SMC Networks HP1D-USB - annexe 1 Quick Installation Manual

Package contents
Verify you have the following items included in the EZ Connect™ Powerline to USB
Desktop Adapter package.
• 1 SMCHP1D-USB EZ Connect™ 14 Mbps Powerline to USB Desktop Adapter.
• 3 Power Adapters (US/UK/EU).
• 1 USB Cable.
• Quick Installation Guide.
• 1 EZ Installation CD including.
- EZ Install Wizard
- USB Drivers
- EZ Configuration Utility 1.0
- User Guide
Immediately inform your dealer in the event of any incorrect, missing or damaged
parts. If possible, please retain the carton and original packing materials in case there
is a need to return the product.
Please register this product and upgrade the product warranty at SMC's Web site:
www.smc.com or www.smc.europe.com.
Hardware Description
The EZ Connect™ 14 Mbps Powerline to USB Desktop Adapter (SMCHP1D-USB) is the
easiest way to create or extend a home network. The Powerline to USB Desktop Adapter is
compatible with Windows 98, Me, 2000, XP, and is ideal for connecting a desktop or
laptop in another room of the house without having to run expensive CAT-5 cabling.
Combine the EZ Connect TM Powerline to USB Adapter with the EZ Connect
Ethernet Desktop Adapter (SMCHP1D-ETH) for a complete Powerline solution from your
Router to your PC.
The EZ Connect TM 14 Mbps Powerline to USB Desktop Adapter (SMCHP1D-USB)
is equipped with:
• 1 USB 1.1 connection.
• 1 Powerline connection.
There are two LED indicators to display status, connectivity, and data traffic:
LED (Label) Color
Power Green
(PWR)
Powerline
Green
(HP)
TM Powerline to
Activity
Solid LED indicates that the unit is powered on.
No LED light indicates the unit is powered off.
Solid LED indicates that a Powerline signal is detected.
Blinking LED indicates traffic is being transmitted.
No LED light indicates no Powerline signal is detected.
