Introducing the Cool SATA to USB 2.0
The Cool SATA to USB 2.0/eSATA Docking is designed to
support USB 2.0 and eSATA equipped computers. This
adapter provides large capacity mobile storage using
3.5" or 2.5" SATA hard disk drives through high-speed,
hot-swapping USB 2.0 & eSATA interfaces.
Features and Benefits
•
Supports Hi-Speed USB 2.0 & eSATA interfaces
•
Supports SATA I/II (SATA 150/300)
•
Supports 2.5" and 3.5" hard drive
•
Plug and Play, no additional drivers needed
•
Supports USB hot-swap and hot-plug
System Requirements
PC:
•
Pentium
eSATA or USB port (USB 2.0 recommended)
•
Windows
2008 (32-/64-bit) / Vista (32-/64-bit)
Mac
:
®
•
An available eSATA or USB port (USB 2.0
recommended)
•
Mac OS
04-0522A
Cool SATA to USB 2.0/
eSATA Docking
Quick Installation Guide
or equivalent computer with an available
®
2000 / XP (32-/64-bit) / Server 2003 &
®
X v10.4.8 or higher
®
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIIG SC-SA0312-S1
Summary of Contents for SIIG SC-SA0312-S1
- Page 1 Cool SATA to USB 2.0/ eSATA Docking Quick Installation Guide Introducing the Cool SATA to USB 2.0 The Cool SATA to USB 2.0/eSATA Docking is designed to support USB 2.0 and eSATA equipped computers. This adapter provides large capacity mobile storage using 3.5"...
-
Page 2: Package Contents
Package Contents • Cool SATA to USB 2.0/eSATA Docking • Switching power adapter • USB 2.0 cable (type A to type B) • eSATA cable • Quick Installation Guide Layout Note: You cannot use one hard drive in both platforms, Windows and Mac. It is not supported SATA Drive Slot LED (All three LED's stay on while the unit is on) -
Page 3: Hardware Installation
Hardware Installation Make sure the SATA connectors are in alignment. Gently insert the SATA hard drive into the SATA drive slot. Plug the included switching power adapter into the Cool SATA to USB 2.0/eSATA Docking power adapter jack, then plug the switching power adapter into a reliable power source. - Page 4 Using the Cool SATA to USB 2.0/eSATA Windows Two additional drive icon will appear in My Computer when the converter is plugged into a USB port. The drive acts just like a conventional hard drive in your system. Note: Be careful not to touch the hard drive while in use.
- Page 5 Highlight USB Mass Storage Device, click Stop, OK then Close. You can now unplug or turn off the Cool SATA to USB 2.0/eSATA Docking. Windows Vista™ Verify that the HDD LED is OFF before proceeding. Double click the Unplug or Eject Hardware icon located in the system tray.
- Page 6 Disconnecting From The Computer Before unplugging the Cool SATA to USB 2.0/eSATA Docking from the computer, drag the drive icon into the Trashcan and wait for the confirmation box. The same rule applies when turning off theCool SATA to USB 2.0/ eSATA Docking .
- Page 7 Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. Step 2: After obtaining an RMA number, ship the product.
- Page 8 Fremont, CA 94538-3152, USA Ph: 510-657-8688 Cool SATA to USB 2.0/eSATA Docking is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
