SMC Networks EZ Switch SMC105DT Specifications

Managed &
Unmanaged
Switches
SMC's EZ Switch™ 10/100 is a palm-sized 5-port
Fast Ethernet switch that delivers dedicated
10/100Mbps links to each attached LAN segment
– all with conventional cabling and adapters.
SMC's EZ Switch™ 10/100 offers a simple, cost-
effective strategy for integrating Fast Ethernet
into your Ethernet network. Auto-negotiation is
used to select the optimal communication mode
for each connection. With store-and-forward
Overview
Features
• Auto-negotiation of half or full duplex,
and auto-sensing of transmission
speed, on all ports
• Auto configuration for MDI/MDI-X
cable connections
• ANSI/IEEE 802.3u compliant
• Store-and-forward support
• "At-a-Glance LEDs"
• Small form factor
• External power supply
• Mountable on metal surfaces
3 8 T e s l a
Irvine, CA 92618
1-800-SMC-4YOU
w w w. s m c. c o m
EZ Switch
TM
5-port Fast Ethernet Switch
Benefits
• Half and full-duplex flow control prevents packets
from being dropped under heavy loading
• Plug-n-Play ensures ease of implementation and
use. Allows connections to servers, workstations,
hubs or switches to be made with straight-through
cables or cross-over cable
• Standards-based technology ensures interoperability
between various IEEE-based products
• Store-and-forward architecture prevents
propagation of bad packets
• Intuitive status indicators allow for simple switch
and network diagnostics
• Can be conveniently mounted on a metal surface
with included magnets or positioned on the
desktop
10/100
Model Number::
switching and flow control, maximum data
integrity is always maintained, even under heavy
loading. Easy installation, "At-a-Glance LEDs" , and
its ability to be mounted on any metal surface
make this plug-n-play switch an ideal choice for
smooth Fast Ethernet integration.
SMC105DT
Compatibility
• IEEE 802.3
• IEEE802.3u
• IEEE802.3x
