241-9834
JIGSAW
Operator's Manual
SAVE THIS MANUAL
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
For questions about this product, Please call 1-866-915-8626

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 241-9834 and is the answer not in the manual?

Questions and answers

Related Manuals for Toolshop 241-9834

Summary of Contents for Toolshop 241-9834

  • Page 1 241-9834 JIGSAW Operator’s Manual SAVE THIS MANUAL You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference. For questions about this product, Please call 1-866-915-8626...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING When using electric tools, machines or equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury. READ INSTRUCTIONS BEFORE USING THIS TOOL 1. KEEP WORK AREA CLEAN. Cluttered areas can cause injuries. 2.
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS 15. USE EYE PROTECTION. Use a full-face mask if the work you’re doing produces metal filings, dust or wood chips. Goggles are acceptable in other situations. Wear a clean dust mask if the work involves creating a lot of fine or coarse dust.

  • Page 4: Specifications

    SPECIFICATIONS Voltage:120V AC, 60Hz. Current rating: 3.0 Amp No load speed: 3,000 /min Maximum depth of cut: 2-3/16” (Wood), 1/4” (Steel) Includes: 1 wood cutting blade 1 hex key stored in the housing below the cord sheath FUNCTIONAL DESCRIPTION A. Blade clamp B.

  • Page 5: Operating Procedures Maintenance

    OPERATING PROCEDURES OPERATING PROCEDURES OPERATING PROCEDURES Running the JigSaw 1. Plug in the tool. 2.Hold the saw firmly. Make sure that saw blade travel is not obstructed. Depress the trigger switch to turn the tool on. Engage the lock-on button and release the trigger switch to maintain the tool operating itself.

  • Page 6: Parts List

    PARTS LIST ADJUSTMENTS Please refer to the schematic drawing on page 7. Part Description Quantity Part Description Quantity Screws MST4*14 Central support Support roller Bearing 608ZZ Sole Rotor Square nut Wire holder Left housing Screw ST4.2*12 Shield Brush-holder Reciprocating lever support Carbon Brush Baize components Bearing607ZZ...

  • Page 7: Schematic Drawing

    SCHEMATIC DRAWING WARNING: Repairs should be made by an authorized repair center. Do not open or disassemble this power tool. Contact customer service at 1-866-915-8626 questions regarding this power tool.
  • Page 8 TOOL SHOP® JIGSAW WARRANTY 1-YEAR LIMITED WARRANTY: This TOOL SHOP brand power tool carries a 1-Year Limited Warranty to the ® original purchaser. If, during normal use, this TOOL SHOP tool fails due to a ® defect in material or workmanship within one (1) year from the date of purchase, simply bring this tool with your original sales receipt back to your nearest MENARDS retail store.
