Cooper Lighting Shaper 260-A SERIES Specification Sheet

D E S C R I P T I O N
260-A Luminous Cylinder features a direct downlight component.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Solid aluminum with a matte
white acrylic cylinder.
F i n i s h
Standard: Natural Aluminum
(NA) [Sustainable Design].
Premium: Matte White (MW),
Lacquered Satin Aluminum
(SAL), Clear Anodized Aluminum
(CAL) or Custom Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
O R D E R I N G I N F O R M AT I O N
Sample Number: 260-A-CFL/1/18-277V-CAL
Series Lamp
CFL/1/18
260-A Cylinder Surface =
CFL/1/26
INC/1/75
Notes:
1
Available with CFL only.
2
S upplied by others.
3
Interior applications only.
L a m p / S o cke t
One (1) 18W (GX24q-2) or 26W
(GX24q-3) 4-pin triple CFL lamp
or 75W A-19 lamp. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
O p t i o n s
Damp Location (DL): All Painted
Finishes only, Perforated Band
(PFB), Remote Emergency Ballast
- Supplied by others (REM), MRI
applications, (INC only) - Contact
factory. Energy Star Rating-
Consult Factory.
Voltage Finish
120V
Standard
1
277V
NA Natural Aluminum =
1
347V Premium
CAL Clear Anodized =
Aluminum
CC Custom Color =
MW Matte White =
SAL Lacquered Satin =
Aluminum
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
L a b e l s
U.L. and C.U.L. approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard surface
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
3
DL Damp Location =
REM Remote =
Emergency
2
Battery
PFB Perforated Band =
shaperlighting.com
Type
Date
260-A SERIES
S u r f a c e L u m i n a i r e
S t a r t e r C o l l e c t i o n
L u m i n o u s C y l i n d e r
STARTER
COLLECTION
Shaper's exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
SUSTAINABLE
DESIGN
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
QUICK SHIP (QS)
Shaper's Quick Ship program
features over thirty-four fixtures
with finish options such as Satin
Chrome, Natural Aluminum and
Satin Brass and a wide variety of
lamp selections. All products ship
in five days from receipt of order.
Refer to the Icon Legend
Link on shaperlighting.com.
