default settings, click “Modify.” To create a new configuration profile, click “New.”...
  • Page 24 RIVER NSTALLATION Configuration Name - Enter the desired profile name. Network Name (SSID) - Set the “SSID” (Service Set ID) to the same as that used by the ad hoc workgroup or access point you want to connect to. (The SMC2755W access point default is ANY.) Note: The SSID is upper/lower case sensitive and can...
  • Page 25 MAC address consists of 12 hexadecimal numbers. 10. Click “OK” when you have finished the configuration profile. This returns you to the “SMC NIC Configuration” dialog box. The profile can be modified by selecting the profile name from the “Configuration List” and clicking on “Modify.”...
  • Page 26 RIVER NSTALLATION To enter security keys click on the “Security” tab in the “Network Configuration Settings” screen and check “Enable Security.” Note: 64-Bit Manual Entry - Each Key ID contains 10 HEX digits. 128-Bit Manual Entry - Each Key ID contains 26 HEX digits.

  • Page 27: Installation For Windows Nt 4.0

    14. Click “Add” to install the network protocols you want to use, such as IPX/SPX, NetBEUI or TCP/IP. If you install TCP/IP, be sure to set the appropriate Gateway, DNS Server, and Domain for your network. If you install an IPX/SPX-compatible protocol, then you also need to install the Client for NetWare Networks.
  • Page 28 RIVER NSTALLATION 3. Double click on “Network.” 4. Click “Adapters,” and then click the “Add” button on the Network dialog box.
  • Page 29 5. Windows NT will present a list of all its supported adapters. Click “Have Disk” to continue. 6. Windows NT will ask for the drive/path containing the SMC2735W Windows NT drivers. Insert the CD ROM labeled “SMC2735W/SMC2755W Driver/Utility/Documentation CD,” specify the location “D:\Driver\WinNT” and click “OK.”...
  • Page 30 RIVER NSTALLATION IRQ Level - Select 9, 10 or 11. (Check for available resources under Windows NT Diagnostics.) Mode - Set to “AdHoc” or “Infrastructure,” depending on the type of network you want to connect to (see page 21). SSID - Set the “SSID” identifier to the same as that used by the ad hoc workgroup or access point you want to connect to.

  • Page 31: Network Configuration And Planning

    ETW O RK SMC’s EZ Connect Wireless Solution supports stand-alone wireless network configuration, as well as an integrated configuration with 10/100 Mbps Ethernet LANs. The SMC2735W can be configured as: • Ad hoc for departmental or SOHO LANs • Infrastructure for enterprise LANs...

  • Page 32: Network Topologies

    LAN. Computers in a specific ad hoc wireless LAN must therefore be configured to the same radio channel. An ad hoc wireless LAN can be used for a branch office or SOHO operation. PC with Wireless PCI Adapter...

  • Page 33: Infrastructure Wireless Lan

    Infrastructure Wireless LAN The SMC2735W can also provide access to a wired LAN for wireless workstations. An integrated wired/wireless LAN is called an infrastructure configuration. A Basic Service Set (BSS) consists of a group of wireless PC users, and an access point that is directly connected to the wired LAN.

  • Page 34: Infrastructure Wireless Lan For Roaming Wireless Pcs

    Extended Service Set (ESS). By placing the access points so that a continuous coverage area is created, wireless users within this ESS can roam freely. All SMC wireless network cards and adapters and SMC2755W Wireless access points within a specific ESS must be configured with the same SSID.

  • Page 35: Configuration And Diagnostic Utility

    TILITY O NFIGURATIO N AND IAGNO STIC TILITY SMC’s EZ Connect Wireless CardBus Adapter provides free optional management software for quick network configuration and easy diagnostics. The CD labeled “SMC2735W/SMC2755W Driver/Utility/Documentation CD,” that comes with the package, contains a Utility Program that has user-friendly interface for configuring the card.

