TECHNICAL SPECIFICATIONS
NETWORK INTERFACES
• One RJ-45 (10/100 Base-T Ethernet)
• One Coaxial Connector
• Power line port
LEDS
• Power (PWR)
• Coax / PLC Link/Activity
• Ethernet Link/Activity
POWER INPUT
• 100-240VAC @ 50~60Hz (internal)
ETHERNET STANDARDS
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100 Base-TX Fast Ethernet
ADDITIONAL PROTOCOLS
• Forward Error Correction (FEC)
• Automatic Channel Adaptation
• Integrated Quality of Service (QoS)
SECURITY
• 128-bit AES Link Encryption
CONFIGURATION MANAGER SOFTWARE
• Device Detect/Diagnostic
• NEK Password Setup for Local and Remote Device
CONFIGURATION MANAGER SUPPORT
• Windows 98SE, 2000, Me, and XP
CERTIFICATIONS
• HomePlug AV Powerline Specifications
• FCC Part 15 Class B
• CE
FREQUENCY
• 2 MHZ - 28 MHZ
MODULATION SCHEMES
• OFDM SYMBOL MODULATION
• QAM, QPSK, BPSK, ROBO CARRIER MODULATION
TYPICAL COVERAGE
• Estimated range of 300 meters in wall power lines
HUMIDITY
• Operating: 10% to 90% Non-Condensing
TEMPERATURE
• Operating: 32º to 104º F / 0º to 40º C
www.smc.com
SMCHPAVH-ETH
WARRANTY
• Limited Lifetime
DIMENSIONS
• 6.2 x 3.9 x 1.2 in
• 157 x 99 x 30 mm
WEIGHT
• 0.22kg
• 0.48lb
Contact
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe / Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
