SIIG SC-SA0J12-S1 Quick Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Introducing the SuperSpeed USB to SATA
3Gb/s Dual Docking
The SuperSpeed USB to SATA 3Gb/s Dual Docking provides
large capacity mobile storage using 2.5" or 3.5" SATA hard
disk drives through SuperSpeed USB 3.0 interface.
Features and Benefits
•
Supports SuperSpeed USB 3.0 data transfer rates up
to 5Gb/s
•
Backward compatible with previous version of
USB ports (2.0/1.1)
•
Backward compatible with previous versions of
SATA hard disks (1.5Gb/s)
•
Supports 2.5" and 3.5" (or mix) hard disk drives up
to 2TB capacity
•
Compliant with Serial ATA Specification Revision
2.6
•
Plug and play, no driver installation needed
Note: For maximum data throughput, use a SATA
3Gb/s hard disk drive with the enclosure and
connect to a SuperSpeed USB 3.0 port.
04-0633B
SuperSpeed USB to SATA
3Gb/s
Quick Installation Guide
Dual
Docking
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-SA0J12-S1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG SC-SA0J12-S1

Summary of Contents for SIIG SC-SA0J12-S1

  • Page 1 SuperSpeed USB to SATA 3Gb/s Dual Docking Quick Installation Guide Introducing the SuperSpeed USB to SATA 3Gb/s Dual Docking The SuperSpeed USB to SATA 3Gb/s Dual Docking provides large capacity mobile storage using 2.5" or 3.5" SATA hard disk drives through SuperSpeed USB 3.0 interface. Features and Benefits •...

  • Page 2: System Requirements

    System Requirements • Desktop or notebook PC with an available USB port (SuperSpeed USB 3.0 recommended) • Windows 8 (32-/64-bit) / 7 (32-/64-bit) / Vista (32- ® /64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32- /64-bit) / Server 2008 R2 Package Contents •...

  • Page 3: Hardware Installation

    port Power Adapter jack Figure 2: Back Layout Hardware Installation Important: Do not insert or remove a hard disk drive when the SuperSpeed USB to SATA 3Gb/s Dual Docking is powered on. Make sure the SATA connectors of the hard disk drive are in alignment with the SATA connectors of the SuperSpeed USB to SATA 3Gb/s Dual Docking.

  • Page 4: Driver Installation

    Driver Installation Windows will automatically detects and installs the drivers for the SuperSpeed USB to SATA 3Gb/s Dual Docking. No additional driver installation is needed. Note: In order to get USB 3.0 performance, make sure your USB 3.0 controller has the correct drivers installed.
  • Page 5 Windows 8 (32-/64-bit) / 7 (32-/64-bit) / Server 2008 R2 Click the Safely Remove Hardware and Eject Media icon located in the taskbar by the system clock. Click Eject USB Mass Storage Device. When the message Safe To Remove Hardware pops up, you can safely unplug or turn off the SuperSpeed USB to SATA 3Gb/s Dual Docking.
  • Page 6 Blank Page...
  • Page 7 Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
  • Page 8 Fremont, CA 94538-3152, USA Phone: 510-657-8688 SuperSpeed USB 3.0 SATA 3Gb/s Dual Docking is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
