BitFenix Spectre ARGB SE Kit Quick Installation Manual

Quick Installation Guide
Spectre ARGB Fan
Dimensions 120 x 120 x 25mm
Fan: 12Vdc ± 5%
Operating Voltage
LED: 5Vdc ± 5%
Starting Voltage 5Vdc
Max. Current 0.35A
Speed 1200r.p.m±10%
Air Flow(CFM) 42 CFM±10%
Air Pressure(H²O) 0.67 mm H²O
Noise dB(A) 22 dB(A)
Bearing Type Rifle Bearing (RFB)
Accessories Fan Screw x 4
Fan header
ARGB header (3Pin 5V)
SE Controller
SATA Power Header
ARGB header (3Pin 5V)
Rated voltage DC12V/DC5V
With 7 of ARGB 3Pin 5V sockets, 6 of 12-volt fan
sockets.
A single ARGB sockets can bear up to 36 LEDs
Fan sockets support up to 8 of 12V DC fans
A total of 39 lighting illumination modes
The light can be controlled by the remote control
compatible with Asus AURA SYNC, MSI Mystic
Light, Gigabyte RGB Fusion 2.0, Asrock Po
loychrome SYNC and Biostar VIVID LED DJ.
SE Remote
Short press to turn on the light.
Long press to switch to remote
control.
Press this key to enter the auto
play mode when it is on.
Press to turn off the light.
Accelerate the fan speed.
Slow down the fan speed.
select the mode up.
Connect fans on controller
select the mode down.
Brightness +
Brightness –
Long Press to switch to motherboard
control.
Press the buttons of different colors
and the corresponding light colors
will appear.
Connect SATA cable on the controller
S ATA
Press ON on remote to turn on the light
