SIIG JJ-E20011-S2 Quick Installation Manual

Cyberserial dual pcie
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Introducing the CyberSerial Dual PCIe

The CyberSerial Dual PCIe high-speed serial I/O card
provides two additional 9-pin serial ports.

Features and Benefits

•
Compliant with PCI Express Base Specification 1.0a
•
PCI Express 1-lane (x1) serial I/O card works with
PCI Express slots with different lane width
•
Installs in any available PCI Express slot and
provides two 9-pin RS232 serial ports via a fanout
cable
•
Spare enhanced low profile bracket is included to
work in low profile chassis
•
32-byte FIFO buffers dramatically increase data
transmit/receive speed and supports data rates up
to 230Kbps
•
Works as standard RS232 port or with 5V or 12V
power output for devices that require power

System Requirements

•
PCI Express-enabled system with an available PCI
Express slot
•
Windows
(32-/64-bit) / Vista (32-/64-bit)
04-0384C
CyberSerial Dual PCIe

Quick Installation Guide

2000 / XP (32-/64-bit) / Server 2003
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JJ-E20011-S2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG JJ-E20011-S2

Summary of Contents for SIIG JJ-E20011-S2

  • Page 1: Quick Installation Guide

    CyberSerial Dual PCIe Quick Installation Guide Introducing the CyberSerial Dual PCIe The CyberSerial Dual PCIe high-speed serial I/O card provides two additional 9-pin serial ports. Features and Benefits • Compliant with PCI Express Base Specification 1.0a • PCI Express 1-lane (x1) serial I/O card works with PCI Express slots with different lane width •...

  • Page 2: Package Contents

    Package Contents • CyberSerial Dual PCIe adapter and spare enhanced low profile bracket • Mini 2-port fanout cable and "Y" split power cable • Driver software and user's manual Layout JI (serial port 1) Fanout cable connector Figure 1: CyberSerial Dual PCIe Board Layout Jumper Settings (J1, J2) Short 2-3 = 0 volts (default) Short 1-2 = 5V...

  • Page 3: Hardware Installation

    2-Port Fan-out Cable Figure 2: 2-Port fanout cable Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system.

  • Page 4: Driver Installation

    Set J1 and J2 jumper settings to the desired voltage only if your serial device needs additional power from the serial port. However, most serial devices do not require additional power. information see Jumper Settings on page 2. The jumpers can be removed if power is not required. If power output is required, connect the board's power connector.
  • Page 5 Right click My Computer, click Manage, then click Device Manager. Click on the + (plus sign) in front of Ports (COM & LPT), CyberSerial PCI 16Cxxx... should be displayed two times. Double click Multifunction adapters, SIIG CyberPro 2S PCI board should be displayed.
  • Page 6 Click on the + (plus sign) in front of Ports (COM & LPT), CyberSerial PCI 16Cxxx... should be displayed two times. Double click Multifunction adapters, SIIG CyberPro 2S PCI board should be displayed. Changing COM Port Address Some serial devices need a specific COM port in order to work.

  • Page 7: Technical Support And Warranty

    Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. SIIG RMA department can also be reached at (510) 413-5333.
  • Page 8 6078 Stewart Avenue Fremont, CA 94538-3152, USA CyberSerial Dual PCIe is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are registered trademarks of Microsoft Corporation. Other names used in this publication are for identification only and may be trademarks of their respective companies.
