KickAss KABTRYSHUNT User Manual page 9

Recommended Values for Different Battery Types
Battery Type
*Total rated capacity of battery bank.
For example: A single @ 120Ah battery: CAP= 120Ah,
CAP
2x battery @ 120Ah: CAP= 240AH
FCV
(refer to
charger spec)
LCA
ZCV
POV
At 80% DOD**: Rated Capacity ÷ 500
At 50% DOD**: Rated Capacity ÷ 1000
ATT
At 20% DOD**: Rated Capacity ÷ 2000
Recommended Attentiation Values
120Ah AGM
170Ah AGM
120Ah Lithium
170Ah Lithium
* Rated Capacity - The capacity the battery is rated to by the manufacturer. For many battery types like AGM, it is
not recommended to use 100% of the battery capacity.
** DOD: Depth of Discharge - The percentage at which the battery is discharged in relation to the rated capacity.
eg. At 80% DOD, the State of Charge is approximately 20% of the total rated capacity of the battery.
GEL AGM
14.1V 14.4-14.7V
50%-60% of CAP
80% DoD
Not Allowed
Not Allowed
0.24
WET
14.7V
10.8V
11.5V
50% DoD
0.12
0.17
0.12
0.4 0.2
7
CALCIUM LITHIUM
14.7V 14.4-14.6V
20%
10.5V
12V
20% DoD
0.06
0.085
0.06
1
