AMS-500HD and AMS-750HD
SERIES 2 HARD DRIVE SHREDDERS
OWNER'S MANUAL
Thank you for purchasing an Ameri-Shred Shredder. This model is made of the finest materials available and is
manufactured in the Unites States by skilled craftsmen. The shredder has been designed with the operator in
mind for both ease of operation and maintenance. Ameri-Shred requests that each operator read and familiarize
themselves with this manual before operating the machine.
The AMS-500HD and AMS-750HD Hard Drive Shredders are designed by Ameri-Shred Engineers to shred hard
drives and other electronic media into unusable particles to ensure that the information they contain is rendered
useless. Ameri-Shred believes in using the highest quality components in each of our industrial shredders.
Included in this manual are safety tips, operating instructions, preventative maintenance and lubrication
schedules, and trouble shooting information. For information or questions that may not be found in this manual
please contact our service department at 888-270-6879.
NOTICE: The information contained within this manual is correct at time of printing, but due to the continuing development of prod ucts,
changes in specifications are inevitable. Ameri-Shred reserves the right to implement such changes without prior notice.
Series 2 Hard Drive Shredder Manual 2015 v.2
Series 2 Hard Drive Shredder Manual 2015 v.2
1
