HDMI over CAT5e Transmitter
Quick Installation Guide
Introducing the HDMI over CAT5e Transmitter
The HDMI over CAT5e Transmitter provides a cost effective
solution by which high definition video and high quality
audio can be transmitted to mulitiple locations over long
distances using inexpensive CAT5e/6 cables.
Features and Benefits
•
Extends video/audio transmission from an HDMI
source to an HDMI display over one economical
CAT5e/6 cable
•
Minimize cable skew with the adjustable 8-level
equilization knob
•
Embedded EDID feature support & learning the
EDID of the connected HDMI display
•
Supports local HDMI display
•
Supports distances up to 60m/200ft @ 1080i or
40m/130ft @ 1080p with CAT5e cables
•
Supports up to 15m/50ft HDMI cables (Input/
Output)
Technical Specifications
•
HDMI 1.2a compliant & HDCP compatible
•
Video bandwidth: 1.65 Gbps
•
Input: 1x HDMI (female, 19 pin)
•
Output: 1x HDMI (female, 19 pin), 1x RJ45, 1x 3.5mm
stereo audio jack
04-0505A
1
Advertisement
Table of Contents
Related Manuals for SIIG CE-H20311-S1
Summary of Contents for SIIG CE-H20311-S1
- Page 1 HDMI over CAT5e Transmitter Quick Installation Guide Introducing the HDMI over CAT5e Transmitter The HDMI over CAT5e Transmitter provides a cost effective solution by which high definition video and high quality audio can be transmitted to mulitiple locations over long distances using inexpensive CAT5e/6 cables.
- Page 2 Package Contents • HDMI over CAT5e Transceiver & 4 rubber pads • Power adapter (5V DC) • Quick Installation Guide Layout HDMI In Switch • HDMI In LED: will light up when your HDMI source is powered on and working properly •...
-
Page 3: Hardware Installation
Hardware Installation Please read and follow the safety guidelines to protect yourself from possible injury and to minimize the risk of damage to your equipment. • Do not attempt to service the unit yourself. • Provide proper ventilation and air circulation, do not use near water •... - Page 4 Speakers HDMI display Speakers HDMI cable HDMI display Figure 2: Application HDMI source Transmitter Power adapter CAT5e cable (up to 200ft) Transceiver Power adapter CAT5e cable to Transceiver or Receiver...
- Page 5 HDMI Pin Definition Pin 1 TMDS Data2+ TMDS Data2 Pin 2 Shield Pin 3 TMDS Data2- Pin 4 TMDS Data1+ TMDS Data1 Pin 5 Shield Pin 6 TMDS Data1- Pin 7 TMDS Data0+ TMDS Data0 Pin 8 Shield Pin 9 TMDS Data0- Pin 10 TMDS Clock+...
- Page 6 Notes Transmission length is affected by the type of LAN cables, the type of A/V sources, and the type of A/V displays. Test results show that solid LAN cables (usually in 300m/1000ft form) can transmit over longer distances than stranded LAN cables (patch cords), shielded STP cables perform better than unshielded UTP cables, and solid UTP CAT5e cables show longer transmission distances than...
- Page 7 Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. Step 2: After obtaining an RMA number, ship the product.
- Page 8 Fremont, CA 94538-3152, USA Ph: 510-657-8688 HDMI over CAT5e Transmitter is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Other names used in this publication are for identification only and may be trademarks of their respective companies.
