  • Page 1 ONLINE SUPPOR s ONLINE SUPPOR T and Product Registration Product Registration Product Registration Product Registration Product Registration www.siig.com www.siig.com Visit SIIG’s web site at www.siig.com www.siig.com www.siig.com and click Support Support Support Support Support for instant technical support. Also, click Support/Register...
  • Page 2 6078 Stewart Avenue Fremont, CA 94538-3152, USA USB Over IP is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Other names used in this publication are for identification only and may be trademarks of their respective companies.

  • Page 3: Table Of Contents

    User's Manual Contents Chapter 1: Introduction 1-1 Unpacking the USB Over IP ... 1-1 1-1.1 Static Electricity Precaution ... 1-2 1-1.2 Record the Serial Number ... 1-2 1-2 Introducing the USB Over IP ... 1-3 1-2.1 Features and Benefits ... 1-3 1-2.2 System Requirements ...
  • Page 4 Chapter 4: USB Over IP Admin 4-1 Introducing the USB Over IP Admin ... 4-1 4-2 Windows Vista Firewall ... 4-2 4-3 Using USB Over IP Admin ... 4-3 4-3.1 Quick Start Icon ... 4-3 4-3.2 USB Devices ... 4-3 4-3.2.1 USB Function Buttons ...
  • Page 5 User's Manual About This Manual The purpose of this manual is to introduce you to your USB Over IP server. It will guide you to properly configure and install into your system. Please save this manual for future reference. This manual is comprised of the following sections: Chapter 1: Introduction Provides unpacking instructions, and introduces features and specifications.

  • Page 6: Chapter 1: Introduction

    Thank you for your purchase of the USB Over IP. SIIG’s goal is to provide reliable, high quality products and fast customer support. The purpose of this comprehensive user’s manual is to: • Introduce you to your USB Over IP features and benefits •...

  • Page 7: 1-1.1 Static Electricity Precaution

    Handle cards only by their edges. 1-1.2 Record the Serial Number In order for SIIG's Technical Support or RMA Department to give you prompt service, you will need the following product information. The serial number label is located on the side of the box and on the adapter.

  • Page 8: Introducing The Usb Over Ip

    1-2 Introducing the USB Over IP The USB Over IP allows network users to connect remote USB devices like, printers, scanners, digital cameras and USB Flash drives over the network. It is ideal for home office, small office or classroom use! User friendly client software, which maps USB devices connected to the USB Over IP onto the local host computer, is included 1-2.1 Features and Benefits...

  • Page 9: 1-2.2 System Requirements

    User's Manual 1-2.2 System Requirements • Windows XP (32-/64-bit)/Server 2003 (32-/64- ® bit)/Vista (32-bit) • Ethernet network with an available RJ45 port • CD-ROM drive 1-2.3 Layout Power LED: USB Over IP is powered on • Ready LED: when the box is first powered on, the •...

  • Page 10: Chapter 2: Hardware Installation And Device Compatibility

    Chapter 2 Hardware Installation and Device Compatibility 2-1 Hardware Installation General hardware installation instructions are provided below. Since the design of computer cases and motherboards vary, refer to your computer's reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system.

  • Page 11: Usb Device Support

    User's Manual 2-3 USB Device Support USB Over IP Admin client software is based on open architecture, wherein the USB Over IP box virtualizes the connected USB devices onto the remote client. The Client, installed on the remote host, interacts with the USB Over IP box and enables remote access.
  • Page 12 LifeCam VX-1000 LifeCam VX-3000 Vista Plus Webcam QHMPL 500lm-8lm e-CAM LifeCam VX-6000 Quickcam for Notebooks Pro Sony Sony USB Speakers Microsoft Life Chat LX3000 head phones Audio Advantage Micro Sound Card USB SoundWave 7.1 SIIG USB SoundWave 7.1 Pro Model...
  • Page 13 User's Manual 2-3.1 Device Interoperability List Contd. Device Type Keyboard Mouse Joystick Mass Storage Device Western Digital HDD Enclosure Transcend 2GB Make Acer Acer Keyboard Apple Mac Mac Extended Keyboard Microsoft Comfort curve keyboard Microsoft Intranet Pro Keyboard Apple Apple Optical mouse Apple Apple mouse Microsoft...
  • Page 14 2-3.1 Device Interoperability List Contd. Device Type Make Printers Epson Canon Samsung Multi-function printers Canon Brother Dell Scanners USB IP Admin Software Utility Business InkJet 1200 DeskJet D2360 LaserJet 1020 (GDI printer) DeskJet 3740 PhotoSmart 3200 LaserJet 2200d EPL-6200L Stylus C87 Plus Stylus C58 Plus LX-300 +II iP1700...

