- Page 1 V200 V1 Feb 15...
-
Page 2: Table Of Contents
Unpacking and unit placement Installation 4 01 Connecting to power supply Operation 5 01 Turning extractor On / Adjusting Airflow Maintenance 6 01 Cleaning the unit Filter replacement Replacement Parts 7 01 Consumable Spares & Filter Disposal System Specifications V200 Specifications... -
Page 3: Overview 1
Overview Clips Air Inlet Filter Condition Light Company Branding... - Page 4 Overview Air Outlet/Motor Cooling Fuse Compartment Mains Inlet Main Isolation Switch...
-
Page 5: Safety Instructions
Dangers to eyes, breathing and skin to within this manual. Once used, the filter within the V200 system may contain a mixture of particulates, some of which may be sub-micron size. When the used filters are moved it may agitate some of... - Page 6 Safety Instructions Serial Number Label Warning and Information labels Location: Next to mains inlet. The following listing details labels used on your extraction Meaning: This label contains a variety of information about unit. the extraction unit, including. Goggles, Gloves & Mask Label •...
-
Page 7: Before Installation 3
Before installation Packaging Removal & Unit Placement Before installation, check the extraction unit for damage. All packaging must be removed before the unit is connected to the power supply. Please read all instructions in this manual before using this extractor. 1. -
Page 8: Installation 4
The supply cord should only be replaced by a BOFA engineer as an electrical safety test may be required after replacement. The extraction unit MUST be connected to a properly earthed outlet. -
Page 9: Operation 5
Operation Turning extraction unit On The V200 features a fused IEC inlet for the mains cable as well as a main isolation switch. The unit can be powered on and off by pressing the red rocker switch to the right hand side. -
Page 10: Maintenance 6
Maintenance no longer removes fume efficiently. All filters are tested to BS3928. A certificate of conformity for each filter is available on request. It is recommended that a spare set of filters are kept on site to avoid prolonged unit unavailability. Part numbers for replacement filters can be found on the filters fitted in your system. - Page 11 Maintenance Filter Replacement The V200 will alert the user when its filter needs to be replaced. When the filter becomes full the red ‘Filter Condition ‘ light will glow. To remove and replace the combined filter follow the procedure detailed below.
-
Page 12: Replacement Parts
Deposit Comment The V200 contains a pre filter and combined filter. These Listing* should be replaced when instructed to do so by the V200 15 02 03 Can be disposed of as non- system (see section for replacing the filters) Hazardous hazardous waste. -
Page 13: System Specifications
System Specifications Unit: V200 Capacity: 90m³h (53CFM) Weight: 7kg (15lbs) Motor: Centrifugal Fan Output: 230V:90W 115V: 107W Electrical supply: 115-230V Hertz: 50/60Hz Full Load Current: 230V:0.5A 115V: 0.9A Noise Level: Below (at typical operating speed) Size: Metric Imperial (mm) (inches) - Page 14 Contact Information BOFA Headquarters 21-22 Balena Close Creekmoor industrial Estate Poole Dorset BH17 7DX Phone: +44 (0) 1202 699444 BOFA Americas 303 S.Madison Street Staunton Illnois 62088 Phone: 001 (618) 205-5007...
