Summary of Contents for Outdoor Water Solutions AerMaster DW 7
- Page 1 ASTER LTIMATE OLAR ERATOR DW 7- DW 9 HP COMPRESSOR...
- Page 2 PANEL OR INSIDE BLACK ELECTRICAL BOX LOCATED IN THE CABINET. • The solar panel can develop voltages greater than 42V DC, which poses a shock and/or electrocution hazard. Outdoor Water Solutions recommends wearing electrically non- conductive gloves when handling the Solar Panel’s output leads.
- Page 3 • Monitor the panels. You don't need to do anything, but keep an eye on them. Make sure your diffusers are producing water movement on the pond surface at clear sun peak. • Keep the panels out of the shade. While you're at it, make sure that there are no new shade issues that weren't there when the system was installed.
- Page 4 Solar Panels Wired in Series-(amount of panels may vary) When solar panels are wired in series, the positive terminal of one solar panel is wired to the negative terminal of the next solar panel. When panels are connected in series: •...
- Page 5 Installation Instructions: Attach your airline to each of the airlines exiting the AerMaster cabinet. Run each airline out to the place in the pond where you want your diffuser and attach your diffuser. For diffusers with a base, lower the diffuser down to the bottom of the pond. Using a rope can help to keep the diffuser and base upright.
- Page 6 Troubleshooting- To reset the unit see toggle switch inside yellow box unscrew (4) flat head screws removing cover on yellow box. After cover is removed you will need to reset to OFF then ON. After toggle switch is reset, turn breaker to On position. Toggle Switch...
- Page 7 Troubleshooting - Indicator Lights There are three LED lights on the yellow controller. The indicator lights and recommended corrective actions are listed below. AC Power SOLAR WARNING Mode/Issue -Unit is OFF FLASHING - Startup - Running FLASHING - Standby - Over temperature - Power deration FLASHING FLASHING...
-
Page 8: Maintenance
Never use an abrasive soap or a cleaning sponge - the goal is to get the glass as clean and clear as possible and you don't want to scratch it. Outdoor Water Solutions recommends to use warm water and dishwashing soap. - Page 9 Air Filter replacement/Cleaning Air filter replacement or cleaning: Unplug system from power source. Remove compressor air intake filter and wash with soap and water or replace with new filter cartridge. Washing or replacing should be completed 2-4 times per year. Ideally every three months for changing filter and cleaning inside of cabinet.
- Page 10 Repair Kit Instructions *Repair kit contents may vary depending on your compressor. WARNING: Electrical shock hazard. Disconnect electrical Before beginning, you will need: supply before performing maintenance. Vent all air lines to release vacuum or pressure. Failure to follow these instructions may result T15 and T25 Torx driver in death, fire or electrical shock.
- Page 11 Press retainer plate with piston Inspect the leaf valves for damage Remove the cylinder o-ring(s) from cup into cylinder all the way to the or wear. NOTE: There is one the bot- tom of valve plate(s) and piston. The cylinder can be rotated install new o-rings.
- Page 12 This warranty covers all AerMaster aeration systems from purchase date against defects in workmanship. 1. Outdoor Water Solutions, Inc. (OWS) will replace or repair any part deemed to be defective by Outdoor Water Solutions, Inc., due to defects in quality and/or workmanship Note: Wearable parts are considered routine maintenance.
- Page 13 Troubleshooting Guide Problem What to look for Usual Cause How to Correct Problem Compressor shakes Check for low voltage Gauge of supplied If the gauge of wire is erratically and makes while compressor is wires to circuit incorrect, have an unusual noises under load possibly undersized or...