  • Page 15: Chapter 3: Driver Installation

    3-1 Driver Installation This section provides information on how to install the USB Over IP drivers. 3-1.1 Windows XP Connect the USB Over IP to your network and boot up Windows. At the Windows desktop insert the driver CD. Autorun should start the installation, if not, click Start, then Run.
  • Page 16 User's Manual At Choose Components, click Next. At Choose Installation Location, click Install.
  • Page 17 At the Security Alert, click Yes. (skip this step for 32-bit XP) At Completed, click Finish. Driver Installation...
  • Page 18 User's Manual At the Found New Hardware Wizard, select No, not this time, click Next. (skip this step if not prompted) 10. Windows detects a new device, at the Found New Hardware Wizard, select Install the software automatically (Recommended), click Next.
  • Page 19 Driver Installation 11. At the Security Alert, click Yes. (skip this step for 32-bit XP) 12. Click Finish.
  • Page 20 User's Manual 13. At Windows Security Alert, click Unblock. (skip this step for 32-bit XP) 14. Repeat steps 9-12 for each USB Over IP connected to your network. 15. Restart XP to complete the installation. 3-1.2 Windows Server 2003 Connect the USB Over IP to your network and boot up Windows.
  • Page 21 At the USB Over IP screen, click Install. At Choose Components, click Next. Driver Installation...
  • Page 22 User's Manual At Choose Install Location, click Install. At Security Alert, click Yes.
  • Page 23 Driver Installation Click Finish. At the Found New Hardware Wizard, select No, not this time, then click Next.
  • Page 24 User's Manual 10. Select Install the software automatically (Recommended), click Next. 11. At Security Alert, click Yes. 3-10...
  • Page 25 12. Click Finish. 13. Repeat steps 9-12 for each USB Over IP connected to your network. 3-1.3 Windows Vista™ Connect the USB Over IP to your network and boot up Windows. At the Windows desktop insert the driver CD. At the Auto Play window: click Open folder to view files.
  • Page 26 User's Manual If Auto Play doesn't start: click Start, in the Start Search box, type D:\Launch.exe. (Change D: to match your CD-ROM drive letter) Right click Launch, click Run as administrator. Click Allow. At the USB Over IP screen, click Install. 3-12...
  • Page 27 Driver Installation At Choose Components, click Next. At Choose Install Location, click Install. 3-13...
  • Page 28 User's Manual At Windows Security, click Install this driver software anyway two times. Click Finish. 3-14...
  • Page 29 Driver Installation At Windows FireWall Security Alert, click Unblock. 10. Right click the USB Over IP Admin icon located on the desktop, click Properties. 3-15...
  • Page 30 User's Manual 11. Click Compatibility tab. Check Run this program as an administrator, click OK. (This step may take up to 30 seconds to complete) 12. Click Start, All Programs, USB Over IP. 3-16...
  • Page 31 Driver Installation 13. Right click the USB Over IP Admin icon, click Properties. 14. Click Compatibility tab, check Run this program as an administrator, click OK. 3-17...

  • Page 32: To Verify Installation

    User's Manual 3-2 To Verify Installation 3-2.1 Windows XP/Server 2003 Right click My Computer, click Manage, click Device Manager. Double click USBoIP Device Servers. Virtual USB Bus should be displayed for each USB Over IP connected to the network. 3-2.2 Windows Vista Right click Computer, click Manage, click Continue.

  • Page 33: Set Ip Address

    USB Over IP Admin. This section guides you through setting the IP address to match the subnet mask of your network. At the SIIG USB Over IP screen, click Configure. Note: You must have Administrator rights to run this utility in Windows Vista.
  • Page 34 User's Manual Click Unblock. (Skip this step if not prompted) At List of Servers, double click the MAC address of the USB Over IP you want to change. 3-20...
  • Page 35 At IP Configuration screen, either type in the IP address, subnet mask, and gateway or select DHCP, then click Change. Click Exit to save and exit. Driver Installation 3-21...

  • Page 36: Chapter 4: Usb Over Ip Admin

    4-1 Introducing the USB Over IP Admin The USB Over IP Admin is a user friendly PC software which supports High speed USB cameras, USB audio, USB Printers, Multi-function printers, scanners, storage devices, PDAs, digital cameras, serial adapters, mice, keyboards and much much more. Supports various types of USB Devices (class, •...

  • Page 37: Windows Vista Firewall

    User's Manual 4-2 Windows Vista FireWall Windows Vista operating system firewall blocks the USB Over IP Admin Quick Start Icon from starting up automatically at boot up. Follow the steps below to enable it. After Windows Vista has fully started, click on the Blocked startup programs icon located in the taskbar by the system clock.

  • Page 38: Using Usb Over Ip Admin

    Using the USB Over IP Admin The USB over IP Admin is used to connect to your USB devices and configure your USB Over IP server. 4-3.1 Quick Start Icon The USB Over IP Admin Quick Start Icon installs automatically during driver installation and is located on the right side of the taskbar by the system clock.

