Introducing the CyberSerial 4S PCIe

The CyberSerial 4S PCIe high-speed serial I/O card
provides four additional 9-pin serial ports.

Features and Benefits

•
Compliant with PCI Express Base Specification 1.0a
•
PCI Express 1-lane (x1) serial I/O card works with
PCI Express slots with different lane width
•
Installs in any available PCI Express slot and
provides four 9-pin RS232 serial ports via a fanout
cable
•
Spare enhanced low profile bracket is included to
work in low profile chassis
•
32-byte FIFO buffers dramatically increase data
transmit/receive speed and supports data rates up
to 230Kbps
•
Works as standard RS232 port or with 5V or 12V
power output for devices that require power

System Requirements

•
PCI Express-enabled system with an available PCI
Express slot
•
Windows
(32-/64-bit) / Vista (32-/64-bit)
04-0392B
CyberSerial 4S PCIe

Quick Installation Guide

2000 / XP (32-/64-bit) / Server 2003
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JJ-E40011-S2 and is the answer not in the manual?

Questions and answers

Related Manuals for SIIG JJ-E40011-S2

Summary of Contents for SIIG JJ-E40011-S2

  • Page 1: Quick Installation Guide

    CyberSerial 4S PCIe Quick Installation Guide Introducing the CyberSerial 4S PCIe The CyberSerial 4S PCIe high-speed serial I/O card provides four additional 9-pin serial ports. Features and Benefits • Compliant with PCI Express Base Specification 1.0a • PCI Express 1-lane (x1) serial I/O card works with PCI Express slots with different lane width •...

  • Page 2: Package Contents

    Package Contents • CyberSerial 4S PCIe adapter and spare enhanced low profile bracket • 4-port fanout cable and "Y" split power cable • Driver CD and user's manual Layout Jumper settings Fanout cable connector Figure 1: CyberSerial 4S PCIe Board Layout Jumper Settings (J1-J4) Short 2-3 = 0 volts (default) Short 1-2 = 5V...

  • Page 3: Hardware Installation

    Board connector Figure 2: 4-port fanout cable Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system.

  • Page 4: Driver Installation

    To install the card, carefully align the card's bus connector with the selected PCIe slot on the motherboard. Push the board down firmly, but gently, until it is well seated. Replace the slot bracket holding screw to secure the card. Replace the computer cover and reconnect the power cord.
  • Page 5 Right click My Computer, click Manage, then click Device Manager. Click on the + (plus sign) in front of Ports (COM & LPT), CyberSerial PCI 16Cxxx... should be displayed four times. Double click Multifunction adapters, SIIG CyberPro 4S PCI board should be displayed.
  • Page 6 Click on the + (plus sign) in front of Ports (COM & LPT), CyberSerial 16Cxxx... should be displayed four times. Double click Multifunction adapters, SIIG CyberPro 4S PCI board should be displayed. Changing COM Port Address Some serial devices need a specific COM port in order to work.

  • Page 7: Technical Support And Warranty

    Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. SIIG RMA department can also be reached at (510) 413-5333.
  • Page 8 6078 Stewart Avenue Fremont, CA 94538-3152, USA CyberSerial 4S PCIe is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are registered trademarks of Microsoft Corporation. Other names used in this publication are for identification only and may be trademarks of their respective companies.