  • Page 36: Using The Wireless Lan Utility

    ONFIGURATION AND 5. Follow the on-screen instructions to finish installation. Using the Wireless LAN Utility Once the installation is completed, the configuration utility can be accessed from the “Start” menu, as shown below. This configuration software includes the following functions:...
  • Page 37 TILITY General Information Screen When you start the CardBus utility, general information for the SMC2735W is shown under the first tab of the utility windows as shown below. Frame Statistics This, and the following dialog box, provides statistics on frames...
  • Page 38 ONFIGURATION AND IAGNOSTIC TILITY Transmit Retries...
  • Page 39 PCs in its BSS. (Default: “52” for the USA and “38” for Japan.) A Basic Service Set (BSS) consists of a group of wireless PC users, and an access point that is directly connected to the wired LAN. Note that the channel for wireless clients is automatically set to the same as that used by the access point to which it is linked.
  • Page 40 ONFIGURATION AND Driver This dialog box gives information on how the operating system interacts with the CardBus Adapter. IAGNOSTIC TILITY...

  • Page 41: Troubleshooting

    Check for any hardware problems, such as physical damage to the card’s connector. • Try the card in another CardBus slot. If this also fails, test your computer with another SMC2735W wireless card that is known to operate correctly. • When operating under Windows NT, make sure a CardBus adapter and socket services driver is installed in your computer.

  • Page 42: Network Connection Problems

    ID and password. • If you cannot access the Internet, ensure that you have configured your system for TCP/IP. If your wireless station cannot communicate with a computer in the Ethernet LAN when configured for infrastructure mode, check the following: •...

  • Page 43: Smc Networks

    If you have any questions or comments regarding the features or performance of this product, or if you would like information regarding SMC’s full line of wireless products, you can visit SMC’s Web site at www.smc.com or you can call SMC toll-free at 800.SMC.4YOU.

  • Page 44: Specifications

    Functional Criteria Data Rate Normal Mode: 6, 9, 12, 18, 24, 36, 48, 54 Mbps Turbo Mode: 12, 18, 24, 36, 48, 72 Mbps Standard IEEE 802.11a - wireless Operating Range Up to 1650 ft (503 m) Radio Signal Signal Type...
  • Page 45 QPSK Turbo (36 Mbps) 16 QAM Turbo (48 Mbps) 16 QAM Turbo (72 Mbps) Modulation Modulation BPSK(6 Mbps) BPSK(9 Mbps) QPSK(12 Mbps) QPSK(18 Mbps) 16 QAM(24 Mbps) 16 QAM(36 Mbps) 64 QAM(48 Mbps) 64 QAM(64 Mbps) BPSK Turbo(12 Mbps) BPSK Turbo(18 Mbps) QPSK Turbo(24 Mbps) QPSK Turbo(36 Mbps) 16 QAM Turbo(48 Mbps)
  • Page 46 PECIFICATIONS Idle/Listening, 1238 mw, Sleep - 40 mw Weight 50 g (4.8 oz) Dimensions 11.5 x 5.3 cm (4.53 x 2.09 in.) Antenna Built-in side-stem antenna LED Indicators Power, Network Host Interface 68-pin connector to CardBus slot Environmental Temperature 32 to 140 °F/ 0 to 50 °C (operating) 32 to 158 °F/ 0 to 70 °C (storage) Humidity 5 to 80% (non-condensing)
  • Page 47 PECIFICATIONS Windows XP Windows ME...

  • Page 48: Terminology

    Access Point – An internetworking device that seamlessly connects wired and wireless networks. Ad hoc – An ad hoc wireless LAN is a group of computers each with LAN adapters, connected as an independent wireless LAN. Backbone – The core infrastructure of a network. The portion of...
  • Page 49 Infrastructure – An integrated wireless and wired LAN is called an Infrastructure configuration. Roaming – A wireless LAN mobile user moves around an ESS and maintains a continuous connection to the Infrastructure network. RTS Threshold – Transmitters contending for the medium may not be aware of each other.
  • Page 50 ERMINOLOGY...