  • Page 39: 4-3.2.1 Usb Function Buttons

    User's Manual 4-3.2.1 USB Function Buttons • Refresh: refreshes USB device list • Connect: connects to a free USB device • Disconnect: disconnects from a connected USB device • Printer Auto Connect: automatically connects and disconnect to your printer when a print job is sent 4-3.3 Servers Screen The Server screen is divided into three sections, Server Manager, Server Details and Connected Clients...

  • Page 40: 4-3.3.1 Servers Function Buttons

    4-3.3.1 Server Function Buttons Refresh: searches for servers • Unlock: unlocks password enabled servers • Upgrade: upgrades server firmware • Setup: enters Server Configuration. This button is • disabled whenever a server is password enabled Restore: restores the box to its factory default IP •...

  • Page 41: How To's

    User's Manual 4-4 How To's 4-4.1 Device Mapping 4-4.1.1 How to Connect In the Device Mapping window, select a device who's status is Free, then click the Connect button. The Status will change to Connected. Depending on the device, Windows will either automatically install a driver for it or prompt you for a driver.

  • Page 42: 4-4.1.2 How To Disconnect

    4-4.1.2 How to Disconnect In the Device Mapping window, select a device who's status is Connected, then click the Disconnect button. The Status will change to Unloading then to Free. Configuration Utility...

  • Page 43: 4-4.1.3 Printer Auto Connct

    User's Manual 4-4.1.3 Printer Auto Connect The Printer Auto Connect feature automatically connects and disconnects your printer from your computer everytime you send a print job to the printer. Make sure the printer driver has been installed and the printer is configured to print from your computer before enabling this feature.

  • Page 44: 4-4.2 Server Manager

    4-4.2 Server Manager 4-4.2.1 Setup (Server Configuration) Use the Setup button to change server name, modify IP settings and enable or disable password. If the server is password protected the setup button will be disabled. To enable the Setup button, go to section 4-4.2.2 Unlock Server and Reset Password.
  • Page 45 User's Manual Select IP Settings tab. Check Modify, then either select Static and type in your IP address and gateway or, to have your server configured automatically, select DHCP. Select Password tab. Check Modify, then enable, disable or change your password. Click Save to save your changes and exit.
  • Page 46 4-4.2.2 Unlock Server and Reset the Password Whenever the USB Over IP is password protected, it's Status will be Locked. Follow the steps in the order that they appear to unlock the server. Select the locked server and click the Unlock button. Type in your current password, and click OK.
  • Page 47 User's Manual Your password will be confirmed or denied, click OK. If failed, try again. If you continue to have problems, check with your system administrator for the correct password. Click Refresh button, the server status should be Unlocked. Click the Setup button. 4-12...
  • Page 48 Select the Password tab. Check Modify, uncheck Enable Password, then click Save. Configuration Utility 4-13...

  • Page 49: 4-4.2.3 Refresh (Refresh Servers)

    User's Manual 4-4.2.3 Refresh (Refresh Servers) Click the Refresh button. The Searching for Servers box will pop up. 4-14...
  • Page 50 Configuration Utility The Server Manager list will be refreshed. 4-4.2.4 Restore (Restore Factory Default Settings) The factory default settings are: SIIG (Server Name), 192.168.3.22 (IP) and 192.168.3.1 (Gateway). Click the Restore button. 4-15...
  • Page 51 User's Manual Click OK. Click OK. Click Refresh to display the server list. 4-16...

  • Page 52: 4-4.2.5 Upgrade (Upgrade Firmware)

    4-4.2.5 Upgrade (Upgrade Firmware) Select a server, click the Upgrade button. In Select File box, browse to or type in the location of the file, then click Transfer. Do not unplug the power adapter from the USB Over IP during the update process.

  • Page 53: 4-4.2.6 Configure Ip Address

    User's Manual 4-4.2.6 Configure IP Address: Server Not On the Same Subnet At the Server Manger screen, select the server that is not on the same subnet. At Configure IP Address, click Yes. 4-18...
  • Page 54 Click Unblock. (Skip this step if not prompted) Either type in an IP address and Gateway or select DHCP, then click Change. Configuration Utility 4-19...
  • Page 55 User's Manual At the Server Manager screen, click Refresh. Yes should be displayed in the Same Subnet? column of the server. 4-20...

  • Page 56: Overview

    Chapter 5 Technical Support & RMA 5-1 Overview This chapter will give you instructions on how to obtain product information, contact technical support and return defective product. This user's manual is written with easy-to-understand instructions on how to configure and install this product in your system. We encourage you to consult this manual as your first step for technical assistance.
  • Page 57 Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. Step 2: After obtaining an RMA number, ship the product.
  • Page 58 Technical Support & Product Return Blank Page...
  • Page 59 User's Manual Blank Page...
  • Page 60 03-0315B...
